PPHP 37UB: 1200 Watt Wireless BT Loudspeaker PA Cabinet
Speaker Features:
• Loudspeaker PA System
• Rugged, Durable & Reliable Sound
• Wireless BT Music Streaming Ability
• Speaker System: 12" Woofer, 1.34" Tweeter
• Compression Driver with Titanium Diaphragm
• 2-Way Full Range Audio Projection
• 1/4" Jack, XLR Microphone Input
• 1/4" Jack, XLR, RCA Input
• XLR Line Out
• Connect & Stream Audio from External Devices
• USB Flash Drive & SD Memory Card Readers
• Digital LCD Display
• Rear Panel Rotary Dial & Button Control Center
• Master Volume, Mid, Treble, Bass Adjustable, Line Volume Mic Volume
• Integrated Carry Handles
• Heat sink with fan for cooling
• 35mm Speaker Stand Mount Compatible
• Heavy Duty Engineered ABS Housing
MP3 Audio Recording Ability:
• Short Press in BT Mode to Enter the recording function
• Record Audio as Streamed through the Speaker System
• Ability to Record Vocals via BT and FM
• Records to USB Flash & SD Memory Card
• Audio File Type Created: .WAV
• Easy Transfer to PC & Mac
4
www.PyleUSA.com
Subwoofer:
• Size: 30.5 cm/12" inch
• Material: Stamped Steel Basket
• lmpendence: 4Ohm
• Magnet: 50 oz.
• Voice Coil: 60mm, 2.5"
• Sensitivity: 97dB
• Frequency Response: 45Hz - 4kHz
Tweeter:
• Size: 3.4 cm/1.34" -inch
• Material: Titanium
• lmpendence: 8 Ohm
• Sensitivity: 11 0dB
• Voice Coil: Kapton
• Frequency Response: 600Hz-20kHz
Technical Specs:
• Max Power Output:1200 Watt
• lmpendence: 4 Ohm
• Digital Audio File Compatibility: MP3, WMA
• Maximum SD/USB Flash Memory Support: 32GB
• XLR and 1 /4" TS/Unbalanced with 3.5 TRS Stereo jack with RCA
• T.H.D.: <1%
• S/N Ratio: 74dB
• Power Supply: 110/220V, Selectable
• Dimensions (L x W x H): 34 x 31 x 57 cm/13.5" x 12.2" x 22.6" inches
