Introduction:
The SE Controls Variable Speed Fan Control Panel is a modular
design that is built and tested to provide a method of operating a
single 400 V three-phase 50Hz duty/ standby fan arrangement
It must not be used for any other application or in conjunction with
other manufacturers' products without prior consultation with
SE Controls.
Installation of this equipment must only be carried out by competent
and qualified persons.
This information pack must be retained for future reference by the client
and be made available for reference by persons installing, servicing or
modifying the panel.
+44 (0)1543 443060
sales@secontrols.com
www.secontrols.com
VARIABLE SPEED FAN CONTROL
PANEL 30 kW - 37 kW
Technical information and operating instructions
Application:
The Variable Speed Fan Control Panel is a control
system designed to operate 400 V/ 3PH/50Hz
fans in a duty and standby configuration for
smoke control in a powered extract system.
The control of environmental fans is also possible
when specific additional packs are fitted.
Operating from a 400 V supply, the Variable
Speed Fan Control Panel can control fans up to
30kW - 37kW (Standard Versions).
Please keep these operating instructions for future reference and maintenance.
Subject to technical modifications. Diagram is not binding.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SE Controls FCS0295 Series
Summary of Contents for SE Controls FCS0295 Series
- Page 1 Technical information and operating instructions Introduction: Application: The SE Controls Variable Speed Fan Control Panel is a modular The Variable Speed Fan Control Panel is a control design that is built and tested to provide a method of operating a...
-
Page 2: Table Of Contents
Contents General Information Connections, Continued 3.13. Pressure SensorConnections 1.1. General Safety Information (TB27-32) 1.2. Health and Safety 3.14. Outside Temperature Sensor / Hot 14 1.3. Environment Corridor Solution (TB20, if this option pack is fitted!) 1.4. User Responsibilities 3.15. 0-10 V Output 1.5. -
Page 3: Important Notices
• Do NOT use this controller • Where a replacement is for any other purpose SE Controls reserves the right to needed for consumable other than that intended introduce any modifications and items e.g. fuses, they by the manufacturer. -
Page 4: General Information
If recycling facilities are not locally available, contact SE Controls who can arrange for recycling carried out according to these instructions and to the operating instructions of the drives. -
Page 5: Maintenance
Within the UK a suitable service contract with SE Controls is recommended for this purpose. 1.8. Contact Information The system must be protected against unintentional start-up! -
Page 6: Specification
Specification 2.1. Device Overview Part number 30-37kW Fan Control Panel FCS0295XXXX Dimensions 1600 x 1200 x 400 mm (H x W x D) – Standard Versions Mass Approx. 140-210 kg Supply 400 V ac 50/60 Hz Output Up to 61.5A (37kW Inverter version) – Other versions to be advised Cable Entries Cable entries are via up to 35mm stranded or 50mm solid IP Rating... -
Page 7: Minature Circuit Breakers
2.4. Miniature Circuit Breakers Rating Function CB01 D 40A Input Inverter 1 CB02 D 40A Input Inverter 2 CB03 C 10A PSU 1 + Cooling Fan CB04 C 4A PSU 2 CB05 D 40A Output Inverter 1 CB06 D 40A Output Inverter 2 CB07 D 16A... -
Page 8: Connections
Connections 3.1. Connections The 10 mm terminals (fan connections) have a cable capacity of 10 mm stranded or 16 mm solid. All 4 mm terminals have a cable capacity of 2.5 mm stranded or 4 mm solid. Each terminal is identified with a 2-letter code which is expanded on the terminal label. The following sections are to be used for guidance only and are subject to change. -
Page 9: Duty Fan And Stand By Fan
3.3. Duty Fan and Standby Fan Connections (TB11 & TB12) DIN RAIL CONNECTIONS - TB12 INSIDE CONTROL PANEL DIN RAIL CONNECTIONS - TB11 INSIDE CONTROL PANEL T1 T2 T3 E T1 T2 T3 E STANDBY FAN IN THE FIELD DUTY FAN IN THE FIELD EF:02 EF:01... -
Page 10: 230 V Ac Nv Fan Connections
3.5. 230 V ac NV Fan Connections (TB13) DIN RAIL CONNECTIONS - TB13 INSIDE CONTROL PANEL EARTH BAR - TB08 T1 T2 T3 T3 IS UNUSED UNLESS 415V 3PH IS REQUIRED ENVIRONMENTAL FAN (230V) IN THE FIELD EF:03 230V 3.6. Fan Damper Connection (TB15) DIN RAIL CONNECTIONS - TB15 INSIDE CONTROL PANEL... -
Page 11: Activation Contact (Tb10)
3.7. Activation Contact (TB10) DIN RAIL CONNECTIONS - TB10 INSIDE CONTROL PANEL IN THE FIELD ACTIVATION CONTACT NORMALLY CLOSED 3.8. Firemans Override Switch - FOS - and Boost (TB09) DIN RAIL CONNECTIONS - TB09 INSIDE CONTROL PANEL FOS SWITCH - BOOST IN THE FIELD FIREMANS OVERIDE... -
