- Page 1 Combi steam oven [en] User manual and installation in- structions C29FY5CY0...
- Page 2 en Table of contents You can find additional information and explanations online. Scan the QR code on the title page. Table of contents Table of contents INFORMATION FOR USE Home Connect ........... 2 9 Cleaning and servicing ........ 3 0 Safety...
- Page 3 Safety en 1.4 Safe use Only touch hot telescopic shelves with oven gloves. Always place accessories in the cooking com- partment the right way round. WARNING ‒ Risk of scalding! "Accessories", Page 12 The accessible parts of the appliance become hot during operation. WARNING ‒ Risk of fire! Never touch these hot parts.
- Page 4 en Safety Do not heat spirits (≥ 15% vol.) when undi- impair the functionality of electronic implants, luted (e.g. for marinating or pouring over e.g. pacemakers or insulin pumps. food). Persons with electronic implants must stand Open the appliance door carefully. at least 10 cm away from the control panel and the magnetic controls.
- Page 5 Preventing material damage en 1.6 Meat probe 1.7 Cleaning function WARNING ‒ Risk of electric shock! WARNING ‒ Risk of burns! Using the wrong meat probe could damage The outside of the appliance gets very hot the insulation. when the cleaning function is in progress. Only use the meat probe for this specific ap- Never touch the appliance door.
- Page 6 en Environmental protection and saving energy If aluminium foil comes into contact with the door pane, If there is water on the cooking compartment floor when it could cause permanent discolouration. operating the appliance at temperatures above 120 °C, Do not allow aluminium foil in the cooking compart- this will damage the enamel.
- Page 7 Familiarising yourself with your appliance en is used. EN IEC 60350-1:2023 must be used to meas- ure low power mode. 4 Familiarising yourself with your appliance Familiarising yourself with your appliance 4.1 Control panel You can use the control panel to configure all functions of your appliance and to obtain information about the operat- ing status.
- Page 8 en Familiarising yourself with your appliance 4.2 Display WARNING ‒ Risk of injury! You can configure all the functions on your appliance via the display. The main menu provides an overview of your appli- Children and adults may be injured by the falling control ance's functions.
- Page 9 Familiarising yourself with your appliance en 4.5 Buttons The buttons are touch-sensitive areas. To select a function, press the corresponding button. Symbol Name On/Off Switch the appliance on or off Home Connect Display for Home Connect. The field has no further function. When the symbol lights up, the appliance is connected. Start/stop Start or pause the appliance Open control panel...
- Page 10 en Functions Opening for filling and emptying Handle for removing and inserting 5 Functions Functions The main menu provides an overview of your appliance's functions. Tip: Depending on the appliance type, additional or more comprehensive functions are available to you with the Home Connect app.
- Page 11 Functions en Symbol Heating function Temperature Bread baking setting 180 - 250 °C For baking bread, bread rolls and baked goods that require high temperatures. Full-surface grill 50 - 275 °C For grilling flat items such as steaks, sausages or bread, and for cooking au gratin. The entire area below the grill element becomes hot. Centre-area grill 50 - 275 °C For grilling small amounts of steaks, sausages or bread, and for...
- Page 12 en Accessories Symbol Name Reset Reset the values Change Change the selection Information Display information Rapid heating Activate or deactivate the rapid heating function Home Connect Home network and Home Connect server connected The number of lines shows the signal strength of the home network "Home Connect ", Page 29 Home network Home network not connected...
- Page 13 Accessories en Accessories Meat thermometer High-precision roasting or cooking. "Meat probe", Page 23 6.1 Information on accessories Some accessories are only suitable for certain functions. Steam container The steam containers are suitable for steam-only types of heating up to 120 °C. The steam containers are not suitable for higher temper- atures or other types of heating.
- Page 14 You will find a comprehensive range of products for your appliance in our online shop or from our customer your appliance in our brochures and online: service. www.neff-home.com 7 Before using for the first time Before using for the first time Implement the settings for the initial configuration. Calib- rate the appliance.
- Page 15 Before using for the first time en Make all other settings for initial start-up in the Or calibrate your appliance manually by letting the Home Connect app. steam function run for 30 minutes when the cooking compartment is empty. Setting the time "Steam", Page 17 Swipe left or right to select the hours.
- Page 16 en Basic operation Switch off the appliance after 1 hour. Once the appliance has cooled down, clean the smooth surfaces in the cooking compartment with a detergent solution and a dish cloth. 8 Basic operation Basic operation 8.1 Switching on the appliance Also available to select: Page 27 Rapid heating –...
