Related Manuals for Feider FRWC1-1
Summary of Contents for Feider FRWC1-1
- Page 1 ORIGINAL INSTRUCTIONS >EN ROBOTIC WINDOW CLEANER FRWC1-1 USER GUIDE CAUTION : Read the instructions before using the machine !
-
Page 2: Table Of Contents
CONTENTS 1. SAFETY INSTRUCTIONS........................3 2. PRODUCT DESCRIPTION & PARAMETERS.................. 7 3. USE STEPS............................. 9 4. CLEANING FUNCTION........................11 5. POWER FAILURE PROTECTION(BACKUP BATTERY).............12 6. THE REMOTE CONTROL........................13 7. TUYA APP OPERATION GUIDE.......................14 8. TROUBLESHOOTING.........................16 9. PRODUCT CARE..........................17 10. DECLARATION OF CONFORMITY....................18 11. -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS Attention! Must read before use This appliance shall not be used by children. Keep the appliance and its cord out of reach of children. This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards... - Page 4 Do not use the adapter in a humid environment. Please do not touch the power adapter with wet hands during use. Please charge the window cleaner at the voltage that the power adapter can withstand. Do not use a damaged power adapter, charging cable or power plug.
- Page 5 Please store this product out of reach of children. Please use this product in 0℃~40℃ (32℉~104℉) ambient temperature. Do not clean damaged glass and objects with uneven surface, this product will not produce enough vacuum suction adsorption on uneven surface or damaged glass machine.
- Page 6 Risk of electric shock Make sure the power is completely disconnected and the machine is off before cleaning the body or maintaining the body. Do not drag the power plug through the extension cord, power off should be properly unplugged. ...
-
Page 7: Product Description & Parameters
window glass. Make sure the machine is safely attached to the window surface before releasing your hands. Before turning off the machine, please hold the machine to avoid dropping it. Do not use this product to clean frameless windows or glass . - Page 8 with a more fashionable appearance and a lighter and thinner body. It has better cleaning performance in more different home environments. Specifications Adaptor input 100 - 240V~, 50/60Hz, 1.5A Max. Adaptor output 24 V d.c. 3.0A, 72W Battery 14.8V d.c. 650mAh Rating 24 V d.c.
-
Page 9: Use Steps
Product acessories 3. USE STEPS Power connect A. Connect the AC power cord to the adapter. B. Insert the type threaded connector into the power connector of the fuselage and tighten it. C. Plug the power cord into the socket. Our device has built-in battery for standby power supply in case of power failure. - Page 10 Attach a safety rope A. For the glass doors and windows without balcony, a danger warning must be put on the ground downstairs, to make sure people do not approach. B. Be sure to fasten the safety rope before using, and tie the safety rope to the fixed objects in the house to avoid danger.
-
Page 11: Cleaning Function
Cleaning completed A. Hold the window cleaner with one hand and press the button for 2 seconds with the other hand to turn off the power. B. Remove the window cleaning robot from the window. C. Untie the safety rope and place the machine and its related accessories in a dry and ventilated environment for next use. -
Page 12: Power Failure Protection(Backup Battery)
Spray water function Window cleaning robot set one water spray holes on each side of the left and right sides, when the robot to the left cleaning, the left side spray water, when the robot to the right cleaning, the right side spray water. -
Page 13: The Remote Control
6. THE REMOTE CONTROL A. Do not charge the remote control battery, do not disassemble the battery, do not put the battery in fire, there is a possibility of detonation. B. Please use No., AAA/RL batteries of the same specification as required, please do not use different types of batteries, there is a danger of burning the circuit, when the battery is installed and removed, push the remote control cover down, open the battery cover, and install .When using the battery, align the negative pole with one end of the spring first, press it down, the reverse... -
Page 14: Tuya App Operation Guide
7. TUYA APP OPERATION GUIDE 6. Type” ” and then click “Click LogIn” 1. Open the App store your phone. 2. Search for "Tuya" App. 3. Click to download and install. 7. Turn on Bluetooth: The robot connects power and open the 4. - Page 15 10. (1) Click “window cleaning robot” (2) Click " " to start the robot 11. Click on Control panel to enter clean mode Clean mode: Manual Mode Up Mode Left Mode Right Mode 12. Click on the control panel to enter the water spray mode A Water spray mode: A Automatic Water Spray Mode M Manual Spray Mode...
-
Page 16: Troubleshooting
8. TROUBLESHOOTING 1. When the cleaning cloth is used for the first time (especially in the dirty environment of the outer window glass), the machine may run slowly or even fail: A. When unpacking the machine, clean and dry the supplied cleaning cloth before use. B. -
Page 17: Product Care
beveled window frame). 9. How to deal with the warning sound and red light flashing when the machine stops oper-ation due to power failure： A. Gently pull the safety rope back to the machine; when pulling the safety rope, it should be close to the parallel glass as far as possible to avoid falling. -
Page 18: Declaration Of Conformity
BUILDER SAS 32 rue Aristide Bergès - Z.I. du Casque - 31270 Cugnaux - France Declares that the machine indicated below: Designation: ROBOTIC WINDOW CLEANER Model: FRWC1-1 Serial number: 20241100001-20241101200 Is in conformity with the European Directives: Radio Equipment Directive 2014/53/EU... -
Page 19: Warranty
11 . WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 5 years from the date of the original purchase. It can be extended by one year if the user subscribes to website of myswap. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. -
Page 20: Product Failure
1 2 . PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: • Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. •... -
Page 21: Warranty Exclusions
1 3 . WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 22 BUILDER SAS 32 rue Aristide Bergès - Z.I. du Casque - 31270 Cugnaux - France Made in PRC...
