Help Guide
Wireless Microphone
UO-ULTMIC1
Model: YY7867E
Design and specifications are subject to change without notice.
Quick Start Guide
Let's start to use
Connect the receiver to the speaker.
Turn on the power for the microphone, receiver, and speaker.
Sing or talk on the microphone.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UO-ULTMIC1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony UO-ULTMIC1

Summary of Contents for Sony UO-ULTMIC1

  • Page 1 Help Guide Wireless Microphone UO-ULTMIC1 Model: YY7867E Design and specifications are subject to change without notice. Quick Start Guide Let’s start to use Connect the receiver to the speaker. Turn on the power for the microphone, receiver, and speaker. Sing or talk on the microphone.

  • Page 2: Getting Started

    In case of water exposure Notes on charging How to care for the microphone and receiver Licenses Trademarks Troubleshooting Troubleshooting Pair the microphone and receiver again There is acoustic feedback Restart the microphone or receiver Specifications Specifications 5-066-054-11(1) Copyright 2025 Sony Corporation...

  • Page 3: Parts And Controls

    Help Guide Wireless Microphone UO-ULTMIC1 Parts and controls Microphone power button Power indicator Charge indicator ® DC input port (USB Type-C Receiver power button Power indicator Charge indicator DC input port (USB Type-C) Standard plug (Φ 6.3 mm)
  • Page 4 Related Topic About the indicators 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 5 Help Guide Wireless Microphone UO-ULTMIC1 Charging the microphone and receiver You can charge the microphone and receiver by connecting a commercially available USB AC adaptor and the supplied USB Type-C cable to a power outlet. When using the microphone and receiver for the first time, charge them for at least 1 hour before turning on the power.
  • Page 6 The charge indicators on the microphone and receiver light up in orange while charging is in progress. The indicators turn off when charging is complete. It takes approximately 2.5 hours (*) to fully charge the built-in rechargeable battery from an empty state when the microphone or receiver is turned off.
  • Page 7 When charging the microphone or receiver via a speaker, be sure to connect or disconnect the USB cable while the speaker is turned off. Related Topic Parts and controls Notes on charging 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 8 5 minutes have passed with no audio input or handling while the microphone is connected to the receiver. The built-in rechargeable battery is fully discharged. Receiver 5 minutes have passed while waiting for a connection with the microphone. 5 minutes have passed in pairing mode. The built-in rechargeable battery is fully discharged. 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 9 Help Guide Wireless Microphone UO-ULTMIC1 Using the microphone with a speaker Connect the receiver and microphone, and output the audio from the speaker. The following speakers have been confirmed to be compatible with the microphone and receiver. (*1) (*2) Speakers in the ULT POWER SOUND series that are equipped with a microphone jack (Φ 6.3 mm).

  • Page 10: After Use

    Press and hold the power button on the receiver for about 2 seconds. When both the microphone and receiver are turned on, both power indicators will flash slowly in white. Once the connection is complete, the power indicators will switch from flashing to lit. (*) (*) The color and flashing pattern of the indicators may vary depending on the remaining built-in battery power.
  • Page 11 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 12 (*) If the remaining built-in battery power is low, the power indicator flashes in orange. For more details, see “About the indicators.” Hint The setting is retained on the receiver even when the receiver is turned off. Related Topic Parts and controls 5-066-054-11(1) Copyright 2025 Sony Corporation...

  • Page 13: About The Indicators

    Help Guide Wireless Microphone UO-ULTMIC1 About the indicators Charge indicator (orange) Depending on the charging status of the microphone or receiver, the indicator will light up or turn off as follows. Unlit Battery charging is complete. Battery charging is in progress.
  • Page 14 Disconnect the USB cable, wait for a while, and then restart the receiver. For more details, see “Notes flashing (*) charging.” (*) The remaining built-in battery power does not affect the indicator's color, and it flashes orange. Related Topic Parts and controls 5-066-054-11(1) Copyright 2025 Sony Corporation...

