  • Page 1 1WMPD4003956...
  • Page 2 Cautions ・ Read carefully before using this product. ・ Place this manual with reach of this product.

  • Page 3: Examining Contents In Package

    Introduction ▲Introduction▼ Thank you very much for purchasing the Charge Amplifier AG3103. Prior to using this product, please carefully read the instruction manual so that you can correctly use it. This instruction manual provides information necessary for you to safely and correctly operate the product.

  • Page 4: Safety Measures

    Safety measures Be sure to observe the following precautions when using this amplifier. The warranty does not cover damages resulting from actions that go against instructions, cautions, or warnings mentioned in this manual. To safely use the amplifier, the following statements are used in this manual to call the readers' attention.
  • Page 5 WARNING ● Power supply Be sure to check that the power supply is within the rating of this product before turning it on. To prevent electric shock or fire, be sure to correctly use the power cable and connection cable provided by A&D. ●...
  • Page 6 CAUTION ● Caution in handling When using this product, always follow the precautions below. 1) Limiting users Avoid use by anyone other than those who know how to operate this product. 2) Storage and usage environment for this product The storage temperature of this product is -20 to 70 °C, and the storage humidity is 10 to 90%. During hot seasons in particular, do not store this product in a place where it is exposed to long-term sunlight or where the temperature becomes excessively high (such as in a car).

  • Page 7: Caution In Handling

    Caution in handling Read the manual carefully before using this product. In the sensor check function of this product, a check signal (up to about 0.9 Vp-p) is applied to the sensor. Do not use if sensor damage is suspected. Also, if the sensor cable common wire (negative) is connected to the object to be measured through the sensor case, the voltage is also applied to the object to be measured.

  • Page 8: Warranty････････････････････6

    When connecting a microdot connector to the input connector, depending on the cable used, it may be necessary to remove the rubber ring attached to the seat of the input connector (INT) of the main unit. This product is equipped with flash memory to save setting values, so no battery replacement is required.

  • Page 9: When Disposing Of The Used Product

    When disposing of the used product In the European Union EU-wide legislation as implemented in each Member State requires that used electrical and electronic products carrying this mark (left) must be disposed of separately from normal household waste. This includes electrical accessories, such as chargers or AC adaptors.

  • Page 10: Table Of Contents

    Table of contents Introduction･･････････････････1 Examining contents in package･････････1 Notice･････････････････････1 Safety measures Safety measures･･････････････････2 Warning･･････････････････････3 Caution･･････････････････････4 Caution in handling Caution in handling･････････････････5 Warranty Warranty････････････････････6 Limited warranty････････････････････6 When disposing of the used product When disposing of the used product････････7 Table of contents ････････････････････8 to 10 1.
  • Page 11 3. Preparation for measurement 3.1 Cable connections･････････････3-1 3-1-1 Connecting the input cables･･･････････3-1 3-1-2 Connecting the power supply and output cables･････3-1 3-1-3 Connecting the output cable･･･････････3-2 to 3-3 3.2 Operation of sensor check function････････3-4 3.3 The case････････････3-5 3-3-1 Parts of the case････････････3-5 3-3-2 Using the case･････････････3-5 to 3-6 3-3-3 Dissipating heat for case mounting･････3-7 4.
  • Page 12 7. Specifications 7.Specifications････････････････････7-1 to 7-3 8. References 8.1 Frequency characteristics and phase property･････････8-1 to 8-2 8.2 Cable list･････････････8-3 to 8-4 8.3 External dimensions･･･････････････8-5 8-3-1 The unit･･････････････8-5 8-3-2 Panel cutout dimensions････････････8-6 8-3-3 Benchtop case･･･････････8-7 8-3-4 Rackmount case･･････････8-8 8-3-5 Fan unit･････････････8-9...

  • Page 13: Overview

    8-channel bench top case Can be operated/synchronized Rackmount case AS16-107 8-channel rackmount case with other cases. * The optional cases above can be used for both the AG3103 and the strain amplifier series (AS1603/AS1703/AS1803R). 1.3 Accessories  Output cord (0311-2057) x 1 ...

  • Page 14: Block Diagram Of Measurement･･････1-2

    Digital display Low frequency waveform Pen-type oscilloscope Piezoelectric recording (DC acceleration to 120 Hz) sensor X-Y recorder Drawing AG3103 High bandwidth Acceleration waveform (AC OUT/ sensor with Thermal dot recorder DC OUT) recording (DC built-in amplifier to 20 kHz) High speed...

