USER MANUAL
240v 11,500Btu
Air Conditioner V2
Product Code:
SP11500ACV2
Serial Number Range:
From:
To:
Year Of Manufacture:
*Please note, when ordering online via our website if the part number is not recognised,
please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988
KEEP THIS BOOKLET FOR FUTURE REFERENCE
Nottingham: 0115 946 1988 • London: 0208 830 3333
The Hire Supply Company Terms & Conditions Apply At All Time E&OE
Nottingham: sales@hscgroupuk.co.uk • London: sean@hscgroupuk.co.uk
www.hscgroupuk.co.uk
Advertisement
Table of Contents
Related Manuals for HSC Elite SP11500ACV2
Summary of Contents for HSC Elite SP11500ACV2
- Page 1 USER MANUAL 240v 11,500Btu Air Conditioner V2 Product Code: SP11500ACV2 Serial Number Range: From: Year Of Manufacture: *Please note, when ordering online via our website if the part number is not recognised, please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988 KEEP THIS BOOKLET FOR FUTURE REFERENCE Nottingham: 0115 946 1988 •...
-
Page 2: Important Safety Instructions
CONDITIONER SP11500AC USER MANUAL CONTROLLED DOCUMENT NO: 00100UIRS0321V2 IMPORTANT SAFETY INSTRUCTIONS Before using this SP11500AC please read this user manual, if you do not understand any of the instructions within please do not use and consult your retailer or the manufacturer for clarification. - Page 3 Operating Instructions. Thank you for purchasing an Simply Spares product, manufactured to a high standard, this product will, if used in accordance with these operating instructions, labels affixed to the product and properly maintained, provide you with many years of reliable services.
- Page 4 BEFORE USE - GENERAL SAFETY • FOR INDOOR USE ONLY. • LEAVE THE UNIT TO STAND FOR 12HRS BEFORE CONNECTING TO THE POWER SUPPLY AFTER TRANSPORTATION OR AFTER MOVING. • ONLY USE THE APPLIANCE IN THE UPRIGHT POSITION AND ON A FLAT LEVEL SURFACE (Fig. I ) •...
- Page 5 TO ENSURE MAXIMUM EFFICIENCY • CLOSE DOORS AND WINDOWS • KEEP FILTERS CLEAN • DO NOT EXCEED THE RECOMMENDED ROOM SIZE FOR MAXIMUM EFFICIENCY. • KEEP CURTAINS AND BLINDS CLOSED DURING THE SUNNIEST HOURS OF THE DAY. • ONCE ROOM HAS REACHED THE DESIRED CONDITIONS, REDUCE TEMPERATURE AND VENTILATION SETTING SERVICE AND MAINTENANCE •...
-
Page 6: Air Conditioner
AIR CONDITIONER DIAGRAMS FOR CORRECT INSTALLATION AND USE... -
Page 8: Technical Data
TECHNICAL DATA MODEL SP11500AC Power/Ampere consumption for cooling 1300W 5.8A Air volume (max. speed) 410m3/h Humidity removal capacity 1.4Uhour Power supply 220·240V-. 50Hz Compressor Rotary Refrigerant R290 Fan speed Timer 1 - 24 hours Working temperature Cooling: 18 -32°C Exhaust pipe Ø142 x 1500mm Net Weight 28.5kgs... -
Page 9: Operation
Accessories (Fig, 7) PARTS Front (Fig. 5) 13. Exhaust hose. 1. Control Panel 14. Adaptor - for insertion over hose and into window spacer 2. Air vent (or into hole in the wall/window). 3. Handle 15. Cover for adaptor 4. Castor 16. -
Page 10: Self-Diagnosis
TURNING ON/OFF 1. Open the door for the water tank • Press ON/OFF button, the unit will work in cool mode with low fan speed, the pre-setting temperature is 24 2. Take out the water tank • Indicators of the functions in progress come on at the same time. - Page 11 MAINTENANCE To prolong the compressor's life, after switch-off of the unit, please wait for 3 minutes (at least) before re-switch. Always unplug the air conditioner from the mains before The cooling system will switch off if the ambient temperature cleaning. To maximize the efficiency of the air conditioner is lower than the set one.
- Page 12 This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal. Recycle it responsibly to promote the sustainable reuse of material resources. To return your used device. Please use the return and collection systems or contact the retailer where the product was purchased.
- Page 13 Recycling ENVIRONMENTAL PROTECTION: Please recycle any unwanted materials as opposed to disposing them as general waste. It is recommended the original is retained and used to store the product when not in use for prolonged periods of time. If this is not applicable ensure the materials are sorted and recycled in accordance with local regulations.
