- Page 1 All manuals and user guides at all-guides.com Ericsson G30 / G35 Fixed Wireless Terminal for GSM Mobile Networks User Guide EN-LZT 151 233 FWT User ... Monday, May 21, 2007 16:48 page 1 Magenta Magenta Yellow Yellow Black Black Cyan...
- Page 2 All manuals and user guides at all-guides.com EN/LZT 151 233 R1D © Ericsson AB 2006 – All Rights Reserved EN-LZT 151 233 FWT User ... Monday, May 21, 2007 16:48 page 2 Magenta Magenta Yellow Yellow Black Black Cyan Cyan...
-
Page 3: Table Of Contents
Fixed Wireless Terminal........ 6 Installation ........... 9 Connecting Devices to the FWT....15 Advanced Features........20 Troubleshooting......... 29 Technical Data........... 33 Accessories ..........36 Product Care and Safety......38 Warranty............ 42 Glossary ............ 45 Index ............47 Fixed Wireless Terminal: G30 & G35... -
Page 4: Welcome
All manuals and user guides at all-guides.com Welcome Welcome to the User Guide for the G30 / G35 Fixed Wireless Terminal. Important information: Some of the services described in this guide might not be supported by all networks. Please, contact your network operator for information on different network ser- vices operational in your GSM network. -
Page 5: Copyright
Declaration of Conformity Hereby, Ericsson Enterprise AB declares that this product is in confor- mity with the requirements and other relevant provisions of the European R&TTE directive 1999/5/EC. -
Page 6: Fixed Wireless Terminal
The FWT features the latest technology, which makes it perfect for eve- ryday communication: • Available in 2 dual-band GSM models (GSM 850/1900 or GSM 900/1800. • Telephone line providing high quality speech. • Battery back-up (optional). • PBX connectivity (only on the G35 model). Fixed Wireless Terminal: G30 & G35... -
Page 7: Supplied Parts
1. FWT unit 2. Antenna 3. 4 x mounting screws 4. Power cable (USA, UK, EU or AUS) 5. AC/DC adapter 6. Wall mount bracket 7. Telephone cable 8. Quick Guide and User Guide manuals Fixed Wireless Terminal: G30 & G35... - Page 8 All manuals and user guides at all-guides.com External Connector and Indicators Fixed Wireless Terminal: G30 & G35...
-
Page 9: Assembly
You need to follow these steps before you install the FWT on the wall and finalize all connections. Warning: The FWT should be switched off before inserting or removing your SIM card or connecting any devices to the FWT. Assembly 1. Connect the antenna. Fixed Wireless Terminal: G30 & G35... -
Page 10: Connecting A Telephone To The Fwt
5. Replace the front cover. Connecting a telephone to the FWT Connect an analog telephone to the line interface (RJ11) of the FWT. Important: You may have to use this telephone to enter the PIN code. Fixed Wireless Terminal: G30 & G35... -
Page 11: Switch On The Fwt
After you have switched on your FWT and entered the PIN, the FWT automatically searches for a network. When a network is found, the Radio LED is on or flashes depending on the GSM signal strength. Fixed Wireless Terminal: G30 & G35... -
Page 12: Fwt Location
• Do not install the FWT on walls or in rooms that contain large amounts of metal, steel or wiring. • Do not expose the FWT to extreme temperatures (near radiators, cooling vents, etc). Fixed Wireless Terminal: G30 & G35... - Page 13 Warning: Once you have fixed the FWT to the wall and switched it on, check the final status of the LEDs. If either one is off, then there is a problem with the power supply or the GSM signal. Fixed Wireless Terminal: G30 & G35...
- Page 14 Note: If you want to remove the FWT from the wall bracket, then you have to press the tab (step 1) as indicated in the following picture and then slide the FWT upwards (step 2). Fixed Wireless Terminal: G30 & G35...
-
Page 15: Connecting Devices To The Fwt
The devices must be connected in paral- lel. You can connect the devices directly to the FWT telephone line con- nector (RJ11) or make an internal telephone wiring, use RJ11 splitters or similar connectors. Fixed Wireless Terminal: G30 & G35... -
Page 16: Checking The Connections
(3) Fixed Line devices can be connected in parallel. The FWT provides a single telephone line, which means that only one communication can take place at a time, in the same way as an ordinary fixed line. Fixed Wireless Terminal: G30 & G35... -
Page 17: Connecting The Fwt To A Pbx
The PBX must provide analog trunks. • One position of the trunk must be assigned to each FWT. • The trunk card must support either Busy Tone Detection (BTD) or Polarity Reversal Detection on answer and release. Fixed Wireless Terminal: G30 & G35... - Page 18 FWT trunk if you are using a Least Cost Routing (LCR) programmed PBX. Once LCR is programmed, make a call to a mobile telephone number. See if the call is established through the FWT and check the speech quality. Fixed Wireless Terminal: G30 & G35...
