- Page 1 W O R L D C L A S S H I F I O W N E R S M A N U A L I S S U E 1 Active Crossovers: SNAXO 362, SNAXO 242...
-
Page 2: Getting Started
4 Warnings 1 Equipment Installation 5 Connection Normally your Naim equipment will have been installed by the dealer who sold it to you 5.1 mains lead even if you live outside their immediate vicinity. Your dealer is responsible for making 5.2 mains plugs... - Page 3 In most territories a dealer must be prepared to take back improve system performance. any Naim equipment he has sold you if he cannot make it Do not wire voltage dependent resistors or noise work to your satisfaction in your own home. A problem may suppressors into mains plugs.
- Page 4 Should the plug fuse carrier be damaged or lost, the invalidate your guarantee. correct replacement must be obtained from your dealer, or from Naim Audio direct. Do not use the plug until the fuse carrier is replaced. 5.4 plug fuses Replace only with ASTA or BS 1362 approved fuses.
- Page 5 Naim power supply. Connection of power supplies and of some common amplifier options is illustrated in the diagrams starting on Page 5. Contact your dealer or Naim Audio directly for advice on alternative amplifier options. The crossovers will switch on automatically after a short delay when connected to a live power supply.
- Page 6 SNAXO Power Supply Connection 8.1 SNAXO 362 connected to Supercap Power Supply Supercap mains input from preamplifier power supply SNAXO 8.2 SNAXO 242 connected to Hi-Cap Power Supply Hi-cap mains from preamplifier input power supply SNAXO Interconnect Cables cable 4 to 4 pin DIN Link Plug direction 240°...
- Page 7 SNAXO Connection 9.1 SNAXO 362 connected to three NAP 300 Power Amplifiers Notes • Left and right handed DIN to XLR cables are required. • Power amplifier power supplies are not shown. • Connection to three NAP 500s follows the same principle.
- Page 8 SNAXO Connection 9.2 SNAXO 362 connected to three NAP 250 Power Amplifiers SNAXO NAP 250 mains in left right speaker HF speaker HF NAP 250 mains in left right speaker MF speaker MF NAP 250 mains in left right speaker LF speaker LF cable direction...
- Page 9 SNAXO Connection 9.3 SNAXO 242 connected to two NAP 250 Power Amplifiers Note • Connection to two NAP 200s or NAP 150s follows the same principle but with 4 pin DIN to 4 pin DIN cables. SNAXO NAP 250 mains in left right speaker HF...
- Page 10 Declaration of conformity to appropriate standards Manufacturer Naim Audio Limited, Southampton Road, Salisbury, England, SP1 2LN Products SNAXO 362, SNAXO 242 Safety HD 195-S6 EN 60 065 Emissions Tested to: EN 55013 - Sound and television broadcast receivers and associated equipment...
- Page 11 Part No. OWMXO 12-001-0040 Naim Audio Limited, Southampton Road, Salisbury, England SP1 2LN Telephone: +44 (0) 1722 332266 Fax: +44 (0) 1722 412034 www.naim-audio.com Drawing No. NA503001-400...