  • Page 15: Other Notes

    Help Guide Wireless Microphone UO-ULTMIC1 Precautions On safety Refer to the supplied Reference Guide. The nameplate and important information concerning safety are attached in the following locations: Microphone: the unit side, inside the cover at the bottom of the unit...
  • Page 16 If you have any questions or problems concerning this microphone or receiver that are not covered in this manual, please consult Sony support contact or your nearest Sony dealer. 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 17 Help Guide Wireless Microphone UO-ULTMIC1 To prevent burning or malfunction caused by exposure to water The microphone and receiver are not designed to be waterproof. Depending on how they are used, water may get inside, potentially causing fire, electric shock, or malfunction.
  • Page 18 If the microphone or receiver gets wet or dirty, see “In case of water exposure” and clean them as described before use. 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 19 If the port of the microphone or receiver become dirty, clean it with a dry, soft cloth. If cracks or deformation are observed, avoid using the microphone or receiver in places where it may get wet, consult Sony support contact or your nearest Sony dealer.
  • Page 20 5-066-054-11(1) Copyright 2025 Sony Corporation...

  • Page 21: Notes On Charging

    The built-in rechargeable battery has a limited lifespan. With repeated use and over time, the battery capacity gradually decreases. If you feel that the usage time becomes extremely short even after a full charge, consult Sony support contact or your nearest Sony dealer.
  • Page 22 If an abnormality is detected, disconnect the USB cable and wait for a while. Then, press and hold the power button on the microphone or receiver for about 10 seconds to restart it. If the issue persists, consult Sony support contact or your nearest Sony dealer.
  • Page 23 If you use a disinfectant wipe, use one with an alcohol concentration of 60% or less. After wiping, be sure to finish off with a dry, soft cloth. 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 24 Help Guide Wireless Microphone UO-ULTMIC1 Licenses Services offered by third parties may be changed, suspended, or terminated without prior notice. Sony does not bear any responsibility in these sorts of situations. 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 25 USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum. All other trademarks and registered trademarks are trademarks or registered trademarks of their respective holders. In this manual, ™ and ® marks are not specified. 5-066-054-11(1) Copyright 2025 Sony Corporation...

  • Page 26: Troubleshooting

    4. Should any problems persist, consult Sony support contact below or your nearest Sony dealer. https://www.sony.net/support-contact Note If repairs are necessary, bring the microphones, receiver, and all cables together to Sony support contact or your nearest Sony dealer. Related Topic...
  • Page 27 Help Guide Wireless Microphone UO-ULTMIC1 Pair the microphone and receiver again At the time of purchase, the microphone and receiver are already paired. When you turn on both the microphone and receiver, they will automatically connect. If the microphone and receiver do not connect and both power indicators continue to flash in white (*) after turning on them, pair the microphone and receiver again.
  • Page 28 Related Topic Parts and controls 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 29 If you move the microphone closer to the speaker, acoustic feedback may occur. When this happens, depending on the volume of the speaker, the speaker may automatically turn off due to the product protection function. In this case, wait for a while before turning the speaker back on. 5-066-054-11(1) Copyright 2025 Sony Corporation...
  • Page 30 Help Guide Wireless Microphone UO-ULTMIC1 Restart the microphone or receiver In the following situations, press and hold the power button on the microphone or receiver for about 10 seconds to restart the microphone or receiver. The microphone or receiver does not function properly even after turning it on.
  • Page 31 5-066-054-11(1) Copyright 2025 Sony Corporation...

  • Page 32: Specifications

    Help Guide Wireless Microphone UO-ULTMIC1 Specifications Microphone (transmitter) Communication specification Frequency band 2.4 GHz band (2.400 0 GHz - 2.483 5 GHz) Operating frequency / Maximum output power 2 400 MHz - 2 483.5 MHz / < 10.0 dBm Microphone...

  • Page 33: Operating Temperatures

    For information on the charging time and battery hours of the built-in rechargeable battery, see “Charging the microphone and receiver.” Note Design and specifications are subject to change without notice. Refer to the supplied Reference Guide, which may contain specification information not listed above. 5-066-054-11(1) Copyright 2025 Sony Corporation...
