GEYA GPS8-10 Instruction Manual

Voltage / Current Protector GPS8-10
Instruction Manual
Technical parameters
Function
Rated supply voltage
Rated supply frequency
Operation voltage range
Rated operational current
Burden
Over voltage operation value
Under voltage operation value
Over/under voltage action delay
Over current operation value
Over current action delay
Leakage current value
Leakage reclosing count
Power-up delay
Reset time
Measurement error
Electrical life(AC1)
Mechanical life
Operating temperature
Storage temperature
Mounting/DIN rail
Protection degree
Operating position
Overvoltage cathegory
Pollution degree
Dimensions
Weight
Wiring Diagram
GPS8-10U
N 1
N 2
General
■Applications
-Overvoltage, undervoltage, overcurrent and leakage protection for
household equipment, while displaying frequency, power factor, power,
and electricity consumption;.
■ Function Features
-Overvoltage, undervoltage, overcurrent, and leakage protection.
-Special metering chips are used to detect voltage, current, electricity
consumption and power.
-Double bus wiring design stronger ability.
-Over / under voltage value and over-current value can be set.
-Self reset after fault.
-Large color screen display.
-DIN rail mounting.
■Model and connotation
GPS8
GPS8-10
Over voltage, under voltage and over current
AC220V(L-N)
45~65Hz
80V~400V(L-N)
32A,40A,50A,63A,80A（AC1）
AC max.3VA
OFF,230V~300V
140V~210V,OFF
0.1s~10s
1~32A,40A,50A,63A,80A
2s~600s
OFF,10mA~400mA
OFF,1~20,ON
2s~600s
2s~900s
≤1%
4
1×10
1×10
-20℃ ~ +60℃
-35℃ ~ +75℃
Din rail EN/IEC 60715
IP40 for front panel/IP20 terminals
any
82 54 68mm × ×
205g
GPS8-10D
N 2
N 1
GEYA ELECTRICAL CO.,LTD
Add:Wenzhou Brige Industrial Zone,Beibaixiang Town,
Yueqing,Zhejiang,China 325603
Mobile:0086-13567770207
E-mail:sale@cngeya.com
Web:www.geya.net
10
Incoming line mode
U:upper incoming line
D:lower incoming line
Design number
GPS8 Series
Panel Diagram
>U
13
<U
12
>I
11
EL
10
9
8
Press and hold the setting key for 3 seconds to enter the
1
setting. After modifying the setting, press and hold for 3
seconds to save the setting.
2
1.Used to increase the value when setting parameters.
2.Long press for 5 seconds to configure WiFi network.
1.Used to reduce the value when setting parameters.
2.After exiting the setting, it can be used to manually turn
3
on or off the load.
3.If the automatic fault reset function is turned off, this
button can be used for manual reset when the fault occurs.
4
Current value
5
Power
6
Electricity consumption
7
Power factor
8
Frequency
9
Leakage current
10
Leakage fault indication
11
Overcurrent fault indication
12
Overvoltage fault indication
13
Undervoltage fault indication
14
ON/OFF status indication
15
Voltage value
-1-
14
15
M
7 6 5
4
1
2
3
