Summary of Contents for BAVARIAN SIMTEC Omega Pro V2
- Page 1 Owners Manual D E S I G N E D & M A N U F A C T U R E D IN B A V A R I A omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 2 As you explore the exceptional features of your new Omega Pro V2, know that a reliable team is always available to assist you. Our seasoned customer relations experts are here to assist with any inquiries, ensuring that your experience is nothing short of extraordinary. Thank you once again for choosing us. Embrace the thrill, conquer the track, and keep on racing with unwavering passion.
- Page 3 5. RGB LED Buttons [10x] 6. Thumb-Encoder with RGB LED Lettering [6x] 7. Silicone Handles [2x] 8. 7-Way Multi Switch [2x] 9. Gorilla-Glass Frame with laser-engraved Logo 10. AdaptiveBeamTec 11. Multi-Selector omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
-
Page 4: Rear View
1. 6061 cnc’d aluminum construction 2. Quick Action Buttons [2x] 3. N52 Magnetic Shifter + N52 Pull Paddle [2x] 4. Magnetic Contactless Clutch [2x] 5. Internal Connector 6. Cable Connector 7. Mounting Plate omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page... - Page 5 Omega Pro V2 Mounting to Wheelbase Each BavarianSimTec Omega Pro V2 steering wheel comes with our Mounting Plate featuring a 50.8 and 70 mm Pitch Circle Diameter [PCD], compatible with most hubs sharing the same specification. Select the appropriate PCD for your Quick Release or Hub and securely attach it to the Mounting Plate with the supplied screws.
- Page 6 USB Connection & Software Setup We strongly recommend the following connection method before proceeding: ● PC -> Powered USB Hub -> BST USB Cable -> Omega Pro V2 Or BST - QR ● Without an adequate power supply, you may experience unstable performance and diminished LED brightness.
-
Page 7: Add Device
Omega Pro V2 Add Device 1. Go to Devices 2. Click Add Device omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page... - Page 8 Omega Pro V2 Select Omega Pro V2 3. Click BavarianSimTec in the side panel menu 4. Select BavarianSimTec Omega Pro V2 omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 9 Omega Pro V2 Overview 5. Multi-Link-Selector BRGT mapping 6. Edit Button & Lettering Color (next page) 7. Change the Dashboard to BavarianSimTec Omega Pro omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 10 Omega Pro V2 8. Edit Button & Lettering Color 9. To change AdaptiveBeamTec colors click Edit Profile omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 11 Omega Pro V2 10. Click Settings 11. Change the matching HEX color code omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 12 Omega Pro V2 Setup EditMode Click Screen Settings Make sure the “BavarianSimTec Omega EditMode” is selected omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 13 THE EDITMODE WILL ONLY APPEAR WHEN THE DASH HAS BEEN SET AS MENTIONED ON PAGE 12 Press & Hold for 3 seconds to enter the EditMode Press to exit the EditMode omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 14 The assigned Thumb Encoders will then switch their output signal based on the position of the central Multi-Switch. EditMode Dashboard Scroll the bottom left or right Thumb Encoder to change the selected link position. omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 15 We recommend using the "ABS & TC" profile for Encoder Mode and the "12 POS Profile" for 12-Position Mode. EditMode Dashboard Press the left or right AdaptiveBeamTec switch to toggle between the two modes. omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 16 Omega Pro V2 Clutch Settings Change Clutch Mode +/- 1 +/- 10 Change Master Clutch Calibrate Clutch and follow the Dash instructions omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
-
Page 17: Replacing Labels
We recommend pre-heating the sticker using a blow torch at a temperature not exceeding 100°C, ensuring that the heat is directed solely at the sticker. ● When using tweezers to remove the sticker, take care to avoid contact with the anodized aluminum surface, as any scratching may result in permanent damage. omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page... - Page 18 Pinch through the decal right where the text is. Underneath the text, there’s an empty channel. After piercing through, angle your tweezers slightly and carefully pull the decal out. ● (Optional) Clean any leftover adhesive using a bit of IPA alcohol. ● Apply the new decal omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 19 Pinch through the decal right where the text is. Underneath the text, there’s an empty channel. After piercing through, angle your tweezers slightly and carefully pull the decal out. ● (Optional) Clean any leftover adhesive using a bit of IPA alcohol. ● Apply the new decal omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
- Page 20 Pinch through the decal right where the text is. Underneath the text, there’s an empty channel. After piercing through, angle your tweezers slightly and carefully pull the decal out. ● (Optional) Clean any leftover adhesive using a bit of IPA alcohol. ● Apply the new decal omega pro v2 owners manual rev. 1.0 / 18.12.2024 Page...
-
Page 21: Troubleshooting
To ensure proper operation, it is essential to maintain a clean, reliable USB data signal and minimize Electro Magnetic Interference (EMI) from other devices. ● Connect the BST Omega Pro V2 via a powered USB hub or directly to your computer. ● Avoid using excessively long USB extension cables, as data quality degrades with length. - Page 22 ● DO NOT open the BST Omega Pro V2. ● The BST Omega Pro V2 and its components are intended solely for use as a USB input device on a computer. They must not be used in a real vehicle. The manufacturer is not liable for any damages resulting from improper use of the product.
-
Page 23: Warranty
Warranty Operating Environment and Safe Storage Conditions ● Temperature: 15°C – 35°C, with non-condensing humidity. ● Avoid exposing the BST Omega Pro V2 or any parts to direct sunlight or moisture. ● Intended for indoor use and storage only. Warranty The product includes a 2-year warranty, except in the following situations: ●...
