- Page 1 SAMSON PC/104 Single-Board Computer With E3825/E3845 Processor User Manual Rev 1.0 © Copyright 2025 FOR TECHNICAL SUPPORT Diamond Systems Corporation PLEASE CONTACT: www.diamondsystems.com Email: support@diamondsystems.com...
-
Page 2: Table Of Contents
Contents Important Safe Handling Information ......................3 Introduction ..............................5 Samson Product Overview ........................... 5 Feature List ..............................5 Samson Ordering Guide ..........................6 Block Diagram ..............................7 BOARD DIMENSIONS ............................8 Connector and Jumper Locations ......................... 9 Jumper Selection ............................10 5.1.1... -
Page 3: Important Safe Handling Information
Diamond Systems recommends that all its boards be stored only in individual ESD-safe packaging units. If multiple boards are stored together, they should be contained in bins with dividers placed between the boards. Do not pile boards on top of each other or cram too many boards within a small location. - Page 4 Overvoltage on Analog Input: If a voltage applied to an analog input exceeds the power specification of the board, the input multiplexer and/or parts behind it can be damaged. Most Diamond Systems boards will withstand an erroneous connection of up to 36V on the analog inputs, even when the board is powered off, but not on all boards, and not under all conditions.
-
Page 5: Introduction
2 INTRODUCTION 2.1 Samson Product Overview Samson features a fanless design, ensuring efficient operation without the need for active cooling. It supports the Intel® Atom™ E3800 family of processors, offering powerful performance for embedded applications. Dual Gigabit Ethernet ports provide high-speed network connectivity, while the board also includes LVDS and Analog RGB ports, enabling versatile display options. -
Page 6: Samson Ordering Guide
SBC processor options. In general, when a new COM is added, OS support will also be available for the current versions of Windows and Ubuntu Linux. SAM-E3825-4G-XT Samson PC/104 SBC, E3825 processor, 4GB, -40 to +85C SAM-E3845-4G-XT Samson PC/104 SBC, E3825 processor, 4GB, -40 to +85C... -
Page 7: Block Diagram
3 BLOCK DIAGRAM Figure 1: SAMSON PC/104 CPU Module Block Diagram Samson User Manual rev 1.0 www.diamondsystems.com Page 7... -
Page 8: Board Dimensions
4 BOARD DIMENSIONS The illustrations below provide dimensions of the key connectors and features of Samson. Samson User Manual rev 1.0 www.diamondsystems.com Page 8... -
Page 9: Connector And Jumper Locations
5 CONNECTOR AND JUMPER LOCATIONS Figure 2: Top view (heat sink omitted) Figure 3: Bottom view showing Minicard and SODIMM sockets Samson User Manual rev 1.0 www.diamondsystems.com Page 9... -
Page 10: Jumper Selection
The board comes with some jumpers to alter the hardware configuration. The following table describes the Jumper Blocks on the baseboard. Description Jumper Sets LCD inverter voltage Sets LCD panel voltage The voltage selection of LCD panel Figure 4: Default Jumper Locations Samson User Manual rev 1.0 www.diamondsystems.com Page 10... -
Page 11: Jinv1
Pins 1-2: Keeps CMOS (default setting) • Pins 2-3: Clears CMOS This feature allows you to either retain or reset the CMOS settings based on your system requirements. 5.1.4 JPIC1 This jumper is for internal testing only. Samson User Manual rev 1.0 www.diamondsystems.com Page 11... -
Page 12: Connector Pinouts
Main power input for SBC operation Although two terminals are provided for both 5V input and Ground, the individual terminal rating exceeds the power requirements for Samson, so just a single +5V connection and a single Ground wire is sufficient. 6.2 USB1 The USB1 connector is a USB 3.0/2.0 Type A connector, designed to support both USB 3.0 and 2.0 devices. -
Page 13: Usb 2.0 Ports
The AUDIO1 connector is an AUDIO connector with a 2.00mm pitch 2x5-pin wafer connector. The pin assignments are as follows: Line In R Line In L Line Out R Line Out L Connector PN: Connector Type: 2.00mm pitch 2x5-pin wafer connector. Mating Cable PN: DSC no. 6989030 Samson User Manual rev 1.0 www.diamondsystems.com Page 13... -
Page 14: Vga (J2)
DIO 0 DIO 1 DIO 2 DIO 3 DIO 4 DIO 5 DIO 6 DIO 7 Connector PN: Connector Type: 2.00mm pitch 2x5-pin wafer connector Mating Cable PN: DSC no. 6989036 Samson User Manual rev 1.0 www.diamondsystems.com Page 14... -
Page 15: Kbms1
Serial ports 3 and 4 support RS-232 only. The pinout for these connectors matches the RS-232 column in the below diagram. RS-232 RS-422 RS-485 DCD# DSR# RTS# CTS# DTR# ACES 86801-09 Connector PN: Connector Type: 1x9-pin1.25mm 4-wall connector Mating Cable PN: DSC no. 6989031 Samson User Manual rev 1.0 www.diamondsystems.com Page 15... -
Page 16: Jfrt1
SSDs, conforming to the SATA interface standard for modern storage solutions. Ground Transmit + Transmit - Ground Receive - Receive + Ground Connector Type: Industry-standard SATA 7-pin connector Mating Cable PN: Generic Samson User Manual rev 1.0 www.diamondsystems.com Page 16... -
Page 17: Lvds
The LCD Inverter Connector uses a 1x6-pin CVILUX 1.25mm CI4406P1V00-LF 4-wall connector. The pin assignments are as follows: INV_VCC INV_VCC BKLT_EN BKLT_CTRL Connector PN: Connector Type: 1x6-pin CVILUX 1.25mm CI4406P1V00- LF 4-wall connector Samson User Manual rev 1.0 www.diamondsystems.com Page 17...
