- Page 1 INSTRUCTION MANUAL 54" Foosball Table SKY8457 + SKY8458 + SKY8459 Ver. 1...
- Page 2 Fasten screws loosely during assembly. Do not firmly tighten screws until item is fully assembled. bestchoiceproducts.com CHOKING HAZARD - Toy contains a small ball. Not for children under 3 years old. CHOKING HAZARD - Small parts. Not for children under 3 years old. ADULT ASSEMBLY REQUIRED...
-
Page 3: Tools Required
NOTICE Please retain these instructions for future reference. • Do not stand on or use any part of this set as a step ladder. • Firmly secure all bolts, screws and knobs before use. • Reconfirm that all bolts, screws, and knobs are secure every 90 days. •... - Page 4 PARTS SIDE PANEL END PANEL PLAYFIELD 2 PCS 2 PCS 1 PC 4 PCS SUPPORT LEG SUPPORT 2 PLAYER ROD 3 PLAYER ROD 2PCS 2 PCS 2 PCS 4 PCS 5 PLAYER ROD SCORER HANDLE CUP HOLDER 2 PCS 2 PCS 8 PCS 2 PCS SOCCER BALL...
- Page 5 PRODUCT ASSEMBLY Attach one of the part A side panel to part B end panels with four part 3 screws and four part 5 washers. Install two part E support to the part A side panel with two part 1 screws. Slide part C playfield into the designated slots.
- Page 6 PRODUCT ASSEMBLY Attach the other part A side panel with four part 3 screws, four part 5 washers, and two part 1 screws. Insert four part D legs into the corners. Place two part F leg supports between the legs. Attach the legs with sixteen part 3 bolts and sixteen part 5 washers.
- Page 7 PRODUCT ASSEMBLY Screw in four part 7 feet. Lift the table assembly and flip it upright before returning it to your building surface. Do not tip the assembly or lean it on the legs, as this may damage the product. DO NOT LEAN ON LEGS...
- Page 8 PRODUCT ASSEMBLY Slide the appropriate number of part 8 players (ivory) onto the part G, H, and I rods. Slide two part 11 rubber bumpers onto each rod, one bumper on each side.
- Page 9 PRODUCT ASSEMBLY Slide the appropriate number of part 9 players (black) onto the part G, H, and I rods. Slide two part 11 rubber bumpers onto each rod, one bumper on each side.
- Page 10 PRODUCT ASSEMBLY Confirm that the rods are arranged correctly. = HOME TEAM = VISITORS Secure players with twenty-six part 4 bolts and twenty-six part 7 nuts, one bolt/nut per player. Slide eight part K handles and eight part 10 end caps onto the rods, a handle and end cap per rod. Attach two part N goal sleeves with two part 2 screws.
- Page 11 PRODUCT ASSEMBLY Attach one part J scorer to each of the part A end panels with two part 2 screws, four screws total. Attach one part L cup holder to each of the part A end panels with four part 2 screws, eight screws total.
-
Page 12: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
