We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com

PRECAUTIONS

General safety instructions

Risk of personal injury
• ATTENTION: during use, the
appliance and its accessible
parts become very hot.
Children must be kept away
from the appliance.
• ATTENTION: during use, the
appliance and its accessible
parts become very hot. Never
touch the heating elements
during use.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
91477A558/C
35
35
38
39
39
39
39
39
39
40
40
40
40
40
41
41
41
41
42
42
42
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may be used by
children aged at least 8 and by
people of reduced physical,
sensory or mental capacity, or
lacking in experience in the use
of electrical appliances,
provided that they are
supervised or instructed by
adults who are responsible for
their safety.
• Children must not play with the
43
43
43
44
47
48
48
48
48
50
51
53
53
53
54
55
56
56
57
59
59
59
PRECAUTIONS - 35

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFP9302TX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg SFP9302TX

Summary of Contents for Smeg SFP9302TX

  • Page 1: Table Of Contents

    Electrical connection Preliminary operations We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions • Never try to put out a fire or...
  • Page 2 appliance. APPLIANCE WHILST IT IS IN • Keep children under the age of USE. 8 at a safe distance unless they • DO NOT MODIFY THIS are constantly supervised. APPLIANCE. • Keep children under the age of • Installation and servicing should 8 away from the appliance be carried out by qualified when it is in use.
  • Page 3 and towards the back of the paper, place it so that it will not oven cavity. interfere with the hot air circulation inside the oven cavity. • Do not use the open door to rest pans or trays on the internal glass pane.

  • Page 4: For This Appliance

    • The appliance must not be maintenance, positioning or installed on a pedestal. movement). • Position the appliance into the • Before performing any work on cabinet cut-out with the help of the appliance, switch off the a second person. power supply.

  • Page 5: Appliance Purpose

    • Do not install/use the Identification plate appliance outdoors. The identification plate bears the technical data, serial number and brand name of the • (on some models only) Only appliance. Do not remove the identification use the temperature probe plate for any reason. provided or recommended by Disposal This appliance conforms to the WEEE...

  • Page 6: Energy Efficiency Technical Data

    Information on power consumption in off/stand-by mode Technical data on the appliance's power consumption in off/stand-by mode can be found at www.smeg.com under the page corresponding to the product in question. Light sources • This appliance contains user-replaceable 40 - PRECAUTIONS...

  • Page 7: Description

    DESCRIPTION General description 1 Control panel 4 Door 2 Seal 5 Fan 3 Light bulb Frame shelf Control panel 1 Function knob • the cooking temperature; • the duration of a function; By means of these touch keys or this knob you can: •...

  • Page 8: Accessories

    Cooling fan supplied by the manufacturer. Rack Used for supporting containers with food during cooking. Tray The fan cools the appliance and comes into operation during cooking. The fan causes a steady outflow of air from above the door which may continue for a short period of time even after the appliance has been turned off.

  • Page 9: Using The Accessories

    Digital programmer 2. Heat the empty oven compartment at the maximum temperature to burn off any residues left by the manufacturing process. When heating the appliance • air the room; • don't stay. Using the accessories Racks and trays Racks and trays have to be inserted into the side guides until they come to a complete stop.

  • Page 10: Using The Oven

    4. Turn the temperature knob to adjust the flashing. hours. 2 Turn the temperature knob to the right or to the left to select the wished temperature (for 5. Press the button to set the hours and example "200°C"). move to the minutes. 6.
  • Page 11 4. Check the cooking status of the food by appears on the display. turning on the internal light. 7. Turn the function knob back to 0. End of cooking How to cancel timed cooking 5. To end cooking, turn the function knob to 1.
  • Page 12 4. Turn the temperature knob to set the cooking Minute minder timer during cooking end time (for example “13:15”). The minute minder timer does not stop the cooking operation but rather informs the user when the set time has run out. 1.

  • Page 13: Bottom Heat

    GRILL Cooking advice It allows to obtain excellent grilling and General advice grating results. Used at the end of • Use a fan assisted function to achieve cooking, it gives a uniform browning to consistent cooking at several levels. the dishes. •...

  • Page 14: Mini Guide To Accessories

    INSTRUCTIONS chapter. on cooking suggestions, we recommend visiting the dedicated page on the www.smeg.com Conventional heating mode website, which can be reached using the QR To use the STATIC mode, you have to skip the code on the leaflet supplied with the product.
  • Page 15 9. Below is a reference table with defrosting left by one position. The button flashes times by type of food. Type Weight (kg) Time To scroll through the available functions, Meats 1h 45m press the button until the desired Fish 0h 40m special function is selected.

