1
D x2
Do not fully tighten screws.
Ne pas serrer complètement les vis.
No apriete completamente los tornillos.
Longer Front
Leg Brace
FRONT
D x2
5
C x2
E x2
F x2
UNDER
E x2
F x2
Do not fully tighten screws.
Ne pas serrer complètement
les vis.
No apriete completamente
los tornillos.
C x2
2
A x2
Do not fully tighten screws.
Ne pas serrer complètement les vis.
No apriete completamente los tornillos.
FRONT
A x2
6
A x2
A x2
Do not fully tighten screws.
Ne pas serrer complètement les vis.
No apriete completamente los tornillos.
3
D x2
Do not fully tighten screws.
Ne pas serrer complètement les vis.
No apriete completamente los tornillos.
FRONT
Shorter Back Brace
with tag facing up
D x2
7
Fully tighten all hardware from all
previous steps. DO NOT
OVER-TIGHTEN.
Serrer complètement tous les
éléments de fixation des étapes
précédentes. NE PAS TROP SERRER.
Apriete completamente todos los
materiales de todos los pasos
anteriores. NO APRIETE DEMASIADO.
4
B x6
E x6
F x6
INSIDE
E x6
F x6
FRONT
B x6
