ADAPTDEFY LapStacker FLEX Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Made with love by
Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the LapStacker FLEX and is the answer not in the manual?

Questions and answers

Related Manuals for ADAPTDEFY LapStacker FLEX

Summary of Contents for ADAPTDEFY LapStacker FLEX

  • Page 1 Made with love by Installation Guide...

  • Page 2: Table Of Contents

    ......................6 Install Orientation ......................7 Check Clearance ......................9 Buckle Holder Selection ....................11 LapStacker Horizontal Installation ................14 LapStacker Vertical Installation ..................24 By using your LapStacker you agree to the terms of our Warranty and Product Disclaimer which can be read online https://adaptdefy.com/pages/lapstacker-warranty-disclaimer...

  • Page 3: Warnings

    Warnings - Please read carefully Warnings - General ● LapStacker is not a seatbelt, safety device, or medical device. ● LapStacker is designed as an aid only. ● Do not use your LapStacker to secure people or animals. ● Carefully place and monitor items as they can still move, even with your LapStacker securing them.
  • Page 4 Warnings - Please read carefully ● Avoid contact with your newly installed LapStacker while transferring in and out of the wheelchair. Failure to do so may result in injury or damage. ● Do not use your LapStacker for extensive periods of time. This may result in loss of circulation or pressure injury.

  • Page 5: Components

    COMPONENTS TOP TENSION STRAP WEBBING FLUSH BUCKLE HOLDER FLEX STRAP RETRACTOR MAGNETIC (LEFT SIDE) BUCKLE RETRACTOR (RIGHT SIDE) BASE TENSION STRAP IMPORTANT: LapStacker Flex uses Left and Right Retractors. Please ensure the LapStacker logo faces fowards when installed.
  • Page 6 COMPONENTS (Continued) TOP BUCKLE HOLDER FOAM WEDGE ALCOHOL WIPE VELCRO PAIRS (SHORT) VELCRO PAIRS (LONG)

  • Page 7: Optimal Location

    1. FIND OPTIMAL LOCATION CENTRE OF WEBBING ● LapStacker is best installed inline with the centre of where you will carry items, but will still work if forward or back of this. IDEAL LAPSTACKER ● Locate this central point on your POSITION wheelchairs top tube.

  • Page 8: Install Orientation

    2. SELECT INSTALL ORIENTATION RIGID CHAIRS Single tube frames Dual, non parallel tube frames HORIZONTAL INSTALL HORIZONTAL INSTALL...
  • Page 9 STEP 2. SELECT INSTALL ORIENTATION FOLDING CHAIRS Single tube frames Parallel dual tube frames HORIZONTAL INSTALL VERTICAL INSTALL...

  • Page 10: Check Clearance

    STEP 3. CHECK CLEARANCE - HORIZONTAL HOW IT WORKS TEST FIT: The horizontal install works by fastening Check that your wheelchair components will not LapStacker across the chair frame. If clash with LapStacker. It is possible to adjust you have a raising seat base, the top some wheelchair components if clearance is an tension strap must pass under this.
  • Page 11 STEP 3. CHECK CLEARANCE - VERTICAL HOW IT WORKS TEST FIT: The vertical install works by fastening Check that your wheelchair components will not each half of LapStacker around the top clash with LapStacker. It is possible to adjust and lower frame tubes. some wheelchair components if clearance is an issue.

  • Page 12: Buckle Holder Selection

    STEP 4. SELECT BUCKLE HOLDER - FLUSH FLUSH BUCKLE HOLDER The Flush Buckle Holder comes installed as standard with your LapStcacker and will suit 80% of installs. If clearance is an issue, you may consider using the Top Buckle Holder.
  • Page 13 STEP 4. SELECT BUCKLE HOLDER - TOP TOP BUCKLE HOLDER The Top Buckle Holder sits above the frame top tube and has three adjustment positions to shift the keeper left to right. The adjustment can be used to create clearance from your wheel guards, brakes, seat frame or cushion etc.
  • Page 14 INSTALL TOP BUCKLE HOLDER (OPTIONAL) 1. REMOVE FLUSH 2. INSTALL TOP BUCKLE BUCKLE HOLDER HOLDER Unlock the Flush Buckle With both locking tabs open, place Holder by pulling both locking the Top Buckle Holder onto the Flex tabs out. Strap in the desired position. Lock in place by pressing in both locking tabs.

  • Page 15: Lapstacker Horizontal Installation

    HORIZONTAL INSTALLATION The wheelchairs depicted are for illustration purposes only. These instructions will work for whatever chair type you own.
  • Page 16 HORIZONTAL INSTALLATION FIXED SEAT BASE RAISING SEAT BASE If you have a raising seat base, the LapStacker must pass under the seat base. Adapt install steps to suit.
  • Page 17 Clean the frame and seat base where LapStacker will be located using the alcohol wipes provided. IMPORTANT Any dirt, grease or oils will prevent the adhesive from properly adhering. Please clean well for best results.
  • Page 18 Adhere velcro to the frame and seat base where the Flex Straps will make contact. Repeat on each side. IMPORTANT REPEAT PROCESS FOR If you have existing velcro on your seat OPPOSITE SIDE. base, match the hook and loop to suit.
  • Page 19 Adhere velcro to both LapStacker Flex Straps. Flex Strap Evenly distribute the velcro across the horizontal and vertical surfaces of the Flex Strap. Ensure the velcro is pressed firmly into the internal corner. IMPORTANT You must match the velcro to suit the hook or loop already applied to the wheelchair.
  • Page 20 If the frame is not parallel at the optimal position, use the foam wedges to correct the angle of the Buckle Holders. Apply the short velcro to both sides of the foam wedge. Adhere the foam wedge to the inside of the Flex Strap between the LapStacker and the frame.
  • Page 21 Attach LapStacker assembly to the frame. RAISING SEAT FRAME Ensure the Flex Straps pass under the seat base.
  • Page 22 Clip the Base Tension Strap together and tighten gently. Contain excess webbing using the rubber loops.
  • Page 23 Clip the Top Tension Strap together and tighten gently. Contain excess webbing using the rubber loops.
  • Page 24 Pass the webbing through the Buckle Holder. Repeat for each side. Slide retainer into the closed position.

  • Page 25: Lapstacker Vertical Installation

    VERTICAL INSTALLATION The wheelchair depicted is for illustration purposes only. These instructions will work for whatever chair type you own.
  • Page 26 Using the alcohol wipes clean the frame where LapStacker will be located. IMPORTANT Any dirt, grease or oils will prevent the adhesive from properly adhering. Please clean well for best results.
  • Page 27 Adhere velcro to the frame on both sides where the Flex Straps will make contact.
  • Page 28 Adhere velcro to both LapStacker Flex Straps. Flex Strap Evenly distribute the velcro across the horizontal and vertical surfaces of the Flex Strap. Ensure the velcro is pressed firmly into the internal corner. IMPORTANT You must match the velcro to suit the hook or loop already applied to the wheelchair.
  • Page 29 Attach LapStacker assembly to the frame.
  • Page 30 Pass Tension Strap around the lower tube, join buckles and tighten. Contain excess webbing using the rubber loops.
  • Page 31 Pass the webbing through the Buckle Holder. Repeat for each side. Slide retainer into the closed position.
  • Page 32 Further Information Scan for installation and troubleshooting tips. adaptdefy.com info@adaptdefy.com @adaptdefy @adaptdefy @adaptdefy @adaptdefy...