- Page 17 Steam en 8.9 Keeping warm over an extended period Set the required operating mode. "Heating functions", Page 10 You can use your appliance to keep meals warm for up Set the required cooking time depending on the oper- to 24 hours without changing the behaviour of the appli- ating mode.
- Page 18 en Steam Put the cover back into the opening on the water Press "Steam". tank. Turn the control element Twist Pad Flex or swipe left Insert the full water tank . When doing so, make or right on the display to select steaming. sure that the water tank clicks into place behind the Press "Steam".
- Page 19 Steam en Empty the water tank and dry the cooking compart- Press to confirm the setting. ment. If does not appear, the setting is applied immedi- "After using steam operation", Page 21 ately. Press to start the defrosting process. Dough proving "Pausing operation", Page 16 If the water tank runs dry during the defrosting pro- Yeast dough proves considerably more quickly using cess, the operation is paused.
- Page 20 en Steam Changing added steam WARNING ‒ Risk of scalding! Hot water collects on the vacuum-sealing bag during Press cooking. Press "Added steam". Use an oven cloth to carefully lift the vacuuming Press the required steam intensity. bag so that the hot water runs off into the universal Press to confirm the setting.
- Page 21 Time-setting options en Press at the desired time. Remove the water tank. The steam jet is triggered and the appliance adds Carefully remove the lid of the water tank. clouds of steam to the cooking compartment for ap- Empty the water tank, clean it with detergent and then prox.
- Page 22 en Time-setting options 10.3 Delayed start/"Ready at" time Press Hours, Minutes or Seconds. Turn the control element Twist Pad Flex or swipe left With this function, the appliance automatically switches or right on the display to select the timer duration. itself on, and then switches itself off at the preselected Press to confirm the setting.
- Page 23 Meat probe en Note: If you want to continue the operation without a "Cancelling the cooking time", Page 22 cooking time, cancel the cooking time. 11 Meat probe Meat probe Cook with precision by inserting the meat probe into Thick Insert the meat probe diagonally into the the food and setting a core temperature on the appli- pieces of meat from above, pushing it in as far as...
- Page 24 en Dishes 11.3 Core temperatures of different foods 11.4 Setting the oven temperature and core temperature This is where you can find the suggested core temperat- ures for different foods. You can set a core temperature of between 30 °C and These suggestions depend on the quality and the size/ 99 °C.
- Page 25 Dishes en 12.3 Overview of the dishes ceramic cookware is best. The joint should cover ap- prox. 2/3 of the cookware base. You can see which individual dishes are available to you Cookware made from the following material is not suit- on the appliance. The dishes depend on the features of able: your appliance.
- Page 26 en Favourites ance has already been in operation are shown on the Category Food display. If the appliance is connected to Home Con- Fish. nect, the forecast time remaining is displayed. Vegetables "Remaining time forecast for the operation", Fruit, Dessert Page 25 Preserving, Preserving food Once the dish is ready, a signal sounds.
- Page 27 Childproof lock en Press Press and hold the required favourite and drag it to a different position. 14 Childproof lock Childproof lock Note: When you activate the childproof lock, the appli- You can secure your appliance to prevent children from accidentally switching it on or changing the settings. ance will immediately disable the control panel.
- Page 28 en Basic settings Tone Selection Personalisa- Selection tion Button tone 1 Regional 1 dishes European dishes Volume British dishes Dishes 1 No pork Kosher only 1 Signal tone Very short duration Childproof lock Available 1 Short duration Deactivated Medium duration 1 Automatic 1 Long duration...
- Page 29 Home Connect en 17 Home Connect Home Connect 17.1 Setting up Home Connect This appliance is network-capable. Connecting your ap- pliance to a mobile device lets you control its functions Requirements via the Home Connect app, adjust its basic settings and The appliance is connected to the power supply and monitor its operating status.
- Page 30 en Cleaning and servicing 17.3 Operating the appliance with the start the software update via the app. Once the update has been successfully downloaded, you can start in- Home Connect app stalling it via the Home Connect app if you are in your You can use the Home Connect app to set and start the home network (Wi-Fi).
- Page 31 Cleaning and servicing en Using oven cleaner in a hot cooking compartment dam- WARNING ‒ Risk of electric shock! ages the enamel. An ingress of moisture can cause an electric shock. Never use oven cleaner in the cooking compartment Do not use steam- or high-pressure cleaners to clean when it is still warm.
