Brildor SC-1.1 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User manual
Shin Pad
Heat Press Machine
Brildor SC-1.1
Ref. 045087
Page
1 | 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-1.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Brildor SC-1.1

Summary of Contents for Brildor SC-1.1

  • Page 1 User manual Shin Pad Heat Press Machine Brildor SC-1.1 Ref. 045087 Page 1 | 9...

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION ............................3 PARTS OF THE PRESS ..........................3 TECHNICAL DETAILS ........................... 4 III. DIMENSIONS ..............................4 CONTROL PANEL OPERATION ......................5 Temperature ............................5 Time ................................. 5 INSTRUCTIONS FOR USE .......................... 6 Recommended sublimation parameters ................6 TROUBLESHOOTING ..........................7 VII.

  • Page 3: Introduction

    INTRODUCTION This heat press machine has been specially designed for personalisation using dye sublimation printing. Thanks to its pressure, heat and time control, the transfer will be permanently embedded in the shin pad. Manual opening and closing. The shin pad heat press has a swivel arm that opens •...

  • Page 4: Technical Details

    TECHNICAL DETAILS Model Brildor SC-1.1 Shin Pad Heat Press Machine Type Manual/Swing Away Controller Digital Pad thickness 0.8 cm Side opening angle 180º Voltage 220 V / 50 Hz Power 450 W / 2 A Timer 0-9999 s Temperature range 0-221ºC...

  • Page 5: Control Panel Operation

    CONTROL PANEL OPERATION Temperature Press the arrows Press the OK button The screen shows P-1 and set the temperature you need Time Press the OK button after Press on the arrows Press the OK button selecting the temperature and set up the time. again after setting up setting.

  • Page 6: Instructions For Use

    INSTRUCTIONS FOR USE 1. Make sure the plug is securely connected to the power socket, and press the power switch. 2. Set the temperature and time. You can use the tables above as a reference. 3. The press will notify you when the set temperature has been reached.

  • Page 7: Troubleshooting

    THINGS TO KEEP IN MIND • When the temperature of the heat platen reaches 80ºC (176ºF), the extractor fan will turn on automatically. This helps to keep electrical parts cool and extends their useful life. • Turn off the machine when it’s not in use and remove the plug from the power socket.
  • Page 8 • If the heating platen isn't working, and the relay has already been replaced, check if the heating plate is defective or if the power cable is loose. If the heating plate is defective, you should change it. The temperature is higher than expected: •...