  • Page 15: Part Names And Functions

    2. Part names and functions (10) (11) (12) (13) (15) (14) (16) (17) (18) 2.1 Names and functions of parts on front panel Name Function Model AG model number 17-dot LED monitor meter Checks the output of AC OUT 4 . The green LED at the center illuminates when the output is within ±100 mV.
  • Page 16 Name Function Sensor check (SENSOR CHECK) When the switch is pressed, a calibration voltage is applied to the sensor and the signal from the sensor is measured to automatically detect the presence of disconnection occurring between the sensor and the input connector 1 on the back of this amplifier.
  • Page 17 Name Function Displays the sensitivity of the sensor. The displayed Sensor sensitivity display value is in the range of 0.010 to 999. For switching, use knob (12). Calibration voltage application switch This is the switch for calibration signal output. On the ON side, a sine wave with a full scale voltage of 10 V (CAL) (single amplitude) and a frequency of 80 Hz is output...

  • Page 18: Names And Functions Of Parts On Rear Panel･･･････2-4 To

    (10) (11) (12) (13) (15) (14) (16) (17) (18) 2.2 Names and functions of parts on rear panel Name Function Input connector for piezoelectric Connects to the cable from a piezoelectric acceleration sensor. This is the dedicated input acceleration sensor connector for a microdot connector (10-32 pitch coaxial receptacle).
  • Page 19 Name Function Interface connector (I/F) This connector is the electrical interface between the amplifier and the optional case. Connecting the CAL terminal (I/F:1) to the GND terminal (I/F pin: 7) applies the calibration value. The calibration value is applied when either this terminal or CAL switch (14) turns on. Similarly, connecting the KEY LOCK terminal (I/F: 6) to the GND terminal (I/F: 7) locks each setting switch.

  • Page 20: Sensor Sensitivity (Sens) Setting････2-6 To

    2.3 Sensor sensitivity (SENS) setting [Setting example: 1.00 to 9.99 pC/m/s Press sensor sensitivity setting knob (12). The second LED from the left The leftmost LED flashes. Turn knob (12) flashes. Turn knob (12) to to display "0." and "_". Select "_", then select "1", then press the knob press the knob (12).
  • Page 21 [Setting example: 0.100 to 0.999 pC/m/s Press sensor sensitivity setting knob (12). The second LED from the left The leftmost LED flashes. Turn knob (12) flashes. Turn knob (12) to select "5", then press knob to display "0." and "_". Select "0.", then press knob (12).

  • Page 23: Preparation For Measurement

    ３. Preparation for measurement 3.1 Cable connections 3-1-1 Connecting the input cables Main unit rear panel Piezoelectric acceleration sensor Acceleration sensor with built-in amplifier Current-driven charge converter Piezoelectric acceleration sensor Fig. 3-1 Input connections 3-1-2 Connecting the power supply and output cables 1) Connect the power cord for 100 V AC (0311-5112 for 110 V AC or more), 200 V AC, or 12V DC according to the power source to be used.

  • Page 24: Connecting The Output Cable･･･････････3-2 To

    3-1-3 Connecting the output cable This amplifier is equipped with two kinds of connection, AC OUT and DC OUT. They are both for connection to a voltage input device, such as a data recorder, thermal dot recorder, or oscilloscope. 1) AC OUT The output voltage and current of this output are ±10 V/±5 mA (2 kΩ...
  • Page 25 Note the following points when connecting to a data recorder. a) For direct connection A data recorder allowing 20 Vp-p (±10 V) or greater input level power application can be directly connected. b) For Input requiring a voltage divider circuit A data recorder whose input level is ±1 V requires a voltage divider circuit.

  • Page 26: Operation Of Sensor Check Function････････3-4

    3.2 Operation of sensor check function [ Caution ] [ Caution ] sensor check function If the sensor is connected applies a signal (up to approx. 0.9 through a sensor case to the Vp-p) to the sensor. Do not use object being measured,...

  • Page 27: The Case････････････3-5

    (See Fig. 3-7.) Note that the BAL switch and negative CAL application switch do not operate with the AG3103 because the AG3103 is not equipped with a balancing function and negative calibration value application function.
  • Page 28 The same applies when multiple units are connected. Table 3-2 Operation of each switch of the case Switch on the front of the case AG3103 AUTO No operation All channels, CAL...

  • Page 29: Dissipating Heat For Case Mounting･････3-7

    3-3-3 Dissipating heat for case mounting A) When installing one rackmount case Do not place the rackmount case, which has no feet, directly on the surface CAUTION of a desk, floor, etc. Heat that cannot be dissipated may cause a malfunction.

