Costco Recliner 18586 Assembly Instructions

Please read the assembly instructions thoroughly and assemble this recliner per the assembly instructions. Please note that
using an incorrect assembly method may damage the structure of this recliner!
Recliner Parts & Hardware List
Part # Description Quantity
Large Wooden Seat Base, Central Post,
1 Wooden Seat Frame (larger), Metal Arm 1
Rest Frame & Seat Cushion
2 Back Cushion 1
3 2-1/4" Machine Screws (φ8mm) 2
4 Nuts 2
5 1" Joint Screws 2
6A Right Arm Pad 1
6B Left Arm Pad 1
7 1" Machine Screws (φ1/4") 6
14 Wrenches 2
18586 RECLINER WITH OTTOMAN
Recliner Assembly Instructions
TWO PEOPLE ARE RECOMMENDED FOR BACK
CUSHION ASSEMBLY!
Place the following recliner parts on the floor:
Step 1:
1). The pre-assembled Large Wooden Seat Base, Central
Post, Large Wooden Seat Frame, Metal Arm Rest Frame
and Seat Cushion
2). Back Cushion
3). 6A Right Arm Pad and 6B Left Arm Pad
Bring up the Back Cushion (2), Line up the holes of the tabs
Step 3:
on the bottom of the Back Cushion (2) and the metal rings
on the rear of the Seat Cushion (1). Insert the 1" Joint
Screws (5) through the metal rings in the Nuts (4) and
tighten the 1" Joint Screws (5).
Attach the Back Cushion (2) onto the pre-assembled Large
Step 2:
Wood Seat Base, Central Post, Large Wooden Seat
Frame, Metal Arm Rest Frame & Seat Cushion (1). Align
the holes of the Metal Arm Rest Frame (1) to both sides of
the Back Cushion (2). Fasten by using 2-1/4" Machine
Screws (3).
Attach the Right Arm Pads (6A) and Left Arm Pad (6B)
Step 4:
onto the Metal Arm Rest Frame (1) using 1" Machine
Screws (7).