-
Page 19: Using Telephones
Please refer to the topic Advanced Features documented on page 20 for more de- tailed information. Please refer to the topic Audible Tones documented on page 32 for more detailed information. Fixed Wireless Terminal: G30 & G35... -
Page 20: Advanced Features
To manage diversion With function ... Dial ... You will hear ... of calls ... Activate **21*phone_number# 1 beep Deactivate ##21# 3 beeps Always 1 beep if activated Check status *#21# 3 beeps if deactivated Fixed Wireless Terminal: G30 & G35... -
Page 21: Call Barring
Note: These dialing sequences may vary depending on your network operator. If these do not work, please consult your net- work operator or check the user guide provided with your sub- scription. Fixed Wireless Terminal: G30 & G35... -
Page 22: Multiparty Calls
You can also set up a conference call to have a joint conversation with up to four people. Fixed Wireless Terminal: G30 & G35... -
Page 23: Call Waiting Service
To end the ongoing call and answer the waiting call: press R1. Note: If you hang up the telephone, you will also end the ongoing call and the telephone will ring again so that you can answer the waiting call as a normal call. Fixed Wireless Terminal: G30 & G35... -
Page 24: Conference Calls
Put the ongoing call on hold (press R) and dial the B-number. • Now you can connect this new call, which is ongoing, with the call you have put on hold, but abandon the conversation yourself. To do this, press R4. Fixed Wireless Terminal: G30 & G35... -
Page 25: Abbreviated Dialing
Call your voice mail number in order to receive the voice mail message. Note: This service may vary depending on your network operator. If these do not work, please consult your network operator or check the user guide provided with your subscription. Fixed Wireless Terminal: G30 & G35... -
Page 26: Sending Tone Signals
(1 or 2). Warning: These dialing sequences may vary depending on your network operator. If these do not work, please consult your net- work operator or check the user guide provided with your sub- scription. Fixed Wireless Terminal: G30 & G35... -
Page 27: Sim Card Security
FWT with the following sequence: **04*OLD_PIN*NEW_PIN*NEW_PIN# Note: If instead of hearing 3 beeps you can hear a deep tone, this means that there has been an error in the activation or the deacti- vation. Fixed Wireless Terminal: G30 & G35... -
Page 28: To Unblock Your Sim Card
**05*PUK*NEW_PIN*NEW_PIN# Note: If instead of hearing 3 beeps you can hear a deep tone, this means that there has been an error in the activation or the deacti- vation. Fixed Wireless Terminal: G30 & G35... -
Page 29: Troubleshooting
2 - - - - - - - - Good Green 3 - - - - - - - - - - - - Very good Green Continuous - - - - - - - - - Excellent Fixed Wireless Terminal: G30 & G35... - Page 30 The following table summarizes the different operating status of your FWT depending on the LEDs, and what to do if a problem is encoun- tered. If the problem persists, please contact your distributor or network operator. Fixed Wireless Terminal: G30 & G35...
- Page 31 AC outlet that the FWT is connected to Check the alarm status table Alarm status above. Both LEDs Flashing The FWT is blocked or it has Contact your distributor or (simultaneously) an internal fault network operator for assistance. Fixed Wireless Terminal: G30 & G35...
