IMPORTANT SAFEGUARDS
1. This product is for use with an emergency LED lighting load and supplies 10.0 W of constant output power for 90
minutes and reduces output power thereafter for 120 minutes to LED lamps rated from 20-56 Vdc.
2. Make sure all connections are in accordance with the NEC and any local regulations.
3. To reduce the risk of electric shock, disconnect both normal and emergency power supplies and
converter connector from the emergency driver before servicing.
4. This emergency driver is suitable for factory or field installation.
5. Do not use outdoors. This product is suitable for use in damp locations where the ambient temperature is 0°C
minimum, +55°C maximum. See operating temperature for details. Product is not suitable for heated air outlets and
wet or hazardous locations.
6. An unswitched AC power source is required (120/277 VAC, 50/60 Hz).
7. Do not install near gas or electric heaters.
8. Do not attempt to service the battery. A sealed, no-maintenance battery is used that is not field replaceable.
Contact Dual-Lite for information on service.
9. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
10. Do not use this product for other than intended use.
11. Servicing should be performed by qualified service personnel.
12. Equipment should be mounted in locations and at heights where it will not be subjected to tampering by
unauthorized personnel.
WARNING - This product contains chemicals known to the State of California to cause cancer, birth defects, and/or other
reproductive harm. Thoroughly wash hands after installing, cleaning, or otherwise touching this product.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
INSTALLER:
SEE UNIT LABEL FOR ADDITIONAL MODEL SPECIFICATIONS
SAVE THESE INSTRUCTIONS FOR USE BY OWNER/OCCUPANT
CAUTION: DISCONNECT POWER DURING INSTALLATION AND BEFORE SERVICING.
READ ALL INSTRUCTIONS COMPLETELY BEFORE STARTING INSTALLATION.
ILL: 93318494
CLASS 2 OUTPUT
When using electrical equipment, basic safety precautions should
always be followed including the following.
READ AND FOLLOW
ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
user will be required to correct the interference at his own expense.
currentlighting.com/dual-lite
© 2025 HLI Solutions, Inc. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
PLD10M+
Emergency LED Battery Pack Installation,
Operation, and Service Instructions
PLD10M Plus LED Battery Pack Instruction Sheet_R01
Page 1 of 5
Rev 02/27/25
Advertisement
Related Manuals for Current DUAL LITE PLD10M+
Summary of Contents for Current DUAL LITE PLD10M+
- Page 1 PLD10M+ Emergency LED Battery Pack Installation, Operation, and Service Instructions ILL: 93318494 CLASS 2 OUTPUT IMPORTANT SAFEGUARDS When using electrical equipment, basic safety precautions should always be followed including the following. READ AND FOLLOW ALL SAFETY INSTRUCTIONS 1. This product is for use with an emergency LED lighting load and supplies 10.0 W of constant output power for 90 minutes and reduces output power thereafter for 120 minutes to LED lamps rated from 20-56 Vdc.
-
Page 2: Installation
LED array when operating from the AC driver. 3. Ensure the output current of the LED driver does not exceed 1.2 Amps. This is the current into the blue wire. 4. Ensure the LED fixture’s rated efficacy is equal to or greater than 65 lm / watt. This is to ensure that the LED fixture can be mounted at or below the maximum rated mounting height of 43.29ft (12.78m) for 90-minute runtime (0°C to 55°C) or 35.23ft (10.74m) for 120-minute runtime (5°C to 55°C). - Page 3 LARGE BUSHING MOUNT PLD10M+ UNIT ON TOP OF LED SW INDICATOR PLASTIC FIXTURE TUBE TY-WRAP 93084710 SHING "STATUS" M DRIVER LABEL 93071446 SMALL BUSHING ILLUSTRATION 3 SWITCH UL SWITCH INDICATOR COVER "CAUTION" Mounting Height: This product meets or exceeds the NFPA minimum light requirements with all loads, down to the LABEL smallest rated lamp load, at heights up to 43.29ft (12.78m) for 90-minute runtime (0°C to 55°C) or 35.23ft (10.74m) for 120-minute runtime (5°C to 55°C).
-
Page 4: Operation
OPERATION During normal operation AC power is applied, the charging indicator light is illuminated. (red for non-Spectron® and green for Spectron® models), indicating that the battery is being charged. When power fails, the charging indicator turns off, and the emergency LED driver automatically switches to emergency power (internal battery), operating the LED load for a minimum of 90 minutes or 120 minutes (see operating temperature for details). -
Page 5: Maintenance
MAINTENANCE Although no routine maintenance is required to keep the emergency driver functional, it should be checked periodically to ensure that it is working. If a unit is to be deliberately taken out of service for an extended period, the battery should be disconnected in order to preserve its life.