  • Page 31: How To Measure

    ４. How to measure 4 . 1 Checking before measurement Be sure to check the following points in the table below before measuring. Item Points to check Remarks Use within the specification range of • Intrusion of noise the sensor, and secure the mounting •...
  • Page 32 4-2-3 Setting the range Operate the range setting switch (8) according to the acceleration to be measured. When an input signal of the setting range value is input, the output voltage of this unit is ±10 V for AC OUT and +7.07 V for DC OUT. The following table shows the measurable acceleration range according to the range setting.

  • Page 33: Maximum Input Charge･･････････････4-3

    135,000 4-2-5 Unit selection The AG3103 can measure not only acceleration but also velocity and displacement. Press the UNIT/RANGE knob (8) to switch to the required unit. The other settings are the same as for acceleration. Since the basic measurement is acceleration, make sure that acceleration can be measured.

  • Page 34: Using The Charge Converter･･････4-4 To

    4-2-8 Using the charge converter When the distance between the piezoelectric accelerometer and the main unit (AG3103) is long, the effect of noise can be reduced by using a charge converter (optional). There are two types of charge converters. The specifications are as follows.
  • Page 35 )". Charge converter Piezoelectric Charge amplifier AP11-903 acceleration (1/10) Output AG3103 Setting gain (0.1 mV/pC) sensor For 100 pC/m/s sensor Set as a 10 mV/m/s acceleration sensor with a built-in amplifier. Fig. 4-2 Connection diagram when using charge converter (AP11-903)

  • Page 36: Reading And Calibration Of Measured Values･･････････4-6

    4.3 Reading and calibration of measured values 4-3-1 How to read measured values The input level can be determined from the output amplitude and input from (7), (9), and (10) on the panel. If the sensor sensitivity of the acceleration sensor to be used is set to the unit, the relationship between the output voltage and the measured acceleration is as follows.
  • Page 37 4-3-3 Calibration 1) When the calibration voltage application switch is used The calibration voltage is output while the calibration voltage application switch is turned to the ON side. The calibration voltage in full scale (AC OUT: 10 Vpk, 20 Vp-p, DC OUT: 7.07 Vrms), 80 Hz sine wave, is output regardless of the range setting and sensor sensitivity setting, so it can be used to set the input range on the load side.
  • Page 38 Cautions 1. Dynamic range Set the measurement range so that the output is below full scale when in acceleration mode. If waveform distortion occurs due to scale over in the acceleration signal, large errors will occur in the velocity and displacement. With this product, when the acceleration signal frequency is about 16 Hz, the amplitude is the same as the acceleration amplitude even if the acceleration, velocity, displacement and UNIT are switched.

  • Page 39: Operation Theory

    ５. Operation theory Unit switching ＬＰＦ ＲＡＮＧＥ SENS ＡＣ　OUT Sensor check Average circuit value ＤＣ　OUT detection circuit Sensor power Carrier filter I/F connector (DC POWER) AC line DC/DC DC/DC AC POWER Primary side filter converter converter -15V Fig. 5-1 Block diagram 5.1 Measurement signal flow The sensor input can be switched with the slide switch on the rear panel.

  • Page 41: Maintenance

    ６. Maintenance 6.1 Items to be checked This product is shipped after strict checks, but abnormal operation may occur due to natural failure of parts, performance degradation caused by deterioration, failure, poor connection, etc. If an abnormal operation occurs, you must identify the cause and take corrective action. If you think that sufficient performance cannot be obtained, check the following contents and also page 4-1.
  • Page 42 Standard capacitor Approx. 10 cm Transmitter Adapter AG3103 AC voltmeter Fig. 6-1 Calibration method With the setup shown in Fig. 6-1, an arbitrary charge can be applied to the input section of this unit. When the capacitor capacity is C (pF), the relationship between the charge Q (pC) and the output voltage...

  • Page 43: How To Replace Fuse･････････6-3

    6.3 How to replace fuse Follow the following fuse replacement procedure. 1． Turn the power switch to off, and then disconnect input and output cables from the amplifier unit. 2． As shown in Figure 6-2, place the unit so that its front faces left, its bottom faces forward, and its rear faces right.

  • Page 44: Changing Ac Power Supply Voltage･･･････････6-4

    6.4 Changing AC power supply voltage Follow the steps below to switch the AC power supply voltage. 1. Turn the power off and disconnect the Rear Front power cord and input/output cable from panel panel the amplifier unit. 2. Remove the cover using two screws (M3) on the top face (Fig.