  • Page 16: Secondary Functions

    SABBATH MINUTE MINDER TIMER This function results in the appliance The minute minder timer only warns the operating in a particular way: user that the set number of minutes has passed. • Cooking can proceed indefinitely, it is not possible to set any cooking duration. 1.

  • Page 17: Settings

    2. Turn the temperature knob to activate the 3. Press the button to confirm and modify controls lock function. the time. 4. Turn the temperature knob to adjust the hours. 5. Press the button to set the hours and move to the minutes. 6.
  • Page 18 1. After entering the setting menu, press the 1. After entering the setting menu, press the button until the show room function is button until the keep warm function is selected. selected. 2. Turn the temperature knob to activate the 2.

  • Page 19: Other Settings

    2. Turn the temperature knob to the right or left 2. Turn the temperature knob to disable the to select the desired brightness, from value 1 sound associated with the touching of the (low brightness) to value 5 (high brightness). symbols on the display.

  • Page 20: Cleaning The Door

    microfibre cloth. Cleaning the door glazing Do not allow residues of sugary foods (such as The glass in the door should always be kept jam) to set inside the oven. If left to set for too thoroughly clean. Use absorbent kitchen roll. In long, they might damage the enamel lining of case of stubborn dirt, wash with a damp sponge the oven.

  • Page 21: Cleaning The Oven Cavity

    glass 8. Be sure to fit the 4 pins of the inner glass well into their seats on the door. 5. Clean the external glass pane and the panes removed previously. Cleaning the oven cavity In order to keep your oven in the best possible condition, clean it regularly after letting it cool down.

  • Page 22: Special Cleaning Functions

    slide it out of the seats B at the back. Do not spray the deflector if it has a self- cleaning coating. • Close the door. • During the assisted cleaning cycle, wash the self-cleaning panels (where fitted), which were previously removed, separately in warm water and a small amount of detergent.

  • Page 23: Pyrolytic (On Some Models Only)

    Pyrolytic (on some models only) 4. Turn the function knob to position 0 to exit the function. See General safety instructions. Programmed Vapor Clean cycle It is possible to program the Vapor Clean function start time, like any cooking function. Pyrolytic cleaning is an automatic high- 5.
  • Page 24 (factory set to 2:30 hours). During the Pyrolytic cycle the fans produce a more intense level of noise due to a greater rotation speed. This is an absolutely normal operation, intended to provide more effective heat dispersal. At the end of the pyrolytic cycle, the fans will continue to operate for long enough to avoid overheating the walls of adjacent units and the front...

  • Page 25: Extraordinary Maintenance

    For easier manual cleaning of parts that Take care not to scratch the enamel of are difficult to reach, we recommend the oven cavity wall. removing the door. 4. Slide out and remove the light bulb. Extraordinary maintenance Seal maintenance tips The seal should be soft and elastic.
  • Page 26 leaking in. The aforementioned power cables are sized taking into account the coincidence factor (in compliance with standard EN 60335-2-6). Fixed connection Fit the power line with an all-pole circuit breaker with a contact separation distance sufficient to provide complete disconnection in category III overvoltage conditions, pursuant to installation regulations.
  • Page 27 Appliance overall dimensions (mm) Mounting into a column (mm) Make sure that the cabinet top/rear section has an opening approx. 35-40 mm deep. 91477A558/C INSTALLATION - 61...
  • Page 28 A min. 900 mm B 854 - 864 mm C 583 - 585 mm D 9 - 11 mm E min. 5 mm F 121 - 1105 mm G min. 560 mm H min. 594 mm co Cutout for power cord (min. 6 cm jb Electrical connection box 62 - INSTALLATION 91477A558/C...
  • Page 29 Mounting under worktops (mm) If the appliance is to be built-in under a worktop, a wooden bar has to be installed order to use the seal that is glued to the back of the front panel to prevent water or other liquids leaking in. A min.
  • Page 30 Built-in under hobs (mm) Whenever a hob is installed above the oven, a wooden separator has to be installed at a minimum distance of 20 mm from the top of the oven to prevent overheating when the two appliances are used at the same time. It must only be possible to remove the separator by using suitable tools.
