Summary of Contents for Ventrac Canopy

  • Page 1 Operator’s Manual Canopy *09.10216* 00 09.10216 00 Original Instructions (EN)
  • Page 2: Reader Comments

    Reader Comments Ventrac maintains a continuous effort to improve the quality and usefulness of its publications. To do this effectively, we encourage user feedback. Please comment on the completeness, accuracy, organization, usability, and readability of this manual by an email to techpubs@ventrac.com.
  • Page 3: Table Of Contents

    Optional Light Switches....................4–3 Chapter 5: Operation....................... 5–1 Before Operation........................5–2 Daily Inspection ........................ 5–2 Chapter 6: Maintenance ......................6–1 Cleaning and Maintaining the Canopy................6–2 Chapter 7: Warranty ........................ 7–1 Limited Warranty — Ventrac Commercial Equipment..........7–2 09.10216 00...
  • Page 4 Page 4 09.10216 00...
  • Page 5 Chapter 1 Introduction Table of Contents Intended Use..............................1–2 Product Description ..........................1–2 Getting Help .............................. 1–2 Why do I Need an Operator’s Manual? ....................1–2 Manual Conventions ........................... 1–3 Safety Alert Classifications ........................1–3 09.10216 00 Page 1–1 Introduction...
  • Page 6: Intended Use

    The canopy attaches to the Ventrac traction unit, offering shade for the operator and protection from the elements. Optional features include a 3-speed downdraft fan kit to keep the operator cool, a strobe light kit with lights at all four corners of the canopy, and a front work light kit...
  • Page 7: Manual Conventions

    Manual Conventions This manual identifies potential hazards and has safety messages identified by the safety-alert symbol, which signals a hazard that may cause serious injury or death if you do not follow the recommended precautions. G405934 This manual uses 2 words to highlight information. Important calls attention to special mechanical information and Note emphasizes general information worthy of special attention.
  • Page 8 Introduction: Manual Conventions Page 1–4 09.10216 00...
  • Page 9 Chapter 2 Safety Table of Contents General Safety.............................. 2–2 Training Required ............................ 2–2 Operation Safety ............................2–2 Maintenance Safety..........................2–5 Canopy Safety .............................. 2–7 09.10216 00 Page 2–1 Safety...
  • Page 10: General Safety

    General Safety Training Required • The owner of this machine is solely responsible for properly training the operators. • The owner/operator is solely responsible for the operation of this machine and for the prevention of accidents or injuries occurring to him/herself, other people, or property.
  • Page 11 Operation Safety (continued) • Always be alert to what is happening around you, but do not lose focus on the task you are performing. Always look in the direction the machine is moving. • Look behind and down before backing up to be sure of a clear path. •...
  • Page 12 Operation Safety (continued) • Equipment can cause serious injury and/or death when improperly used. Before operating, know and understand the operation and safety of the machine and the attachment being used. • Do not operate the machine if you are not in good physical and mental health, if you will be distracted by personal devices, or if you are under the influence of any substance which might impair your decisions, dexterity, or judgment.
  • Page 13: Maintenance Safety

    • When new components are installed, be sure that the current safety decals are affixed to the replacement components. • If any component requires replacement, use only original Ventrac replacement parts. • Always turn the battery disconnect to the O position or disconnect the battery before performing any repairs.
  • Page 14 Maintenance Safety (continued) • Do not touch the engine, the muffler, or other exhaust components while the engine is running or immediately after stopping the engine. These areas may be hot enough to cause a burn. • Allow the engine to cool before storing and do not store near an open flame. •...
  • Page 15: Canopy Safety

    Canopy Safety The canopy reduces the slope rating of the traction unit by 5 degrees. Refer the traction unit Operator’s Manual for the machine slope rating and slope operation information. 09.10216 00 Page 2–7 Safety: Canopy Safety...
  • Page 16 Safety: Canopy Safety Page 2–8 09.10216 00...
  • Page 17: Chapter 3: Setup

    Chapter 3 Setup Table of Contents Before Setup ..............................3–2 Installing the Roll Bar Lock Brackets....................... 3–3 Installing the Canopy........................... 3–5 09.10216 00 Page 3–1 Setup...
  • Page 18: Before Setup

    If the mounting stud on the work light does not fit in the mounting hole in the canopy mount plate , either drill the hole to fit the light stud or replace the canopy mount plates with the mount plates from the original rear work light kit.
  • Page 19: Installing The Roll Bar Lock Brackets

