Summary of Contents for hogar SMART MINI HUB
- Page 1 SMART MINI HUB SMART CONTROLLER SERIES #Smarthomehub...
- Page 3 & choosing Hogar Smart Mini Hub. This manual is designed to help you install your Hogar Smart Mini Hub in an easy and hassle-free manner. Please follow all the steps given below and experience the safety and comfort of your very own, personal smart space.
-
Page 4: Table Of Contents
SMART MINI HUB TABLE OF CONTENTS USAGE NOTICE 1.1. Warnings and Considerations 1.2. Precautions PRODUCT DETAILS 2.1. Description 2.2. Features 2.3. Technical Specifications 2.4. App Registration / Login 2.5. Configuration Process WARRANTY... -
Page 5: Usage Notice
Install this device by following the socket type mentioned. Using this product in any manner other than how it this document VOIDS your warranty is referred to in Further, Hogar Controls is NOT liable for any damage incurred due to the misuse of the product. - Page 6 Avoid pressing hard on the device body, reset button, and connecting ports. This is an electronic device with complex components. Handle and install with care! If you are not sure about any part of these instructions, please consult a Certified Electrician to perform the installation process.
-
Page 7: Precautions
1.2. PRECAUTIONS Ensure the below DOs & DON'Ts are followed to enjoy a seamless product experience: - TURN OFF the product before cleaning. - Clean the product with a soft dry cloth. DON'Ts - DON'T drop or disassemble the device. - DON'T touch the device with sharp or hard objects. -
Page 8: Product Details
PRODUCT DETAILS 2.1 DESCRIPTION Hogar Smart Mini Hub controller is designed for low-power connected home requirements, and is compatible with up to 60 devices, allowing you to collaborate and control your entire home simultaneously using the exclusive Hogar Mini S App. - Page 9 - It lets you monitor the history of events. - It supports IR device control (TV/AC/Set-top box) It can be accessed both locally and remotely. NOTE: For optimal performance, place Hogar Smart Mini Hub five feet above the ground level vertically.
-
Page 10: Technical Specifications
2.3. TECHNICAL SPECIFICATIONS Model Number HC-01-SMB-IN Brand Name Hogar Power Requirement 5V DC MIPS24KEc @580 MHz RAM & ROM 128MB & 32MB Setup Mobile Application Number of Z-Wave Upto 60 devices Devices supported per controller Encryption Security Level Multi-Controller Upto 4... - Page 11 Operating 32°F - 104°F or 0°C - 40°C Temperature and & 0-90% Humidity Internet Connectivityl Wi-Fi Range 30m Indoor and 50m Outdoor...
-
Page 12: App Registration / Login
2.4. APP REGISTRATION / LOGIN Sign Up: - Open the Hogar Mini S App. - You can either sign up with your mobile number or email id. - Enter a password of your choice and click “Register”. - You will receive an OTP which is valid for 10 mins. Enter the OTP and sign up. -
Page 13: Configuration Process
2.5. CONFIGURATION PROCESS Adding Hogar Smart Mini Hub to Hogar Mini S App: - Click on “Add Home” or Tap on the “+” button on the top right corner of the screen. - Enter the following details: Home name, Domain (Unique without space &... - Page 14 If DHCP, click on “Continue”. It will show Successfully configured, details and click on “Continue”. - Connect your phone to the internet and go back to the mobile App, click on “OK”. - Wait until Smart Mini Hub gets rebooted.
- Page 15 SETTING SMARTHOME TO SMART MINI HUB SETUP YOUR FLOORS Adding Floors to your Hogar Mini S App - Go to Settings → General → Config Room & Floor. Tap ‘ ’ button in the top right corner. - Name the “Floor”.
- Page 16 - Add the ‘Room details’ and type in the Room Name. - Assign a photo by allowing Hogar Mini S App to click pictures by tapping ‘’Allow’’. - The created Floors appear as a list. Deleting your Room: - Go to General →...
- Page 17 It is controlled through the Hogar Pro S App. SETUP FOR MULTIPLE HCs Hogar Smart Mini Hub allows multiple controllers on the same network. There is only one primary Home Controller which can act as Master and the rest as Slave controllers. Slave controllers also communicate with devices directly connected to it.
- Page 18 ADDING/ DELETING SMART DEVICES TO YOUR Smart Mini Hub SETUP FOR Z-WAVE SMART DEVICES Adding Smart Devices: - Scroll through the Hogar Mini S App, choose Z-Wave to “Add” devices. - You will receive a pop-up notification display stating “Device Added”.
- Page 19 Set Timer for Rule: Enable Timer and Scroll through the timer, choose a time between 0 and 23 hours and 0 to 59 minutes and click on “Confirm” to save. Add input/output devices: Add the input and output devices to Smart Mini Hub.
- Page 20 Normally, various smart sensors can be automated through scenes to trigger your smart switches. No manual intervention or internet connectivity is required once certain scenes are set by you on your Hogar Mini S App.
- Page 21 Add a Scene: Go to scenes. Tap the “ ” button in the top right corner of the screen. Add scenes to the room by selecting the “Room” in the scene. Tap “Done” on the top right corner when you are done with creating the scene.
- Page 22 Edit Existing Scene: Tap on a specific scene from the list, and change the data accordingly and tap “Done”. Delete a Scene: Go to Settings → General → Scene → Select the Scene → Scroll to bottom → Click on Delete Scene GROUPS Using this functionality, you can Group devices of the same type i.e Switches grouping, RGBW grouping, Light dimmer, Fan speed...
- Page 23 Delete a Group: Go to Settings → General → Group → Select the Group → Scroll to bottom → Click on Delete Group SCHEDULE To view the list of schedules, go to Settings → General → Schedules Add a Schedule: Go to Settings →...
- Page 24 RESETTING INFORMATION Network and Factory reset (Using reset button) LED Indication for Network reset: - Press and hold the reset button the LED changes colors from red - magenta - blue - white at which point release the reset button. LED Indication for Factory reset: - Press and hold the reset button the LED changes colors from red - magenta - blue - white- red - magenta - blue at which...
-
Page 25: Warranty
Warranty Hogar offers an Exclusive 18-Month Warranty on any product that covers defects in materials and quality under normal use of the Product. The Terms and Conditions of this 1.5 YEARS LIMITED WARRANTY can be viewed on www.hogarcontrols.com or scan... - Page 26 CONGRATULATIONS You've successfully installed & Configured Hogar Smart Mini Hub. Now you can experience seamless control of your home with Hogar Mini S Application. Add more smart home devices to your home from our range of smart home solutions and live a smart life.
- Page 27 Hogar Pro App. Add more to your home from our range of smart home automation solutions and live the smart life. Hogar Controls Inc, 46040 Center Oak Plaza, Suite 125, Sterling, Virginia 20166 | Phone : +1 703 844 1160 INDIA Sandhya Techno-1, Khajaguda X Road, support@hogarcontrols.com...
