  • Page 1 All manuals and user guides at all-guides.com USER'S MANUAL...
  • Page 2 all-guides.com...

  • Page 3: Precautions Before Using

    All manuals and user guides at all-guides.com PRECAUTIONS BEFORE USING Please read the User's Manual before using. It gives you important information about how to operate the portable radio. Thank you for purchasing this Radio. Please put the radio and accessories where the children can not touch. We believe this easy-to-use radio will provide reliable and dependable communication.

  • Page 4: Table Of Contents

    All manuals and user guides at all-guides.com FEATURES UHF/VHF dual band receive/transmit Frequency deviation and offset direction CONTENTS FM radio (65-108MHz) setting Multi step frequency Large LCD display SUPPLIED ACCESSORIES Busy channel lock High capacity Li-ion battery and smart charger PC programmable Time-out-timer(TOT) READY TO WORK...
  • Page 5 All manuals and user guides at all-guides.com CONTENTS CONTENTS STEP FREQUENCY(STEP) SCAN RESUMED MODE OUTPUT POWER (TXP) PTT ID（PTT-ID） BATTERY SAVING (SAVE) PTT ID PROLONG TIME（PTT-LT） VOX FUNCTION (VOX) A CHANNEL DISPLAY MODE（MDF-A） WIDE/NARROW BANDWIDTH (W/N) B ChANNEL DISPLAY MODE（MDF-B） AUTO BACKLIGHT （ABR) BUSY CHANNEL LOCK（BCL）...
  • Page 6 All manuals and user guides at all-guides.com CONTENTS CONTENTS TAIL TONE ELIMINATION（STE） REVERSE FUNCTION（ R ） TAIL TONE ELIMINATION WHEN THROUGH REPEATER（RP-SET） FREQUENCY SCANNING DELAY TIME OF TAIL TONE ELIMINATION WHEN THROUGH REPEATER（RPT-RL） CHANNEL SCANNING DISPLAYS WHEN POWER ON（PONMSG） AUTOMATIC SEARCH FM RADIO（FM） CALL END WARNING TONE（ROGER）...

  • Page 7: Standard Supplied Accessories

    All manuals and user guides at all-guides.com CHARGING NOTES (1) SUPPLIED ACCESSORIES Carefully unpack the portable radio. We suggest that you check the following Battery packs are not charged when they are shipped, charge them before use. items before you throw away the packing materials. STANDARD SUPPLIED ACCESSORIES Initially charging the battery pack after purchase or extended storage (longer than 2 months) will not bring the battery pack to its greatest capacity or its normal capacity, which can be done only...
  • Page 8 all-guides.com...

  • Page 9: Installing External Speaker/Microphone

    All manuals and user guides at all-guides.com INSTALLING EXTERNAL SPEAKER/MICROPHONE ATTACHING THE BATTERY PACK Insert the speaker/microphone plugs into the speaker/microphone jacks. Slide the battery pack into the back of the radio in the direction of the arrow(①), then lock it with the battery release button.
  • Page 10 All manuals and user guides at all-guides.com RELEASING THE BATTERY PACK DIAGRAM Jacklight Antenna Power/Volume switch Turn off the radio before releasing the battery pack. Push the battery release button in the direction of the arrow(①)as shown below. LCD display At the same time push the battery back.

  • Page 11: Lcd Display

    All manuals and user guides at all-guides.com LCD DISPLAY BASIC OPERATION PTT Key Transmitting/Receiving switch key: Press "PTT" to transmit and speak to microphone. Release "PTT" to receive. CALL Key (FM/Alarm) LCD ICON EXPLANATION Press it for a short time to turn on FM radio function.Operate it again to turn it off. Press it for a long time to turn on Alarm function.Operate it again to turn it off.
  • Page 12 All manuals and user guides at all-guides.com BASIC OPERATION BASIC OPERATION Function Keypads *SCAN Menu/Confirm key： Press Scan key for a short time to activate RX/TX reverse function. MENU It’s used for activating the menu, choose each menu item and confirm the parameter. Press Scan key for more than 2s to start frequency or channel scanning.

  • Page 13: Menu Functions

    All manuals and user guides at all-guides.com FAST MENU SETTING FAST MENU OPERATION FLOW 1 Press Menu key; Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page Characterr 2 Press Menu key again; 3 Press Up/Down key to select Menu No. Press Menu key, 4 press Menu to confirm or EXIT key to exit(As picture below).
  • Page 14 all-guides.com...
  • Page 15 All manuals and user guides at all-guides.com FAST MENU OPERATION FLOW FAST MENU OPERATION FLOW Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page...
  • Page 16 All manuals and user guides at all-guides.com FAST MENU OPERATION FLOW FAST MENU OPERATION FLOW Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page...

