ASSEMBLY INSTRUCTIONS
BELLSOFSTEEL
www.bellsofsteel.com | www.bellsofsteel.us | Telephone: 1-888-718-7997
BLITZ AIR ROWER
SKU: ROW2-BTZ
PO:
Stuck? Scan the QR code for the assembly video

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLITZ AIR ROWER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bells Of Steel BLITZ AIR ROWER

  • Page 1 BLITZ AIR ROWER SKU: ROW2-BTZ ASSEMBLY INSTRUCTIONS BELLSOFSTEEL Stuck? Scan the QR code for the assembly video www.bellsofsteel.com | www.bellsofsteel.us | Telephone: 1-888-718-7997...
  • Page 2 BUILDING STRENGTH, ONE BOLT AT A TIME. Welcome to Bells of Steel, you’ve made an excellent choice. Kaevon Khoozani Crush your Gains! Subscribe to our Warranty & returns? We got Changed your mind? No sweat. YouTube for workouts & how-to’s.
  • Page 3 A GUIDE TO SAFETY We know you are excited to use your new Bells of Steel gear, but please read through this Guide to Safety to ensure you do not hurt yourself or others while exercising. It is your responsibility to ensure that all users of the equipment are informed of all warnings and instructions in this manual.
  • Page 4 FCC WARNING – POSSIBLE RADIO/TELEVISION INTERFERENCE Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 5 Exploded Drawing PAGE 5 OF 34...
  • Page 6: Parts List

    PARTS LIST PAGE 6 OF 34...
  • Page 7 PARTS LIST Short Spacer for Guide Wheel PAGE 7 OF 34...
  • Page 8: Assembly Part List

    HARDWARE KIT LIST • Hardware Package ASSEMBLY PART LIST • PAGE 8 OF 34...
  • Page 9 ASSEMBLY STEP 1: PAGE 9 OF 34...
  • Page 10 STEP 2: Assemble the Pedal Support Plate L (# 7) onto the Main Frame (# 1) , align the hole positions,With 2PCS Outer 2. Assemble the Cover For Pedals (# 23) onto the Main Frame (# 1) and lock it with 3PCS Self Tapping Screw (# 84). PAGE 10 OF 34 PAGE 9 OF 32...
  • Page 11 STEP 3: PAGE 11 OF 34...
  • Page 12 STEP 4: PAGE 12 OF 34...
  • Page 13 STEP 5: Connection of the Aluminium Rail to the Main Frame WARNING: At least two people are required when disconnecting or connecting the monorail. Do not attempt to lift the main frame if you have limitations in the musculoskeletal system. To prevent WARNING: Do not attempt to operate the unit when it is disassembled.
  • Page 14 HOW TO CHANGE THE HANDLE Twist handlebar to open u-bolt section. Handlebar Loosen nuts using 10mm wrench, Remove the u-bolt. Attach carabiner. Fix the other end to the post. PAGE 14 OF 34...
  • Page 15: Foot Pedal Adjustment

    HOW TO OPERATE THE DAMPER Rotate Fan adjustment cover (# 134) ,When adjusted to L1, the resistance is minimal, When adjusted to L10, the resistance is maximum. FOOT PEDAL ADJUSTMENT There are several settings for the foot position. Before you start with your training, adjust the foot pedal correctly. Loosen the strap by opening the Velcro and place your foot on the pedal through the strap.
  • Page 16 STORAGE PAGE 16 OF 34...
  • Page 17: Directions For Use

    DIRECTIONS FOR USE PAGE 17 OF 34...
  • Page 18 CAUTION PAGE 18 OF 34...
  • Page 19 REMOVE THE PACKAGING AUXILIARY TUBES PAGE 19 OF 34...
  • Page 20 CONSOLE INSTRUCTION & BLUETOOTH APP CONNECTION INSTRUCTIONS DISPLAY FUNCTION: Description TIME User exercise time. Without setting, it will count up, setting range:0:00~99:00(+1:00) TIME/500m Display its value according to the signal input. DIST User exercise distance. Without setting, it will count up, setting range: 0~9990(+10) User exercise calorie.
  • Page 21 OPERATION INSTRUCTION 1. Power ON: 2. Standby Mode: 3. Standby Mode: 4. Exercise Stop Screen: 5. The display screen of VR adjustment: LEVEL 01 LEVEL 05 PAGE 21 OF 34...
  • Page 22 6. MANUAL: Picture 1 Picture 2 Picture 3 Picture 4 Picture 5 PAGE 22 OF 34...
  • Page 23 7. INTERVAL: Picture 6 Picture 7 Picture 8 Picture 9 Picture 10 Picture 11 PAGE 23 OF 34...
  • Page 24 Picture 12 Picture 13 Picture 14 PAGE 24 OF 34...
  • Page 25 Picture 15 Picture 16 Picture 17 Picture 18 Picture 19 Picture 20 PAGE 25 OF 34...
  • Page 26 7. TARGET: Picture 21 Picture 22 Picture 23 Picture 24 Picture 25 PAGE 26 OF 34...
  • Page 27 Picture 26 Picture 27 Picture 28 Picture 29 Picture 30 Picture 31 Picture 32 Picture 33 PAGE 27 OF 34...
  • Page 28 Picture 34 Picture 35 Picture 36 Picture 37 Picture 38 Picture 39 Picture 40 Picture 41 PAGE 28 OF 34...
  • Page 29 Special Mode: Picture 42 Picture 43 VR Correction Mode: Picture 44 Picture 45 Picture 46 Picture 47 PAGE 29 OF 34...
  • Page 30 KINOMAP APP CONNECTION STEPS PAGE 30 OF 34...
  • Page 31 PAGE 31 OF 34...
  • Page 32 PAGE 32 OF 34...
  • Page 33 PAGE 32 OF 34...
  • Page 34 PAGE 33 OF 34...
  • Page 35 YOU’RE FINISHED! WANT TO LEARN MORE ABOUT THE BLITZ AIR ROWER? CHECK OUT THE OVERVIEW VIDEO: VISIT OUR SHOWROOMS Calgary - HQ Toronto - Showroom Indianapolis - Showroom Corporate Headquarters 7880 66 St SE, Calgary, AB, Canada U.S.A. Headquarters 5925 W 71st St, Indianapolis, IN, U.S.A.