-
Page 32: Audible Tones
Positive 1 beep Subscriber service successfully activated or positive interrogation indication. Negative 3 beeps Negative interrogation indication. Error 1 deep tone Subscriber service not activated or programming procedure not successfully performed. Fixed Wireless Terminal: G30 & G35... -
Page 33: Technical Data
Power class 1 GSM 1900 Frequencies: TX 1850-1910 MHz, RX 1930-1990 MHz. RF power: Maximum 1 W (30 dBm) Power class 1 Speech codec: Full Rate, Enhanced Full Rate, Half Rate and Adaptive Multi-Rate (AMR) Fixed Wireless Terminal: G30 & G35... -
Page 34: Basic Kit
Dual band antennas depending on model types: e.g. model types FWT G30a / G35a (American) cover the frequencies of 850/1900 MHz and model types FWT G30e / G35e (European) cover the fre- quencies of 900/1800 MHz • Characteristics: omni directional Fixed Wireless Terminal: G30 & G35... -
Page 35: Environmental Conditions
Available plugs: EU, UK, USA, and AU Environmental Conditions • Operating Temperature: -10ºC to +55ºC • Operating Humidity: 20 – 75 % • Storage Temperature: -40ºC to +85ºC • Storage Humidity: 5 - 95% Fixed Wireless Terminal: G30 & G35... -
Page 36: Accessories
Please refer to the topic Product Care and Safety docu- mented on page 37 for more detailed information. Note: only an Ericsson approved battery must be used (part number BKB 201 005). Battery Cable The battery cable is used to connect the backup battery to the FWT. -
Page 37: Battery
The key is inserted into the “keyhole” at the bottom of the FWT between the unit and the wall mounting bracket. It releases the FWT unit from the wall mounting bracket Fixed Wireless Terminal: G30 & G35... -
Page 38: Product Care And Safety
Only Certified Service Centers should perform service. • Do not use any accessories other than those approved by Ericsson. Use of non-Ericsson original, or non-Ericsson approved accesso- ries, may result in loss of performance, damage to the product, fire, electric shock or injury and may violate regulations. -
Page 39: Radio Wave Exposure Information
European Committee for Electrotechnical Standardization (CENELEC). With the antenna solutions recommended by Ericsson, the maximum radio wave exposure is below the limit in the international safety guide- lines within a few centimeters from the antenna. Consequently, for rec- ommended placement of the terminal and antenna, the radio wave ex- posure levels are below the limits. -
Page 40: Personal Medical Devices
Make sure the cord is positioned so that it will not be stepped on, tripped over or otherwise subjected to damage or stress. Children DO NOT ALLOW CHILDREN TO PLAY WITH YOUR FWT SINCE IT CONTAINS SMALL PARTS THAT COULD BECOME DETACHED AND CREATE A CHOKING HAZARD. Fixed Wireless Terminal: G30 & G35... -
Page 41: Accessing The Battery Compartment
Accessing the battery compartment This label appears under the battery compartment indicat- ing that the terminal should always be switched off before attempting to access the battery compartment. Fixed Wireless Terminal: G30 & G35... -
Page 42: Warranty
• Read the Guidelines for safe and efficient use. • Read all of the terms and conditions of the Ericsson Warranty listed below. • Save your original receipt, this is necessary for warranty repair claims. Should your Ericsson Product need warranty service, you should return it to the dealer from whom it was purchased or con- tact your local Ericsson helpdesk for further information. -
Page 43: Conditions
All manuals and user guides at all-guides.com For efficiency purposes, Customers are reminded that should their Erics- son Product need warranty service, they return it to the dealer from which it was purchased or call their local Ericsson helpdesk for further information on warranty claims. Conditions 1. - Page 44 This warranty gives specific legal rights, and depending on the country, other rights may be available as well. Fixed Wireless Terminal: G30 & G35...
-
Page 45: Glossary
Personal Identity Number. This is the number you get from your network operator and which you need to access the network. It will prevent the SIM card to be used by unauthorized people. Fixed Wireless Terminal: G30 & G35... - Page 46 This is the line provided by the FWT (RJ11 connector) that behaves in the same way as the ordinary fixed line. Telephone Line Wiring This is the cable layout that has to be available in order to distribute telephone lines within a house or office. Fixed Wireless Terminal: G30 & G35...
-
Page 47: Index
Making a Second Call, 23 Mechanical Antitheft Key, 37 DC/DC Power Converter, 37 Mechanical Antitheft Lock, 37 Declaration of Conformity, 5 Minute Minder, 26 Disposal of the product, 4 Moving or Storing the FWT, 41 Multiparty Calls, 22 Fixed Wireless Terminal: G30 & G35... - Page 48 To Change your PIN, 27 To Manage your SIM Card, 27 To Unblock your SIM Card, 27 Troubleshooting, 29 Using telephones, 19 Voice Mail, 25 Wall mounting, 13 Warranty, 5, 42 Welcome, 4 What Ericsson will do, 42 Fixed Wireless Terminal: G30 & G35...
- Page 49 All manuals and user guides at all-guides.com EN-LZT 151 233 FWT User ... Monday, May 21, 2007 16:48 page 3 Magenta Magenta Yellow Yellow Black Black Cyan Cyan...
- Page 50 All manuals and user guides at all-guides.com Ericsson is shaping the future of Mobile and Broadband Internet communications through its continuous technology leadership. Providing innovative solutions in more than 140 countries, Ericsson is helping to create the most powerful communication companies in the world.
