Shining 3D Aoralscan Elite Instructions For Use Manual page 45

interface and make comparison. Click on the compared models to check the results.
7.11. Pre-Design
7.11.1. Texture and Smooth
Texture: Click
Open
Smooth: Click
Open
7.11.2. Occlusion Test
Click under the "Pre-design" process to enter the occlusion detection interface.
The green color indicates there is a distance between the two jaws.
The red color indicates the touching area between the two jaws.
The blue color indicates the bite-through area between the two jaws.
Double-click on the point of the model to detect the occlusal gap at that point.
to view the texture of the model.
to clean the noise and improve the quality of the model.
Close
Close
