> Preface Preface Thank you for purchasing this product. By connecting this product to our inkjet printer, you can use the function of the extended option device. Please read this User Guide before using the device to configure the settings. Notice This section describes notices to be taken when using the device.
> Notice Precautions for Use WARNING Keep the plastic bags that are used with the machine away from children. The plastic may cling to their nose and mouth causing suffocation. Precautions for Handling the Machine's Interior WARNING Do not remove any covers or screws other than those explicitly mentioned in the guide. Contact with your service representative if any of the machine's internal components require maintenance or repair.
> Part names Part names LED Indicators There are LED indicators on the upper left side of the front of this product. The current state of the machine is shown by the LED indicators being lit, flashing, or being turned off. Name Icon LED Color...
Page 5
> Part names Button (Rear Side of Device) There is a button on the rear side of the device. Button IMPORTANT Only service personnel should press the button. If you press this button during normal use, paper jams may occur, resulting in malfunction or failure.
Page 6
> Describing Definition of Parameter in Extended Option Device Describing Definition of Parameter in Extended Option Device After connecting the printer with the interface box and then completing various settings, you can print to the post- processing peripheral by the following method. •...
Page 7
> Describing Definition of Parameter in Extended Option Device Ejecting from Fiery Controller The procedure for ejecting from a Fiery controller to extended option devices is as follows. Perform the operation for each job. Obtain the parameters associated with the setting information from the person in charge of installation.
Page 8
> Describing Definition of Parameter in Extended Option Device NOTE You can also operate the setting from the Command Center RX. Select the job you want to print from Fiery Controller (Fiery Command WorkStation), and right-click to select Properties. The Job Properties screen appears. Click [FINISHING].
Page 9
> Describing Definition of Parameter in Extended Option Device Ejecting from Printer Driver The procedure for ejecting to extended option devices using our printer driver is as follows. Obtain the parameters associated with the setting information from the person in charge of installation. Touch an application icon (Interface Box Setting) from the operation panel of printer.
Page 10
> Describing Definition of Parameter in Extended Option Device NOTE You can also operate the setting from the Command Center RX. Display the screen. Click [File] and select [Print] in the application. Configure the settings. Select the machine from the “Printer” menu and click the [Properties] button. Select the [Basic] tab.
Page 11
> Describing Definition of Parameter in Extended Option Device Configuring extended option device from Command Center RX From Command Center RX, you can select job settings for extended option devices in the same way as with the application on the control panel. The steps are as follows. Display the screen.
Page 12
> Checking Status of Extended Option Device Checking Status of Extended Option Device You can check various statuses of the extended option devices from the operation panel. Offline When the extended option device is being initialized, “Please Wait” appears. Cover Open or Paper Jam If the cover of the extended option device is open or a paper jam occurs, an error message will be displayed with a JAM code.
Page 13
> Checking Status of Extended Option Device Paper Full Error When the output tray is full of output paper, an illustration and a message indicating that tray A of the 4,000-sheet finisher is full appears instead. Power Cord Not Connected If the power cord of the extended option device is not connected or is not properly connected, a power unconnected error will appear.
