LINOVISION IOT-S500 Series User Manual

Indoor environment monitoring sensor
Hide thumbs Also See for IOT-S500 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Indoor Environment
Monitoring Sensor
IOT-S500 Series
Updated on Apr 11，2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IOT-S500 Series and is the answer not in the manual?

Questions and answers

Related Manuals for LINOVISION IOT-S500 Series

Summary of Contents for LINOVISION IOT-S500 Series

  • Page 1 Indoor Environment Monitoring Sensor IOT-S500 Series Updated on Apr 11，2022...

  • Page 2: Safety Precautions

    In order to protect the security of the device, please change device password when first configuration. The default password is 123456. ❖ The device is not intended to be used as a reference sensor, and Linovision will not should responsibility for any damage which may result from inaccurate readings. ❖...

  • Page 3: Revision History

    For assistance, please contact Linovision technical support: Tel: +86571-86708175 E-mail:sales@linovision.com Website: www.linovision.com Revision History Date Doc Version Description Nov. 23, 2020 V 1.0 Initial version...

  • Page 4: Table Of Contents

    3.5.1 Calibration Settings....................12 3.5.2 Threshold & Alarm Settings ..................12 3.5.3 Data Storage ....................... 15 3.5.4 Data Retransmission....................17 3.5.5 Linovision D2D Settings .................... 18 3.6 Maintenance ......................... 19 3.6.1 Upgrade ........................19 3.6.2 Backup .........................20 3.6.3 Reset to Factory Default ....................21 4.

  • Page 5: Product Introduction

    1.1 Overview ® IOT-S500 series is a sensor mainly used for outdoor environment through wireless LoRaWAN network. IOT-S500 device is battery powered and designed for multiple mounting ways. It is equippedwith NFC (Near Field Communication) and can easily be configured by a smartphone.

  • Page 6: Hardware Overview

    2.2 Hardware Overview 2.3 GPIO Wiring (IOT-S500-DI) 2.3 Dimensions(mm) 2.4 Power Button Note: The LED indicator and power button are inside the device. Turn on/off and reset can also be configuredvia NFC. Function Action LED Indication Off → Turn On Press and hold the button for more than 3 seconds.

  • Page 7: Operation Guide

    2) If the smartphone fails to read/write configurations via NFC, keep the phone away and back to try again. 3) IOT-S500 series can also be configured by dedicated NFC reader provided by Linovision IoT or you can configure it via TTL interface inside the device.

  • Page 8: Lorawan Settings

    3.2 LoRaWAN Settings Linovision series support to configure join type, App EUI, App Key and other information. You can also keep all settings by default. Parameters Description Device EUI Unique ID of the device which can also be found on the label.
  • Page 9 Examples: 1, 40: Enabling Channel 1 and Channel 40 1-40:Enabling Channel 1 to Channel 40 1-40,60:Enabling Channel 1 to Channel 40 and Channel 60 All: Enabling all channels Null: Indicate that all channels are disabled Select Standard-Channel mode or Single-Channelmode. When Single-Channel Channel Mode mode is enabled, only one channel can be selected to send uplinks.

  • Page 10: Basic Settings

    1) Please contact sales for device EUI list if there are many units. 2) Please contact sales if you need random App keys before purchase. 3) Select OTAA mode if you use Linovision IoT Cloud to manage devices. 4) Only OTAA mode supports rejoin mode.

  • Page 11: Interface Settings (Iot-S500Di)

    Parameters Description Reporting interval of transmitting battery level and liquid status to Reporting Interval network server. Range: 1-1440mins, Default: 1440 mins When the liquid is full, click the Calibrate button to record the full status. After calibrated, the device will report a calibration result packet. Note: Full Liquid 1) The device will calibrate once automatically after turning on 20...

  • Page 12: Advanced Settings

    IOT-S500TH/MCS/SLD/ZLD/DI supports temperature and humidity calibration. The device will add the calibration value to raw value and upload the final values to network server. 3.5.2 Threshold & Alarm Settings IOT-S500 series supports various types of alarm settings. 1) Temperature Threshold Alarm: IOT-S500TH/MCS/SLD/ZLD/DI supports temperature threshold alarm settings. When current temperature is over or below the threshold value, the device will report the threshold alarm packet once instantly.
  • Page 13 Parameters Description The interval to detect temperature after threshold alarm triggers. Collect Interval This interval should be less than reportinginterval. 2) IOT-S500MCS/SLD/ZLD/MLD: Parameters Description After enabled, the device will report the alarm packet when the door Alarm Reporting status changes to open or water is detected to leak. The interval to report digital status after alarm triggers.
  • Page 14 Parameters Description After enabled, the device will report the alarm packet according to Alarm Reporting digital change options. The interval to report digital status after alarm triggers. This Alarm Reporting Interval interval should be less than reportinginterval. Alarm Reporting Times Alarm packet report times after alarm triggers.