  • Page 17: Dual-Watch Operation（Tdr-Ab

    All manuals and user guides at all-guides.com FAST MENU OPERATION FLOW FAST MENU OPERATION FLOW Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page...
  • Page 18 All manuals and user guides at all-guides.com FAST MENU OPERATION FLOW FAST MENU OPERATION FLOW Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page Feature Function Function Set LCD Display Parameter LCD Display Selectable Confirm key Back Key Page...
  • Page 19 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） VOX Function（VOX）——Menu No.4 Auto Backlight（ABR）——Menu No.6 When this function is on, the system will recognize your talking to the microphone and then it will This function can adjust the auto off time after radio display backlight is on.
  • Page 20 all-guides.com...
  • Page 21 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Squelch Level（SQL）——Menu No.0 Output Power（TXP）——Menu No.2 This function can turn on or off the monitor according to signal strength. This function can choose High/Low output power.
  • Page 22 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Keypad Sound Reminding（BEEP）——Menu No.8 Receiving DCS（R--DCS）——Menu No.10 This function is to set the reminding sound. It will beep when you press keypad. Using this function can set your privacy and prevent disturbance from others or match with the code of other radios.
  • Page 23 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Voice Reminding（VOICE）——Menu No.14 Transmitting DCS（T--DCS）——Menu No.12 Using this function can set your privacy and prevent disturbance from others or match with the code It will voice remind you when you operate the radio.
  • Page 24 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） DTMFST（DTMFST）——Menu No.16 Scan Resumed Mode（SC-REV）——Menu No.18 This function can scan activities from other radios’ frequencies or channels. You can select the scan This function is that when the radio transmits, the recipient can hear the DTMF and ANI-ID code issued by the radio.
  • Page 25 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） B Channel Display Mode（MDF-B）——Menu No.22 PTT ID Prolong Time（PTT-LT）——Menu No.20 This function is to set the display mode of channel B. This function is to set the prolong time of sending the radio’s PTT-ID.
  • Page 26 all-guides.com...
  • Page 27 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Auto Keypad Lock（AUTOLK）——Menu No.24 Frequency Deviation（OFFSET）——Menu No.26 When power on, but the radio is not in the working mode, the keypad will be automatically Using this function, you can set the deviation between receiving and transmitting frequency.
  • Page 28 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without First, storing channel 1： voice prompt.） a. In frequency mode, input number 4, 6, 5, 8, 7, 5. b. Press Menu+11, the LCD displays: R-CTCS Channel Delete（DEL-CH）——Menu No.28 R-CTCS c.
  • Page 29 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） RX Backlight（RX-LED）——Menu No.30 Alarm Mode （AL-MOD）——Menu No.32 You can choose the color of backlight when the radio is receiving. This function can set tone alarm/code alarm/site alarm of the radio.
  • Page 30 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Mute Mode Selection（SPMUTE）——Menu No.34 Tail Tone Elimination When Through Repeater（RP-SET）——Menu No.36 This function can be set up receiving decoding mode for radio. This function is that when the radio is through the repeater, the transmitter release PTT to enter receiving condition.Because of the delay of the repeater, it will receive the noise from repeater to The operation steps are as follows:...
  • Page 31 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Displays When Power On（PONMSG）——Menu No.38 Dual-watch Operation（TDR-AB）——Menu No.40 This function can set the display mode when power on. The function is to set A band or B band is transimit band when in dual-watch state.
  • Page 32 all-guides.com...

  • Page 33: Installing Antenna

    All manuals and user guides at all-guides.com CHARGING NOTES (2) INSTALLING ANTENNA Plug the AC adapter into the back of the charger. Then plug the power cable of the adapter into Attach the antenna to the radio as illustrated on the right. city electric power.

  • Page 34: Vfo-Menu Initialization

    All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） VFO-Menu initialization FM Radio（FM） 1. In frequency or channel mode, press Menu+40, the LCD displays: RESET You can listen to the radio frequency, the frequency range is from 65-108MHz.

  • Page 35: Jacklight

    All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Jacklight Reverse Function（ R ） When you set different frequencies, tapping“*”key can shift the transmitting and receiving This function is suitable for night lighting and warning light.

  • Page 36: Channel Scanning

    All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Channel Scanning Search CTCSS/DCS Code This function can scan the frequency activity from other radios. Using this function may search and store the CTCSS/DCS code from other radios when in same frequecy.

  • Page 37: Stun/Kill/Revive

    All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） Stun/Kill/Revive three same digits of ANI code of 3 sub-radio and two digits of troop call “100AA” and stun code “A8A8A” by keypad (Note: 100AAAB*88), finally the sub-radios can only receive without transmit.
  • Page 38 all-guides.com...
  • Page 39 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） 1. ANI code can be set by PC programming only, you can input user-defined code in “ ID CODE” frame after click b.
  • Page 40 All manuals and user guides at all-guides.com FUNCTION OPERATION AND DESCRIPTION（The following description is without FUNCTION OPERATION AND DESCRIPTION（The following description is without voice prompt.） voice prompt.） overtime warning” in DTMF side tone after clicking “option box” and “Edit” in PC program software. 4.
  • Page 41 All manuals and user guides at all-guides.com CTCSS D023N D115N D212N D306N D431N D546N 67.0 94.8 131.8 171.3 203.5 D025N D116N D223N D311N D432N D565N 69.3 97.4 136.5 173.8 206.5 D026N D122N D225N D315N D445N D606N 71.9 100.0 141.3 177.3 210.7 D031N D125N...

  • Page 42: Specificatons

    All manuals and user guides at all-guides.com SPECIFICATIONS D743N D114I D212I D311I D445I D612I GENERAL D754N D115I D223I D315I D446I D624I Frequency range VHF:136~174MHz，UHF:400~480MHz Rated voltage DC7.2V(Rechargeable Li-ion battery) D023I D116I D225I D325I D452I D627I Memory channel 128 channels D025I D122I D226I D331I...