Page 12: Healthy Contact (Tb16)
3.9. Healthy Contact (TB16) DIN RAIL CONNECTIONS - TB16 INSIDE CONTROL PANEL CLOSED CONTACT OPENS ON FAULT SYSTEM HEALTHY VFC IN THE FIELD 3.10. Duty/Standby Fan Activated (TB17) DIN RAIL CONNECTIONS - TB17 INSIDE CONTROL PANEL CLOSED CONTACT OPENS ON FAULT DUTY / STANDBY ACTIVATED VFC IN THE FIELD Please keep these operating instructions for future reference and maintenance. -
Page 13: Lift To Ground/Stairwell (Tb18)
3.11. Lift to Ground/Stairwell (TB18) DIN RAIL CONNECTIONS - TB18 INSIDE CONTROL PANEL CLOSED CONTACT OPENS ON ACTIVATION LIFT TO GROUND / STAIRWELL IN THE FIELD 3.12. Environmental Damper Radial (TB14, if this option pack is fitted) DIN RAIL CONNECTIONS - TB14 INSIDE CONTROL PANEL EARTH BAR - TB08 NV DAMPER RADIAL... -
Page 14: Pressure Sensorconnections
3.13. Pressure Sensor Connectors (TB27-32) DIN RAIL CONNECTIONS - TB27-32 INSIDE CONTROL PANEL PLEASE NOTE PRESSURE SENSOR DIN RAIL TERMINALS ARE MOUNTED STARTING FROM RIGHT TO LEFT PRESSURE SENSORS IN THE FIELD 24Vac V OUT 24Vac V OUT 3.14. Outside Temperature / Hot Corridor Solution -(TB23 if this option is fitted) DIN RAIL CONNECTIONS - TB23 INSIDE CONTROL PANEL OUTSIDE AIR TEMPERATURE... -
Page 15: Output
3.15. 0-10V Output (TB24, if this option pack is fitted) DIN RAIL CONNECTIONS - TB24 INSIDE CONTROL PANEL 0-10V OUTPUT IN THE FIELD 0-10V 3.16. Push-Pull Panel Link Connection (TB21, if this option is fitted) DIN RAIL CONNECTIONS - TB21 INSIDE CONTROL PANEL 2 PANEL 2 PLEASE NOTE... -
Page 16: Oslink Connection
3.17. OSLink Connection (TB22, if this option is fitted) DIN RAIL CONNECTIONS - TB22 INSIDE CONTROL PANEL TERMINALS IN PANELS IN THE FIELD Please keep these operating instructions for future reference and maintenance. +44 (0)1543 443060 Subject to technical modifications. Diagram is not binding. sales@secontrols.com For a larger version of this diagram, please contact: technicalsupportteam@secontrols.com www.secontrols.com... -
Page 17: System Design
fire/ building regulations. This is beyond the scope of this document. If in doubt, consult SE Controls or approved agents who can give further guidance. The system design documentation should include the ‘Cause and Effect’ list or similar to identify the essential smoke control functions of the system. -
Page 18: Installation, Commissioning And Fault Finding
Installation, Commissioning and Fault Finding 5.1. Fixing When installing a panel internally, the fixing brackets should be screwed to the panel first. Then, hold the panel against the surface to which it is to be fixed. Mark through the holes. Drill appropriate sized pilot/fixing holes and use plastic plugs/cavity fixings where appropriate. -
Page 19: First Power Up Tests
5.2. First power-up tests Full commissioning of a new system requires the availability of three phase and neutral electrical supply. If activation is via a fire alarm controlled relay, ensure the fire alarm is normally closed when the system is healthy. For networked systems, an unbound, faulty or disconnected OSLink card may cause a fault indication. -
Page 20: Basic Fault Finding For Standard Version
5.4. Basic Fault Finding for Standard Version No operation, No LEDs illuminated. Check if the isolator S01 is switched on. Check if all circuit breakers are toggled to the ON position. Measure the voltage between terminal 1 and 3 of CB01, which should be ±... -
Page 21: Wiring Schematics
Wiring Schematic (Includes all Option Packs) Please keep these operating instructions for future reference and maintenance. +44 (0)1543 443060 Subject to technical modifications. Diagram is not binding. sales@secontrols.com For a larger version of this diagram, please contact: technicalsupportteam@secontrols.com www.secontrols.com... - Page 22 Wiring Schematic (Includes all Option Packs) TB30 0.2A 0.2A 0.2A 0.2A 0.2A 0.2A 0.2A 0.2A TB31 0.2A 0.2A 0.2A 0.2A 0.2A 0.2A 0.2A 0.2A TB32 0.2A 0.2A TB27 TB28 TB29 Please keep these operating instructions for future reference and maintenance. +44 (0)1543 443060 Subject to technical modifications.
- Page 23 Notes: Please keep these operating instructions for future reference and maintenance. +44 (0)1543 443060 Subject to technical modifications. Diagram is not binding. sales@secontrols.com For a larger version of this diagram, please contact: technicalsupportteam@secontrols.com www.secontrols.com...
- Page 24 Fradley Park, Lichfield www.secontrols.com Staffordshire WS13 8RZ United Kingdon Name & registered office: Loanguard Limited, Lancaster House, Wellington Crescent, Fradley Park, Lichfield, Staffordshire WS13 8RZ United Kingdom Company No.01468061 Vat No.377 5600 30 - SE Controls is a Registered Trademark...
