Interface Board for 12G‑SDI Optical Commercial Use
Read before use
For more information regarding the operations of the projector with this
product installed, please refer to the "Operating Instructions – Functional
Manual". For downloading the "Operating Instructions – Functional
Manual", visit the following URL.
https://docs.connect.panasonic.com/projector
Thank you for purchasing this Panasonic product.
■ Before using this product, please read these "Operating Instructions" and
the "Operating Instructions" of the projector carefully and save the manuals
for future use.
■ Before using this product, be sure to read "Read this fi rst!" ( x page 3).
Operating Instructions
ET-MDNFB10
Model No.
Basic Guide
ENGLISH
FRANÇAIS
日本語
ENGLISH
DPQX1448ZC/X1
Advertisement
Table of Contents
Related Manuals for Panasonic ET-MDNFB10
Summary of Contents for Panasonic ET-MDNFB10
- Page 1 Manual”. For downloading the “Operating Instructions – Functional Manual”, visit the following URL. https://docs.connect.panasonic.com/projector Thank you for purchasing this Panasonic product. ■ Before using this product, please read these “Operating Instructions” and the “Operating Instructions” of the projector carefully and save the manuals for future use.
-
Page 2: Table Of Contents
Contents Contents Read this first! Precautions for use Supported projector Supported SFP module Handling of the product Disposal Accessories Part names and functions Installing the Interface Board Before installing or removing the Interface Board How to install the Interface Board How to remove the Interface Board Installing the SFP module How to install the SFP module... -
Page 3: Read This First
Read this first! Read this first! WARNING: Do not spill water on this product or allow this product to get wet. Doing so may cause electric shock, fire, or malfunction due to short circuit or overheating. f Do not place a container with liquid close to this product. f Consult your dealer when liquid such as water is spilled on this product. -
Page 4: Precautions For Use
SFP (Small Form-Factor Pluggable)/SFP+ module (referred to as “SFP module” hereinafter). By installing this product to the projector manufactured by Panasonic Projector & Display Corporation, long-distance transmission of the SDI signal via optical fiber cable will be possible without a separate converter to convert from optical signal to electric signal. -
Page 5: Supported Sfp Module
Confirmation of operation for SFP module from other manufacturer has been performed with the items set independently by Panasonic Projector & Display Corporation, and not all the operations are warranted. For operation or performance problems caused by the SFP module, contact the respective manufacturers. -
Page 6: Accessories
Precautions for use Accessories Make sure that the following accessories are provided with the product. Numbers enclosed in < > show the number of accessories. Port cover <2> Screw <4> (DVHR1128ZA/X1) (XSB3+8FN) (Attached to the product at the time of purchase) Attention f After unpacking the product, discard the packaging material properly. -
Page 7: Part Names And Functions
Precautions for use Part names and functions SFP port 1 Input indicator <SIGNAL> This is the port to install the SFP module This is the indicator to indicate the for receiving. detection state of the video signal. This is illuminated when input of the video SFP port 2 signal is detected in either or both of the This is the port to install the SFP module... -
Page 8: Installing The Interface Board
Installing the Interface Board Installing the Interface Board Requesting a qualified technician to install or remove the Interface Board to the projector is recommended. A malfunction may occur due to static electricity. Consult your dealer. Before installing or removing the Interface Board f Always turn off the power of the projector before installing or removing the Interface Board. -
Page 9: How To Install The Interface Board
Installing the Interface Board How to install the Interface Board Screws (4 locations) Guide groove Screws (4 locations) Salient Slot cover Fig. 1 Fig. 2 Fig. 3 Remove the slot cover. (Fig. 1) f Remove the four screws fixing the slot cover of the projector by rotating counterclockwise with a Phillips screwdriver. -
Page 10: How To Remove The Interface Board
Installing the Interface Board How to remove the Interface Board Handle Fig. 1 Remove the Interface Board. (Fig. 1) f Remove the four screws fixing the Interface Board by rotating counterclockwise with a Phillips screwdriver. The removed screws are used to fix the slot cover. f Hold the handle of the Interface Board and remove it slowly. -
Page 11: Installing The Sfp Module
Installing the SFP module Installing the SFP module This section explains an example of a procedure to install and remove the SFP module. Please also check the operating instructions and setup guide of the SFP module to be installed. How to install the SFP module SFP ports SFP modules Circuit boards... -
Page 12: How To Remove The Sfp Module
Installing the SFP module How to remove the SFP module Latch Lever Lever SFP modules Fig. 1 Fig. 2 Disconnect the optical fiber cable. f If the optical fiber cable is connected to the SFP module, remove the cable while releasing the latch of the optical fiber cable. Release the latch of the SFP module. -
Page 13: Connecting Example
Connecting example Connecting example 12G-SDI signal output compatible device HD-SDI signal, 3G-SDI signal, 6G-SDI signal, or 12G-SDI signal SDI - optical converter Optical fiber cable Note f Prepare the commercially available SFP module and the optical fiber cable required for connection according to the usage, video signal to be input, specification of the external device to be connected, etc. -
Page 14: Specifications
360 ] (12.7 ozs.) Note f “SLOT NX” is a name of the slot unique to Panasonic Projector & Display Corporation supporting the signal input for the 4K image. f For the video signals supported by this Interface Board, refer to “List of compatible signals” in the “Operating Instructions –... - Page 15 Fabricado por: Panasonic Projector & Display Corporation 2-15 Matsuba-cho, Kadoma City, Osaka 571-8503, Japón Importador: Panasonic Connect Europe GmbH Español Hagenauer Strasse 43, 65203 Wiesbaden, Alemania Representante Autorizado para la UE: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburgo, Alemania ENGLISH - 15...
- Page 16 2-15 Matsuba-cho, Kadoma City, Osaka 571-8503, Japon Importateur : Panasonic Connect Europe GmbH Français Hagenauer Strasse 43, 65203 Wiesbaden, Allemagne Représentant autorisé dans l’UE : Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hambourg, Allemagne Arna dhéanamh ag : Panasonic Projector & Display Corporation 2-15 Matsuba-cho, Kadoma City, Osaka 571-8503, An tSeapáin...
- Page 17 2-15 Matsuba-cho, Kadoma City, Osaka 571-8503, Japan Importør: Panasonic Connect Europe GmbH Norsk Hagenauer Strasse 43, 65203 Wiesbaden, Tyskland Autorisert representant i EU: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Tyskland Wyprodukowano przez: Panasonic Projector & Display Corporation...
- Page 18 Manufactured by: Panasonic Projector & Display Corporation 2-15 Matsuba-cho, Kadoma City, Osaka 571-8503, Japan Importer: Panasonic Connect Europe GmbH Hagenauer Strasse 43, 65203 Wiesbaden, Germany Authorized Representative in EU: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Germany Importer for UK:...
