Current DualLite PLD10+ Installation, Operation And Service Instructions

B
A A A
IMPORTANT SAFEGUARDS
NOTES: UNLESS OTHERWISE SPECIFIED
1. DEBURR AND BREAK SHARP CORNERS.
4
READ AND FOLLOW ALL SAFETY
1. This product is for use with an emergency LED lighting load and supplies 10.0 W of constant output power for 90
minutes and reduces output power thereafter for 120 minutes to LED lamps rated from 20-56 Vdc.
2. Make sure all connections are in accordance with the NEC and any local regulations.
3. To reduce the risk of electric shock, disconnect both normal and emergency power supplies and converter
connector from the emergency driver before servicing.
4. This emergency driver is suitable for factory or field installation inside of a suitable lighting fixture.
5. Do not use outdoors. This product is suitable for use in damp locations where the ambient temperature is 0°C
minimum, +55°C maximum. See operating temperature for details. Product is not suitable for heated air outlets and
wet or hazardous locations.
6. An unswitched AC power source is required (120/277 VAC, 50/60 Hz).
7. Do not install near gas or electric heaters.
8. Do not attempt to service the battery. A sealed, no-maintenance battery is used that is not field replaceable.
Contact Dual-Lite for information on service.
9. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
10. Do not use this product for other than intended use.
11. Servicing should be performed by a qualified service personnel.
12. Equipment should be mounted in locations and at heights where it will not be subjected to tampering by
unauthorized personnel.
WARNING - This product contains chemicals known to the State of California to cause cancer, birth defects, and/or other
reproductive harm. Thoroughly wash hands after installing, cleaning, or otherwise touching this product.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
SEE UNIT LABEL FOR ADDITIONAL MODEL SPECIFICATIONS
SAVE THESE INSTRUCTIONS FOR USE BY OWNER/OCCUPANT
CAUTION: DISCONNECT POWER DURING INSTALLATION AND BEFORE SERVICING.
READ ALL INSTRUCTIONS COMPLETELY BEFORE STARTING INSTALLATION.
CLASS 2 OUTPUT
ILL:93319838
CRITICAL DIMENSIONS
UNSPECIFED TOLERANCES:
X.X=±0.1 X.XX=±0.03 X.XXX=±0.010
FRACTIONS=±1/32 ANGULAR TOLERANCE=±1°
DIMENSIONS IN INCHES
DIMENSIONS IN [ ] IN MM
CONFORMS TO ASME Y14.5M
DO NOT SCALE PRINT
THIRD ANGLE PROJECTION
When using electrical equipment, basic safety precautions should
3 2
always be followed including the following.
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
user will be required to correct the interference at his own expense.
INSTALLER:
currentlighting.com/dual-lite
© 2025 HLI Solutions, Inc. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
B
A
INCHES
The information contained in this drawing is the sole
property of HLI SOLUTIONS, INC. The reproduction,
distribution, and utilization of this document as well as
the communication of its contents to others without
written authorization is prohibited. All rights reserved in
DRAWN:
the event of the grant of a patent, utility, or design.
LM 08/25/24
ILL-PLD10+
CHECKED BY:
LM 05/30/24
MATERIAL: FINISH: PART NO.
ENGINEERING:
- - 93319838
LM 05/30/24
SCALE SIZE DRAWING NO. REV.
CATALOG NO. SHT 1
B A
PV:1 93319838
PLD+ 1 SHTS
1
PLD10+
Emergency LED Battery Pack Installation,
Operation, and Service Instructions
PLD10 Plus LED Battery Pack Instruction Sheet_R01
Page 1 of 5
Rev 02/10/25