  • Page 45: Dip Switch

    6.5 Switching special function settings By switching dip switches on the bottom side of the Front side of 本製品正面 the product product, settings for special functions can be made. 本製品背面 Rear side • Sensor check function judgment level setting • Switching the decimal point of digital monitor (3) . Dip switch Fig.

  • Page 47: Specifications

    Sensor sensibility 1.00 to 9.99 pC/m/s : 0.1 to 1,000 mm Sensor sensibility 10.0 to 99.9 pC/m/s : 0.1 to 100 mm Sensor sensibility 100 to 999 pC/m/s : 0.1 to 10 mm Table 7-1 Specification list for AG3103 (1)
  • Page 48 (Input charge: 1,000 pC or less) Maximum input capacity 1 μF (Input charge: 10,000 to 100,000 pC) (Piezoelectric acceleration 0.1 μF (Input charge: 1,000 to 10,000 pC) transducer input) 0.01 μF (Input charge: 1,000 pC or less) Table 7-1 Specification list for AG3103 (2)
  • Page 49 Storage temperature range -20 °C to +70 °C, Within 10% to 90% RH External dimension H143 (±1.0) × W49.5 (±0.5) × D253 (±2.0) mm * Excluding protrusions Weight 1.4 (±0.1) kg Table 7-1 Specification list for AG3103 (3)

  • Page 51: References

    ８. References 8.1 Frequency characteristics and phase property ＡＧ３１０３周波数特性 AG3103: Frequency characteristics Amplitude (dB) 5.000 0.000 -5.000 -10.000 -15.000 -20.000 1000 10000 100000 1000000 周波数(Hz) Frequency (Hz) W/B (dB) HPF　1Hz (dB) HPF　5Hz (dB) LPF　100Hz (dB) LPH　300Hz (dB) LPF　1kHz (dB) LPF　10kHz (dB) LPF　20kHz (dB)
  • Page 52 加速度、速度、変位の特性 Acceleration/Velocity/Displacement characteristics Amplitude (dB) 5.00 0.00 -5.00 -10.00 -15.00 -20.00 -25.00 -30.00 -35.00 -40.00 -45.00 -50.00 1000 10000 100000 周波数(Hz) Frequency (Hz) 加速度(m/s2) 速度(cm/s) 変位(mm) Acceleration (m/s Velocity (cm/s) Displacement (mm)

  • Page 53: Cable List

    8.2 Cable list Cable Shape Pin allocation Remarks Output cable Red: +Output Length: 2 m Type: 0311-2057 (BNC core wire) Metal BNC – alligator (Black mold) Black: clip (+:Red, -:Black) Common The unit: Attached as standard (One piece) Output cable Length: 2 m Type: 47226 Metal BNC –...
  • Page 54 Cable Shape Pin allocation Rem ark s DC power cord Red: DC (+) Length: 2 m For the unit Black: DC (-) D-sub 9pin male Bare Type: AS16-401 Green: Shield wire DC power cord Red: DC (+) Length: 2.5 ｍ For the case Black: DC (-) External diameter of...

  • Page 55: External Dimensions･･･････････････8-5

    8.3 External dimensions 8-3-1 The unit...

  • Page 56: Panel Cutout Dimensions････････････8-6

    8-3-2 Panel cutout dimensions Square hole...

  • Page 57: Benchtop Case･･･････････8-7

    8-3-3 Benchtop case N a m e Type 8CH b encht op case AS16-1 06 462.6...

  • Page 58: Rackmount Case･･････････8-8

    8-3-4 Rackmount case Rack rail Elongate hole...

  • Page 59: Fan Unit･････････････8-9

    8-3-5 Fan unit 8CH rackmount case Case Fan unit...
  • Page 61 To ensure prolonged use A&D Company, Limited. Thank you for purchasing an A&D product. To ensure prolonged use of the product that you have purchased, we offer the following lineup of maintenance services. Warranty Period The warranty period for this product is two years from the date of purchase. In case of a failure, the product will be repaired free of charge (only if the failure is ascribable to the responsibility of A&D).
  • Page 62 Caution (1) This manual may not be reproduced to any form in whole or in part. (2) The contents in this manual may be updated without prior notice. Charge amplifier AG3103 1WMPD4003956 First edition November 2019...
  • Page 64 4.34.25 >MKFVLM.?OJGXOXUS- CSVLMQF.OX- CSO[S 281.1124- @<B<A CJPJTLSRJ; D92E +4, 64:2.7243 =FZ; D92E +4, 64:2.2677 LWWT;00YYY/FFRII/HS/NT0...
