- Page 1 HYDROBOX HYDRAULIC MODULE FOR MONOBLOCK HEAT PUMPS HYDRAULIC MODULE - HYDROBOX FOR MONOBLOCK HEAT PUMPS INSTALLATION AND USER MANUAL...
-
Page 2: Table Of Contents
From the beginning of TECHNICAL DATA ....................our company’s operation, we have 4.1. Components of the HYDROBOX THERMATEC hydraulic module: ....placed great emphasis on the design 4.1.1. 3-way switching valve AZV 844 by AFRISO .......... -
Page 3: Safety Symbols
Keep the installation and operation manual for future reference. Pass the manual on to any subsequent owner or user of the HYDROBOX THERMATEC hydraulic module for monoblock heat pumps. During operation of the HYDROBOX THERMATEC hydraulic module system, adhere to applicable safety regulations and principles of occupational health and safety. -
Page 4: Description And Application
The version of the HYDROBOX hydraulic module with an anti-freeze system additionally includes a check valve and a 12V DC emergency pump, as well as a 12V DC power backup system. - Page 5 5 – DHW coil supply. The hydraulic module - HYDOBOX THERMATEC consists of an aluminum structural frame to which the equipment elements have been mounted. The module frame is equipped with wall mounting brackets. To connect the hydraulic module to the heating installation, sets of water connections terminated with external thread G 1 1/4"...
- Page 6 ZP C.W.U ZP C.O. Connection drawing of the Hydraulic Module - HYDOBOX THERMATEC (version with anti-freeze system). HYDROBOX Power supply 400 V AC Control of the flow heater 3 x 2kW/230V HOT WATER TANK...
-
Page 7: Components Of The Hydrobox Thermatec Hydraulic Module
4.1. Components of the HYDROBOX THERMATEC hydraulic module: 4.1.1. 3-way switching valve AZV 844 by AFRISO TECHNICAL DATA: PARAMETER / PART UNIT VALUE / DESCRIPTION Connection external thread 1 1/4” Valve flow rate (Kvs) Maximum pressure differential Maximum working pressure Medium temperature °C... -
Page 8: Magnetic Filter
4.1.3. Flow-through electric heater The flow-through electric heater used in the hydraulic module - HYDOBOX THERMATEC is a heater with a maximum power of 6 kW, consisting of 3 heaters with a power of 2 kW each, powered by 3-phase 230V~ voltage, which can be activated independently or collectively through the control circuit of contactors K1, K2, K3. - Page 9 S303 B16 A 3 x HC 1P/25A 2NO 230V~ CONTROL STRIP Flow-through heater 3 x 2kW, 230V ~ Flow-through heater Control of 3 (230V~ voltage) 2kW electric heater temperature sensor for the heating circuit from the heat pump Control of 2 (230V~ voltage) 2kW electric heater for the heating circuit from the heat pump Control of 1(230V~ voltage) 2kW electric heater for the heating circuit from the heat pump...
-
Page 10: Emergency Pump 12V Dc
4.1.4. Emergency pump 12V DC TECHNICAL DATA UNIT DHW MODULE Voltage 8-24 (standard 12V) Current (at 12V) 1,25 Nominal power Maximum flow rate l/min Connections 2 x1/2’’Gz Brass Maximum pressure Maximum fluid temperature °C 4.1.5. Electrical supply, control, and temperature regulation system for the 12V DC emergency pump with 12V DC emergency backup system TECHNICAL DATA UNIT... -
Page 11: Construction Of The Hydrobox Hydraulic Module
6. ELECTRICAL CONNECTION The hydraulic module - HYDROBOX THERMATEC is equipped with a complete electrical distribution board. The electrical distribution board is equipped with N and PE terminal blocks as well as a 3-phase circuit breaker. Power supply from the main distribution board or the distribution board supplying the heat pump, where a residual current device (RCD) type AC 30 mA is installed, should be connected to the appropriate terminals with a 5 x 2.5 mm²... - Page 12 DESIGNATIONS: L1, L2, L3, N, PE – power supply inlet 3 x 230V~ S1 – three-phase circuit breaker B16A - overload protection for the 3 x 2kW/230V~ flow heater, S2 – single-phase circuit breaker B6A - outlet to the buffer power supply 230V~/12V DC, K1, K2, K3 –...
- Page 13 12V DC thermostat VCX 10x 38- 6 A Emergency pump power supply 12V DC Control diagram of the Hydraulic Module - HYDOBOX THERMATEC (version with antifreeze system). S303 B16 A 3 x HC 1P/25A 2NO 230V~ CONTROL PANEL Flow heater...
-
Page 14: Control Of The Anti-Freeze System
8. SAFETY INFORMATION The HYDROBOX THERMATEC hydraulic module is designed for installation only in closed heating systems, following the appropriate instructions of the heat source used. Depending on the version, the device can be used for heating rooms, cooling rooms, and heating domestic hot water. -
Page 15: Operation
9. OPERATION Before commencing use, it is essential to check the general technical condition of the hydraulic module - HYDROBOX THERMATEC. To do so, please ensure that: The hydraulic module - HYDROBOX THERMATEC has been installed according to the schematic. - Page 16 MANUFACTURER’S STAMP THERMATEC | Home Star sp. z o.o. Office: (+48) 32 722 02 03 HYDRAULIC MODULE Misjonarzy Oblatów MN 20A Mobile Phone: (+48) 533 222 223 HYDROBOX 40-129 Katowice, Polska [Poland] biuro@thermatec.pl www.thermatec.eu | www.thermatec.pl | www.thermatec.cz | www.thermatec.fi | www.thermatec.nl...