- Page 32 en Cleaning and servicing Range Suitable cleaning agents Information Notes Enamel burns at very high temperatures, causing minor discoloura- tion. The functionality of your appliance is not affected by this. The edges of thin trays cannot be completely enamelled and may be rough.
- Page 33 Eco Clean cleaning function en Never put the control in your pockets. Clean all of the parts with a cloth moistened with soapy water. WARNING ‒ Risk of injury! Dry all of the parts with a soft cloth. Before assembling, leave all of the parts to dry com- pletely.
- Page 34 en Easy Clean cleaning aid Requirements functions. The more often you use the cleaning function, "Preparing the appliance for the cleaning function", the longer the cleaning ability of the self-cleaning sur- Page 34 faces is retained. Do not open the appliance door while the appliance is in operation.
- Page 35 Descaling en 20.2 Wiping down the cooking compartment Mix 0.4 litres water with a drop of washing-up liquid and pour into the centre of the cooking compartment ATTENTION floor. The prolonged presence of moisture in the cooking Press "Cleaning". compartment leads to corrosion. Press "Easy Clean".
- Page 36 en Drying Slide in the water tank and close the control panel. Thoroughly rinse the water tank and fill it with fresh The rinse cycle starts. The duration counts down on water. the display. Slide in the water tank and close the control panel. Once the rinse cycle has run through to the end, an The rinse cycle starts.
- Page 37 Rails en Press and hold PUSH For both rails, ensure that the curved rods are at the and swing the rail outwards front. until the front retainer is detached. First, push the rail into the middle of the rear socket until the rail rests against the cooking compartment wall, and then push this back Push the rail into the front socket until the rail also...
- Page 38 en Appliance door Press and hold PUSH Guide the pull-out rail with the rear retainer from be- and swing the pull-out rail in- low behind the two guide rods for the required shelf wards until the retainer is attached in the lower position and keep it horizontal.
- Page 39 Appliance door en Use both hands to pull the condensate tray The hinge is now secured wards and out at an angle and cannot snap shut. Locking levers closed The appliance door is se- cured and cannot be de- tached. The locking levers are open. The hinges are now se- cured and cannot snap shut.
- Page 40 en Appliance door Slide the appliance door straight onto the two Remove the door cover . hinges . Slide the appliance door on as far as it will Open the appliance door fully. Close the locking levers on the left- and right-hand hinges ...
- Page 41 Appliance door en Push the intermediate pane upwards until it is in the WARNING ‒ Risk of injury! left- and right-hand retainers . Scratched glass in the appliance door may develop into a crack. Do not use any harsh or abrasive cleaners or sharp metal scrapers to clean the glass on the oven door, as they may scratch the surface.
- Page 42 en Troubleshooting Put the door cover into position and push down on Close the appliance door. it until you hear it click into place. Note: Do not use the cooking compartment again until Open the appliance door fully. the door panes have been correctly fitted. Close the locking levers on the left- and right-hand hinges ...
- Page 43 Troubleshooting en Fault Cause and troubleshooting The operation does not start or is Malfunction interrupted. Call . "Customer Service", Page 45 Appliance does not heat up. Demo mode is switched on. Disconnect the appliance from the power supply for at least 30 seconds by switching off the fuse.
- Page 44 Next time, set lower or higher values. Tip: A lot of other information about the preparation, corresponding adjustment values and recipes can be found in the Home Connect app or on our website www.neff-home.com . 26 Disposal Disposal 26.1 Disposing of old appliance...
- Page 45 BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect functionality conforms to the essen- tial requirements and other relevant provisions of Directive 2014/53/EU. A detailed RED Declaration of Conformity can be found online at www.neff-home.com among the additional docu- ments on the product page for your appliance.
- Page 46 The manufacturer, BSH Hausgeräte GmbH deems that it Products) Regulations 2023 can be found online at has complied with www.neff-home.com/uk/ among the additional docu- provision 5.1-1 of ETSI EN 303 645 v2.1.1 and, ments on the product page for your device.
- Page 47 How it works en 30.4 Cooking tips for steaming Roast pieces of a similar weight and thickness. The grilled food will brown evenly and will remain succu- Cook your food gently. The food remains particularly lent and juicy. succulent. Place the food to be roasted directly on the wire rack. In contrast to cooking with added steam, the meat does To catch any liquids that drip down, place the univer- not become crispy on the outside.
- Page 48 en How it works Recommended settings for various types of food Food Accessory/cook- Height Type of Temperature in Steam Cooking time ware heating °C level in mins Sponge cake, delicate Ring-shaped tin 150-170 60-80 Loaf tin Fruit tart or cheesecake Springform cake 170-180 60-80 with shortcrust pastry...
