California Faucets StyleTherm TO-TH2L Series Installation Instructions

1/2” thermostatic valve with dual volume control trim

Advertisement

Quick Links

TO-TH2L/THC2L/THF2L/THO2L-XX
½" Thermostatic Valve with Dual Volume Control Trim
CALIFORNIA FAUCETS RECOMMENDS THAT ALL PLUMBING PRODUCTS BE INSTALLED
IMPORTANT: Instructions to the Installer
Please read these instructions, fill in blanks below, and then give
these instructions to the end user.
WARNING: Risk of Scalding
This valve MUST have the TEMPERATURE SETTING verified during
installations. The INSTALLER is responsible for installing the valve
and setting of water temperature in accordance with these instructions.
THIS THERMOSTATIC VALVE HAS BEEN PRESET
BY
OF
TO A MAXIMUM DISCHARGE TEMPERATURE OF ______°F.
ANY CHANGES TO THIS SETTING MAY INCREASE THE
DISCHARGE TEMPERATURE AND COULD RISK SCALDING OF
END USER.
DATE
CAUTION: Danger of scald injury.
recalibrated to provide higher temperature water. This valve has been
preset at the factory to provide a range of water temperatures. Any
change in settings or water inlet conditions from those used during
calibration at the factory may raise the outlet temperature and may
cause scalding. The responsibility for the proper installation and any
recalibration of this valve lies with the installer.
TO-TH2L-XX_ii_250115
StyleTherm
Installation Instructions
BY A LICENSED PROFESSIONAL
Valve can be
®
THT52-R
(ROUGH)
THT52D2-R
(ROUGH)
Pg 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the StyleTherm TO-TH2L Series and is the answer not in the manual?

Questions and answers

Summary of Contents for California Faucets StyleTherm TO-TH2L Series

  • Page 1 TO-TH2L/THC2L/THF2L/THO2L-XX ½” Thermostatic Valve with Dual Volume Control Trim Installation Instructions CALIFORNIA FAUCETS RECOMMENDS THAT ALL PLUMBING PRODUCTS BE INSTALLED BY A LICENSED PROFESSIONAL IMPORTANT: Instructions to the Installer Please read these instructions, fill in blanks below, and then give these instructions to the end user.
  • Page 2 TEMPERATURE SETTING • Remove SCREW (2), WASHER (3), MUDGUARD (4) from installed VALVE (1) • Push plastic TEMPERATURE LIMIT STOP (6) onto THERMOSTATIC CARTRIDGE (7) as shown • Temporarily place BONNET onto THERMOSTATIC CARTRIDGE STEM (7a) • Place STEM (19) onto STOP/VOLUME CONTROL (19a) and using PHILLIPS SCREWDRIVER (19C) secure STEM (19) with SCREW (19b) •...
  • Page 3 INSTALL TRIM Finished Wall WARNING: If distance between finish wall & end of ALL THREAD (10a) is less than 1-5/16”, an extension kit (not included) MUST be used; DO NOT loosen PACKING NUT 1-5/16” (10) to extend length as this will cause valve to not operate (SEE WARNING) properly &...
  • Page 4 MAINTENANCE The thermostatic cartridge has built-in screens to prevent debris from affecting proper operation of anti- scald protection. Debris may build up on screens that will affect water flow and will require occasional service. Thermostatic Cartridge Service • Loosen all SETSCREWS (14), then remove HANDLE (13), VOLUME CONTROL HANDLE (13a), SCREW (12), BONNET (8), SLEEVE (11) and FACEPLATE (9)
