Item #1012 049 433
Model #SQHDK03-15PSL
Item #1012 049 434
Model #SQHDE03-5PSL
USE AND CARE GUIDE
PERMANENT MOUNT SMART COLOR
CHANGING STRING LIGHTS
Questions, problems, missing parts?
Before returning to the store, call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-592-5233
HOMEDEPOT.COM/HUBSPACE
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this Permanent
Mount String Light. We strive to continually create quality products designed to enhance your home. Visit us online to
see our full line of products available for your home improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY SQHDK03-15PSL
Summary of Contents for HAMPTON BAY SQHDK03-15PSL
- Page 1 HOMEDEPOT.COM/HUBSPACE THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this Permanent Mount String Light. We strive to continually create quality products designed to enhance your home. Visit us online to...
-
Page 3: Table Of Contents
Table of Contents Safety Information ............3 Installation ..............Warranty............... Operation ..............Pre-Installation ............5 Care and Cleaning ............14 Planning Installation ..........5 Troubleshooting ............14 Tools Required ............5 Package Contents ............ Safety Information IMPORTANT SAFETY INSTRUCTIONS □ This product has a polarized plug (one blade is wider than the other) as a feature to reduce the risk of electric shock. - Page 4 Safety Information CAUTION: □ To avoid risk of shock, always make sure the product is unplugged from the electrical outlet before assembling, disassembling, installing, relocating, servicing or cleaning it. □ Do not overload. This product contains 50FT of string lights, made of three 16.4-FT sections. 3 additional extensions of 16.4FT (sold separately) can be added to reach a total length of 100FT.
-
Page 5: Warranty
Warranty This item is warranted to be free from defects in materials or workmanship for a period of three (3) year from the original date of purchase under normal conditions of intended use. If this product is defective, the Warrantor will, within the warranty period, replace the product or refund the purchase price of the product, at the Warrantor’s option, at the place of purchase upon presentation of sales receipt or other proof of purchase. -
Page 6: Package Contents
Pre-Installation PACKAGE CONTENTS Model #SQHDK03-15PSL Model #SQHDE03-5PSL Part Description Quantity Part Description Quantity 16.4 FT LED String 16.4 FT LED string Lights - Total of 50 FT Screws and 30 Pucks Double sided tape Controller Power supply Adaptor 9.8 FT Extention Cable... -
Page 7: Installation
Installation Before installation, connect each LED string to the controller and plug them into power to make sure every string works properly. Clean the surface where you plan to install the string lights. It is recommended to vertically install 1-3 inches away from the wall surface. - Page 8 Installation Peel off the adhesive tape on the back and place the first bulb, before placing the next bulb make sure the wire is pulled flat to the roof. IMPORTANT: The adhesive tape is only used for TEMPORARY installation. Screws are needed to make the installation permanent. Press every bulb firmly against the surface for 20 seconds.
- Page 9 Installation Install the screws into the screw holes on every bulb. Install the screws into the screw holes of power supply and controller. HOMEDEPOT.COM/HUBSPACE Please contact 1-877-592-5233 for further assistance.
- Page 10 Installation The extension cable can be used if the strings need to be extended. Cable clips are recommended to fix the cable to the desired position. Cable clips are recommended to use to fix the cable onto proper position.
- Page 11 Installation Permanent outdoor light extension kits are used when you need more pucks. Max 60 pucks can be connected; 30 pucks per 50 ft strings provided. E 3 0 I 3 0 S A W M 2 4 6 8 V W - 1 3 0 0 V 2 2 A W G...
- Page 12 Installation Using the Wire Splicer CAUTION: Cutting and joining of the wires should only c. Slide the locking nut, be done by a qualified professional. silicone plug and shell over the wire in the correct order. Warning! Do not unscrew this end of the splicer d.
-
Page 13: Operation
Installation Permanent outdoor light extension kit is used when you need more LEDs. Max. 6 light strings can be connected. Operation Power ON/OFF Brightness - Brightness + Next Scene When party mode is turned ON, microphone will be enabled. NOTE: Turn on Party Mode via the Hubspace app. HOMEDEPOT.COM/HUBSPACE Please contact 1-877-592-5233 for further assistance. -
Page 14: Care And Cleaning
Care and Cleaning Dust and dirt can affect lighting effects, therefore regular cleaning is recommended. □ Clean the dust with a dry cloth. □ Do not wash or clean the product with strong chemical reagents or strong detergents. Specifications Output 36V DC 1A Power 2200K-6500K... - Page 16 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-592-5233 HOMEDEPOT.COM/HUBSPACE Retain this manual for future use. Document #: [Enter Document Number]...