- Page 49 How it works en Food Accessory/cook- Height Type of Temperature in Steam Cooking time ware heating °C level in mins Chicken, 1.3 kg, un- Wire rack 200-220 Medium 50-60 stuffed Chicken breast fillet, Perforated steam- 15-25 steaming ing tray Small chicken portions, Wire rack 200-220 Medium...
- Page 50 en How it works Desserts Making yoghurt Remove the accessories and shelves from the cook- Making crème caramel or crème brûlée ing compartment. Use your preferred recipe to make the mixture for the Heat 1 litre of whole milk (3.5% fat) to 90 °C on the crème.
- Page 51 How it works en 30.7 Special cooking methods and other Immediately place the meat into the pre-warmed cookware in the cooking compartment. applications To ensure that the temperature in the cooking com- Information and recommended settings for special partment remains constant, keep the cooking com- cooking methods and other applications, e.g.
- Page 52 en How it works that can create a 99% vacuum when vacuum-sealing Once the food is cooked, consume it immediately. Do food. not store it after cooking – not even in the refriger- ator. It is not suitable for reheating. Tip: To prevent gases escaping from the food, e.g. from vegetables, vacuum-seal the food no more than one day To kill the germs, dip the vacuum-sealing bag con- before you cook it.
- Page 53 How it works en Food Cooking tips Food Cooking tips Sear the meat at a very high temper- Fry the food for longer if has not – – ature for a few seconds on each been sufficiently well cooked during side. This gives the meat a nice crust the sous-vide cooking stage.
- Page 54 en How it works Food Accessory/ Type of Temper- Steam level Cooking time Tips for sous-vide cookware heating ature in in mins cooking °C Vanilla sauce, 0.5 l Wire rack 15-25 Recipe tip: Mix 0.5 l milk, 1 egg, 3 egg Universal pan yolks, 80 g sugar and the pulp of a vanilla pod, and vacuum- seal.
- Page 55 How it works en Recommended settings for heating and reheating Food Accessory/cook- Height Type of Temperature in Steam Cooking time ware heating °C level in mins Plated meal, chilled, Uncovered cook- 120-130 15-25 1 portion ware Pizza, cooked, chilled Wire rack 170-180 5-15 1 Bread rolls, baguette,...
- Page 56 en Installation instructions Steaming Perforated steaming tray, size XL: Shelf position 2 Shelf positions when steaming on two levels: Slide the universal pan into the cooking compartment Use a maximum of 1.8 kg per level. below the perforated steaming tray (size XL) if instructed Perforated steaming tray, size XL: Shelf position 3 to do so in the recommended settings table.
- Page 57 Installation instructions en 31.2 General installation instructions ¡ Dimensions of the figures in mm. WARNING ‒ Risk of electric shock! Follow these instructions before you start in- Once the appliance has been installed, the stalling the appliance. openings in the back panel of the appliance ¡...
- Page 58 en Installation instructions 31.3 Appliance dimensions 31.4 Installation below a worktop You will find the dimensions of the appliance here Observe the installation dimensions and the installation instructions when installing below a worktop. To ventilate the appliance, the intermediate floor must have a ventilation cut-out. The worktop must be secured to the fitted unit.
- Page 59 Installation instructions en 31.6 Installation in a tall unit Only fit appliances up to a height that allows ac- cessories to be easily removed. Observe the installation dimensions and the installation instructions when installing in a tall unit. 31.8 Corner installation Observe the installation dimensions and the installation instructions when installing in a corner.
- Page 60 en Installation instructions If the display on the appliance remains dark, it has Remove the two transport locks. not been connected correctly. Disconnect the appli- Press on the sloped surface on the rear of the ance from the mains and check the connection. transport lock Press and hold the sloped surface and pull the Electrically connect the appliance with the...
- Page 61 Installation instructions en Centre the appliance. Check whether the left- and right-hand panels are ver- tically aligned. Page 62 If necessary, align the panels. Note: The gap between the worktop and the appliance must not be closed by additional battens. Thermal insulation strips must not be fitted to the side panels of the surround unit.
- Page 62 en Installation instructions Push the eccentric backwards from the fastening ele- Turn the fastening element to the left or right to adjust ment the alignment of the panels. The eccentric breaks off. Push the eccentric backwards into the fastening ele- ment Refit the panels.
- Page 64 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom *9001841133* Register your product online neff-home.com BSH Hausgeräte GmbH (050408) REG25 9001841133 Carl-Wery-Straße 34 81739 München, GERMANY...
