- Page 1 Installation Guide...
- Page 2 Please read this installation guide carefully to ensure your LapStacker is installed and used correctly and safely. Contents Page ......................2 Warnings ..................4 LapStacker Installation ® .....................9 Further Information By using your LapStacker you agree to the terms of our Warranty and Product Disclaimer which can be read online at https://adaptdefy.com/pages/lapstacker-warranty-disclaimer...
-
Page 3: Warnings - Please Read Carefully
Warnings - Please read carefully Warnings - General ● LapStacker is not a seatbelt, safety device, or medical device. ● LapStacker is designed as an aid only. ● Do not use your LapStacker to secure people or animals. ● Carefully place and monitor items as they can still move, even when secured. ●... - Page 4 Warnings - Please read carefully Warnings - Installation ● If moving existing wheelchair components (e.g. armrests, leg restraints), ensure they are reinstalled securely to avoid failure and injury. ● The LapStacker Retractor is not designed for submersion. Water damage may void the Warranty.
- Page 5 XD - Installation LapStacker Assembly WEBBING CENTRE OF RETRACTOR BRACKET WEBBING BUCKLE HOLDER SEAT RAIL IDEAL LAPSTACKER POSITION RETRACTOR Ideally, your LapStacker is positioned centrally in relation to where items will be carried.
- Page 6 Choose Mounting Hardware ● Check the table to confirm the correct Brand Screw screw and nut sizes for your wheelchair brand. Amylior M6 x 16 16 x 16 x 4 ● LapStacker XD comes pre-installed with iBOT M6 x 16 16 x 16 x 4 the M6 x 12 screws and 14 x 10 x 5 nuts.
- Page 7 Slide onto the Seating Rail (T-slot). Remove the end cap or any accessories that may block access to the rail. Slide the nuts into the T-slot of the seating rail.
- Page 8 Adjust position and tighten screws. WARNING! Do not overtighten screws -— this may cause damage. Slide the Retractor to your preferred position, then fully tighten the screws. Items Required: ● LapStacker Assembly ● 4.0mm Allen Key (largest key supplied)
- Page 9 Attach Buckle Holder. WARNING! Do not overtighten the screws — Attach the Buckle Holder this may cause damage. to the Bracket using 2 x M3 fasteners. Refit the end cap and re- Items Required: place any accessories that were removed. ●...
-
Page 10: Further Information
Further Information Scan for installation and troubleshooting tips. adaptdefy.com info@adaptdefy.com @adaptdefy @adaptdefy @adaptdefy @adaptdefy...
