Summary of Contents for AOFAR GX-2S
- Page 5 To select yard and meter, just click the "M" button to change" Y"(yard) and "m"(meter). The GX-2S range finder can be used to measure distances in yard or meter. The unit of measure indicators are located in the lower right portion of the...
- Page 6 Pressing "M" button that is units switching button and hold it for approximately 3 seconds. The data displayed at the top will disappear, leaving only a straight line distance on the LCD, which is designed for golf games. lf you want to turn on the slope mode, just press the "M"...
- Page 7 2.Placing the aiming circle (located in the center of view) on a target over than 6 yards away, click "POWER" button . The range and angle, slope reading will be displayed on LCD. LCD data shows: Line of sight distance until auto power-off. (Straight-line distance is 20 yards, angle is 4.9 degrees, and slope is 22 yards.) For the slope of uphill/downhill slope.
- Page 8 Lock mode sign : After you lock onto flag successfully, the circle on flag sign will show.(As the picture shows) Method: Pressing "POWER" button and scan from far to flag, you will get distance and feel vibration. At the same time, the circle on the flag sign will show Method: Align the flag and keep still, pressing "POWER"...
- Page 9 Note: Within 50 yards, the flag is large. According to the working principle, laser can't measure the distance difference between two targets. lt won't vibrate, but can measure distance normally. Above 50 vards, the flag is small. According to the working principle, laser can measure the distance difference between two targets.
- Page 11 Uphill display: The target is uphill Downhill display: The target is downhill Display order: slope,angle then slope Lock mode sign: lcon change comparison Battery indicator Target marker: Please superimpose the center circlewith target object to be measured Measuring distance: Straight-line distance Distance unit display: The distance unit at your option...
- Page 12 ① Units switching button/ "M" button (m: meter/Y: yard) ②Power/reading button ③Rotary focusing ④Observing eye lens/LCD (liquid crystal display) ⑤Sling connecting hole ⑥Laser transmitting objective lens ⑦Laser receiving objective lens...
- Page 13 The GX-2S range finder emits invisible, eye safe, infrared energy pulses. Sophisti- cated digital technology instantaneously calculates distances by measuring the time, which it takes for each pulse to travel from the rangefinder to the target and back to rangefinder. The color, surface smoothness, size and sharpness of target will affect its reflectivity and range.
- Page 14 Remove the battery cap by rotating the cap counter-clockwise. Insert a CR2-3V battery. Put the negative pole of lithium battery into battery compartment first. Replace the battery cap. Note: lt is recommended that the battery should be replaced once every 12 months. Notice: Replace the battery when Low batteryindicator shows.
- Page 15 Distance measurement of ascending slope: Slope is farther than the straight-line distance. Distance between AB points=distance between AD points parabola 2 in a straight-line 97YHit the ball in accordance with the distance measured with the strike parabolal, the angle parabola 1 of slope is + 6.2 °, and the ball will arrive at the point C.
- Page 16 *Laser rangefinder*1 *Instruction manual *1 *Handbag*1 *Lanyard*1 *Cleaning cloth *1 *Battery*1 *Carabiner*1...
- Page 17 Do not drop, disassemble, modify or repair the product by yourself to avoid damage to the product. lf there is any abnormality or problem, please contact us. Please use and store the product within the operating temperature range (-10℃~50℃). Do not use the product in dusty areas to avoid failures. Do not keep the product under the sun or at high and low temperatures for a long time.
- Page 18 lt is normal for lens to be wet when the temperature changes suddenly. In this situation, remove the battery and do not use the device until it becomes dry. Moving from a cold place to a hot room of the product may dew on the appearance and internal parts.
- Page 19 Prevent leakage, heat, fire, etc. Must not disassemble and modify the product. Must not throw it on fire or store it at a high temperature. Avoid direct contact with metal objects such as coins or keys (in a pocket or bag). If the skin touches the leaked liquid, rinse with cold water immediately.
- Page 20 If LCD can't be turned on: Pressing "POWER" button again. Check battery or replace it if necessary. (Determine if there is an insulator blocking the battery power) If Distance measurement is abnormal: Please confirm whether the lens have dirt. Please make sure that the mark circle overlap your target. It can be turned on, but the data will not be displayed: Low battery voltage, please change the battery.
-
Page 21: Measurement Error
Measurement error: M/Y is not switched. Rain and fog and small target will also affect the measurement results. Battery power runs out quickly: Low ambient temperature will cause the battery power runs out quickly. lf the battery has not been used for a long time after unpacked, the battery power will runout quickly. - Page 22 Method1: Follow our instagram "usaofar ", then contact us Method2: Send your questions to our mailbox "service@aofar.com" Method3: Visit our website "www.aofar.com" Step 1: Visit website https://www.aofar.com Step 2: Find "VIP WARRANTY" and click it, fill in your information to register...
