Acumen XR10 PRO General Installation Manual

Acumen Mirror General Installation Guide
Acumen Mirror
IP67 Waterproof Camera
Recommended to install near the licence plate
ACC+ (Yellow) Line
BATT+ (Red) Line Positive+
GND (Black) Line Negative-
Reversing Line
(Red one on camera cable)
Terminal Blocks Harness
on Acumen Box
(For Legend)
Hardwire Kit
32ft
Camera
Cable
GPS GPS Antenna
(Optional)
12V (+)
Reverse Light
(For Backup Assistant)
Where to connect
Car Cigarette Lighter
Automotive Display
Car Key Hole
Fuse Box
x
Fuse Box
Base floor
Below the A-Pillar
(Driver side)
Any other grounding
x
spot
Reverse Light wires
Ground
(Black)
ACC
(Yellow)
Note: Please connect to Car Cigarette
Lighter, Automotive Display, Car Key
Hole. Do
*We definitely recommend
connection method.
DO'S
We definitely recommend Relay
for all connection method.
For all models of Chrysler , such
as Dodge , the ACC+ (yellow) line
must be connected to the car
cigarette lighter, Otherwise, screen
flickering or automatic shutdown will
occur. Also, all models of Chrysler
does not support Time-lapse recording.
The BATT+ Line should be connected
to the fuse box, we recommend choosing
10A ~ 15A
a fuse with a current between
15A
constant power is recommended to
Cars or SUVs
be connected for .
10A
constant power can only be connected
for vehicles
3.6 liters
with a displacement of more than
connected firmly
Be sure the GND to be
and not loose.
The voltage of the reversing line of
German cars
such as Audi, BMW, and
6 Volts RELAY
Volkswagen is only , so a
must be added when connect to the
reversing line.
40A
devices can only be used after the
Green( or purple)
two wires are bridged.
BATT+
(Red)
Note: Please connect
to fuse that is less than
15 amps.
NOT connect to the Fuse box.
Relay
for all
DON'TS
Do NOT connect the ACC+ line to
the Fuse box which may have chance
to cause damage to other device.
.
.
Do NOT
connect the GND to
improper grounding spot which may
cause rear camera screen black/green.
XR10 PRO