    Installing the Roll Bar Lock Brackets Parts Required Part Number Quantity Description KN-1339 Plate, Roll Bar Lock KN-6053 Bracket, Roll Bar Lock RH KN-6055 Bracket, Roll Bar Lock LH KN-1338 Spacer, 1/2 ID x 1–1/8 OD x 3/8 T 90.0512–2 Bolt, 5/16–18 x 1–1/2 Tap 99.SF05 Nut, SRF 5/16–18 USS...
  • Page 20 5. Insert a 1/2 inch flat washer between the upper and lower roll bar hinge plates. Install the right roll bar lock bracket onto the right roll bar hinge using a 1/2 x 1–3/4 inch bolt and flat washer. Secure with a flange nut but do not tighten.
  • Page 21: Installing The Canopy

    3/8 inch locking flange nuts but do not tighten. 3. Center the mount frame on the roll bar and tighten the eight 3/8 inch locking flange nuts evenly on the U-bolts until they are torqued to 42 N·m (31 ft-lb). 09.10216 00 Page 3–5 Setup: Installing the Canopy...
  • Page 22 5. Install the canopy frame mounts onto the canopy frame using 3/8 x 3/4 inch flange bolts and flange nuts. Torque to 42 N·m (31 ft-lb). G546021 6. Have a helper to assist in lifting the canopy into position.
  • Page 23: Product Overview

    Chapter 4 Product Overview Table of Contents Attachments/Accessories .......................... 4–2 Operational Controls ........................... 4–3 Optional Fan Switch ..........................4–3 Optional Light Switches.......................... 4–3 09.10216 00 Page 4–1 Product Overview...
  • Page 24: Attachments/Accessories

    Attachments/Accessories A selection of Ventrac approved attachments and accessories is available for use with the machine to enhance and expand its capabilities. Contact your Authorized Service Dealer or authorized Ventrac distributor or go to www.Ventrac.com for a list of all approved attachments and accessories.
  • Page 25: Operational Controls

    Operational Controls Optional Fan Switch Rotate the fan switch to select Low , Medium , or High speed. Rotate the switch to the O position to turn off the fan. Optional Light Switches Refer to the traction unit Operator’s Manual for the locations of the strobe light and work light switches.
  • Page 26 Product Overview: Operational Controls Page 4–4 09.10216 00...
  • Page 27: Chapter 5: Operation

    Chapter 5 Operation Table of Contents Before Operation............................5–2 Daily Inspection ............................5–2 09.10216 00 Page 5–1 Operation...
  • Page 28: Before Operation

    1. Park the machine on a level surface, engage the parking brake, and remove the key from the ignition. 2. Inspect the traction unit in accordance with the traction unit Operator’s Manual. 3. Perform a visual inspection of the canopy. Replace any missing or damaged components before operating the machine. Operation: Before Operation Page 5–2...
  • Page 29: Chapter 6: Maintenance

    Chapter 6 Maintenance Table of Contents Cleaning and Maintaining the Canopy....................6–2 09.10216 00 Page 6–1 Maintenance...
  • Page 30: Cleaning And Maintaining The Canopy

    If any component requires replacement, use only original Ventrac replacement parts. 1. Clean or wash the canopy after each use to remove dust, grass clippings, and other debris. 2. Inspect the painted components for chips, scratches, or rust. Clean and touch up the surfaces as needed.
  • Page 31: Chapter 7: Warranty

    Chapter 7 Warranty Table of Contents Limited Warranty — Ventrac Commercial Equipment................. 7–2 09.10216 00 Page 7–1 Warranty...
  • Page 32: Limited Warranty - Ventrac Commercial Equipment

    4000 Series Tractors and Attachments 2–year All Ventrac add-on kits and accessories such as: 3-point hitch, 12V front & rear power outlets, foot pedal, dual wheel kit, etc., will be covered under the above warranty periods provided they are installed by an Authorized Ventrac Dealer. This warranty may be transferred and will carry the remainder of the warranty starting from the original purchase/registration date with the dealership and/or V.P.I.
  • Page 33 (i) damage or defects due to or arising out of repair of Ventrac equipment by person or persons other than an authorized Ventrac service dealer or the installation of parts other than genuine Ventrac parts or Ventrac recommended parts.
  • Page 34 This warranty applies to all Ventrac commercial equipment sold by Venture Products Inc. Warranty: Limited Warranty — Ventrac Commercial Page 7–4 09.10216 00 Equipment...
  • Page 35 Notes:...