  • Page 15: Data Storage

    If the “Water Flow” status has passed the timeout interval, the device will report a water flow timeout alarm packet. If the water Water Flow Timeout flow status stops during next timeout interval, the device will report Alarm the alarm dismiss packet; otherwise, it will report an alarm packet again.
  • Page 16 ® Besides, when device LoRaWAN version is set as 1.0.3,the device will send MAC commands to ask the network server for the time every time it joins the network. 2. Go to Device >Setting >General Settings to enable data storage feature. 3.

  • Page 17: Data Retransmission

    3.5.4Data Retransmission IOT-S500 series (except IOT-S500-CL) supports data retransmission to ensure network server can get all data even if networkis down for some times. There are two ways to get the lost data: Network server sends downlink commands to to enquire the historical data for specifying ●...

  • Page 18: Linovision D2D Settings

    2. Go to Device >Setting >D2DSettings to enable Linovision D2Dfeature. 3. Define an unique D2D key which is the same as Linovision D2D agent devices. (Default D2D key: 5572404C696E6B4C6F52613230313823) 4. Enable one of status mode and configure 2-bytehexadecimal Linovision D2Dcommand. When the status is triggered, IOT-S500 series sensor will send this control command to corresponding Linovision D2Dagent devices.

  • Page 19: Maintenance

    Note: ® 1) If you enable LoRa Uplink, a LoRaWAN uplink packet that contains corresponding alarm status will be sent to gateway after the Linovision D2D control command packet. Otherwise, the ® alarm packet will not send to LoRaWAN gateway.

  • Page 20: Backup

    3.6.2Backup IOT-S500 devices support configuration backup for easy and quick device configuration in bulk. ® Backup is allowed only for devices with the same model and LoRaWAN frequency band. 1. Go to Template page on the App and save current settings as a template. You can also edit the template file.

  • Page 21: Reset To Factory Default

    3.6.3Reset to Factory Default Please select one of following methods to reset device: Via Hardware: Hold on power button (internal) for more than 10s until LED blinks. Via ToolBox App: Go to Device >Maintenance to click Reset, then attach smart phone with NFC area to device to complete reset.

  • Page 22: Installation

    4. Installation 4.1 IOT-S500 Device Installation 1. Attach IOT-S500 device to the wall and mark the two holes on the wall. The connecting line of two holes must be a horizontal line. 2. Drill the holes according to the marks and screw the wall plugs into the wall. 3.

  • Page 23: Sensor Installation

    Besides, it can also be mountedto a wall via 3M tape or be mounted to a pole via cable-tie. 4.2 Sensor Installation ● IOT-S500MLD/SLD/ZLD Refer to Water Leakage Sensor Installation Guide . ● IOT-S500MCS Fix the two magnet parts with 3M tape or screws, the two parts should be aligned. Fixed by Screws Fixed by 3M Tape ●...

  • Page 24: Device Payload

    1 Byte N Bytes 1 Byte 1 Byte M Bytes 1 Byte 5.1 Basic Information IOT-S500 series sensors report basic information of sensor whenever joiningthe network. Channel Type Description 0b (Power On) ff, this means the device is on 01(Protocol Version) 01=>V1...

  • Page 25: Sensor Data

    ff0bff ff0101 ff166136c40091605408ff090300 ff0a0101 ff0f00 Channel Type Value Channel Type Value (Power On) (Protocol Version) (V1) Channel Type Value Channel Type Value 6136c400916054 0300 (Device SN) (Hardware Version) (V3.0) Channel Type Value Channel Type Value 0101 (Software (V1.1) (Device Type) (Class A) Version) 5.2 Sensor Data...

  • Page 26: Iot-S500Di

    01 75 64 Channel Type Value 75(Battery) 64 =>100% 3. Temperature threshold alarm packet: reports once when temperature reaches the threshold. 03671001 Channel Type Value 10 01 =>01 10 =272/10=27.2°C 4. Magnet or water leakage change packet: reports the change immediately and according to alarm settings.
  • Page 27 2 Bytes, Byte 1: 01=High,00=Low, DI Alarm Byte 2: 01=Alarm,00=Alarmdismiss 9 Bytes, water_conv(2B) +pulse_conv (2B) + Water consumption (4B) +Alarm Status (1B) Alarm Status: 01-Wateroutage timeout alarm Pulse Alarm 02-Wateroutage timeout alarm dismiss 03-Waterflow timeout alarm 04-Waterflow timeout alarm dismiss Examples: 1.

  • Page 28: Iot-S500Cl

    2. Alarm packet: reports according to alarm settings. 83ed00 Channel Type Value Liquid status: 01=empty 5.3 Downlink Commands IOT-S500 series sensors support downlink commands to configure the device. The application port is 85 by default. 5.3.1 IOT-S500TH/MCS/XLD Command Channel Type Description...
  • Page 29 CTRL: Bit2~0: 000 -disable 001 -below (minimum threshold) 010 -over (maximum threshold) 011 -within 100 -below or over Bit 5~3: 001 -Temperature 010 -Magnet or water leakage Bit 7~6: 00 4 Bytes, Number(1B)+Function(1B)+D2D Command(2B) Number: 01 -Temperaturethreshold trigger 02 -Temperaturethreshold doesnʼt D2D Setting trigger 03 -Status trigger...

  • Page 30: Iot-S500Di

    Channel Type Value 03 (Report Interval) b0 04 =>04 b0 =1200s= 20 minutes 2. Reboot the device. ff10ff Channel Type Value 10 (Reboot) ff (Reserved) 3. Set a temperature threshold as below 15°C or over 30°C. ff 06 0c96002c0100000000 Channel Type Value CTRL:0c =>00001100...
  • Page 31 Pulse Digital Filter 0100-disable, 0101-enable Modify Initial 01+Initialcounting value (4B) counting value 9 Bytes Byte 1: 00=disable, 01=enable Pulse Value Byte 2-3:Water_conv Conversion Byte 4-5:Pulse_conv Byte 6-9:Unit,ASCII code 0100-Cleanthe count Pulse counter 0101-Stopcounting 0102-Startcounting 9 Bytes, CTRL (1B) +Min (2B) +Max (2B) +00000000(4B) CTRL: Bit2~0:...
  • Page 32 02 -Wateroutage timeout alarm release 03 -Waterflow timeout alarm 04 -Waterflow timeout alarm release 05-DIfrom low to high 06-DIfrom high to low Enable: 00 -Disable 01 -Onlyuse D2D 03 -UseD2D&LoRaWAN Uplink Example:s 1. Set reportinginterval as 20 minutes. ff03b004 Channel Type Value b0 04 =>04 b0 =1200s= 20 minutes...

  • Page 33: Iot-S500Cl

    100 =below or above Min:96 00=>00 96 =150/10=15°C Max: 2c 01=>012c =300/10=30°C 6. Enable water outage timeout alarm and set timeout interval as 10 minutes. ffa1 01 0001 00000000 ff a1 01 0201 0a000000 Channel Type Value 00=Waterflow threshold setting 01=Enable 02=Wateroutage timeout alarm 01=Enable...

  • Page 34: Historical Data Enquiry

    81=Enablealarm reporting and alarm dismiss report 0500=>0005=5reporting times 5.4 Historical Data Enquiry IOT-S500 series sensor supports sending downlink commands to enquire historical data for specified time point or time range. Before that, ensure the device time is correct and data storage feature was enabled to store the data.

  • Page 35: Data Format

    ce (Historical Data) Data time stamp (4B) +Data Contents (Mutable) Data time stamp (4B) +Temperature(2B) +Humidity(1B) ce (IOT-S500DI +Alarm Type (1B) +Interface Type(1B) +Digital(1B)+ Historical Data) Water_conv (2B) +Pulse_conv (2B) +Water consumption(4B) Data format: Sensor Description IOT-S500TH Temperature(2B) +Humidity(1B) Temperature(2B) +Humidity(1B) +Door Status(1B) IOT-S500MCS IOT-S500SLD/ZLD Temperature(2B) +Humidity(1B) +Leakage Status(1B)
  • Page 36 6c (Enquire data in time range) 00: data enquiry success 21ce 0d755b63 0801 57 00 02 00 0a00 6400 3333af41 Channel Type Time Stamp Value Temperature: 0801=>0108=26.4°C Humidity: 57=>87=43.5%RH Alarm Type: 00=No ce (EM300-DI 0d755b63 => Interface Type: 02=Counter Historical 2022/10/28 Digital: None Data)
