AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-S500-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
VSX-S500-K
SYXCN8
VSX-S500-K
DLXCN
This service manual should be used together with the following manual(s).
Model No.
VSX-S300-K/SYXCN8
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
Power Requirement
AC 220 V to 230 V
AC 220 V to 240 V
Order No.
RRV4197
VSX-S500-K
Remarks
K-ZZZ SEPT.
ORDER NO.
RRV4228
Remarks
2011 Printed in Japan
Advertisement
Table of Contents
Related Manuals for Pioneer VSX-S500-K
Summary of Contents for Pioneer VSX-S500-K
- Page 1 ORDER NO. RRV4228 VSX-S500-K AUDIO/VIDEO MULTI-CHANNEL RECEIVER VSX-S500-K THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S). Model Type Power Requirement Remarks VSX-S500-K SYXCN8 AC 220 V to 230 V VSX-S500-K DLXCN AC 220 V to 240 V This service manual should be used together with the following manual(s).
-
Page 2: Contrast Of Miscellaneous Parts
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors). 562 x 10 5621 RN1/4PC CONTRAST TABLE VSX-S300-K/SYXCN8, VSX-S500-K/SYXCN8 and VSX-S500-K/DLXCN are constructed the same except for the following: Mark Symbol and Description VSX-S300-K/SYXCN8 VSX-S500-K/SYXCN8 VSX-S500-K/DLXCN Remarks PCB ASSEMBLIES 1..PCB TTL Assy D-AMP... -
Page 3: Exploded Views
EXPLODED VIEWS EXTERIOR SECTION VSX-S500-K... - Page 4 JA1308 JACK,MODULAR Not used G4060RJ450120-IL C1458, C1596, C1686, C1766 Not used D050221081200-IL C1868 Not used D050221081200-IL C1459 Not used D050471081200-IL The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual. VSX-S500-K...
- Page 5 F POWER TRANS ASSY 8208000920021-IL has no service parts. PCB PARTS LIST Mark No. Description Part No. F USB ASSY SEMICONDUCTORS IC 806 J126050000060-IL D 7-9 K005041480030-IL D 3603,3604 K067012020020-IL MISCELLANEOUS JA 3604 CN,PLUG CONTACT G480040040040-IL CAPACITORS C 5,3605 D050221081200-IL VSX-S500-K...
-
Page 6: Schematic Diagram
5 4 3 2 1 (BT656 FORMAT) 10 11 12 13 14 15 16 27MHz clock option TO DMAIN_1 (Z8030) NOTE : PLACE UNDER IP7560 UNDER IP7560 NOTE : PLACE UNDER IP7560 (Z8030) UNDER IP7560 UNDER IP7560 5/6F NOTE : PLACE UNDER IP7560 VSX-S500-K... - Page 7 5/6F D-MAIN ASSY (7028070683010-IL) 5/6F VSX-S500-K...
- Page 8 2.2 D-MAIN ASSY (6/6) 6/6F D-MAIN ASSY (7028070683010-IL) NOTE : PLACE UNPER DDR2 SDRAM 6/6F VSX-S500-K...
- Page 9 6/6F VSX-S500-K...
-
Page 10: Pcb Connection Diagram
2.3 USB ASSY USB ASSY (7028070662010-IL) KDS4148U R3608 100N-K R3609 R3610 R3607 BA05CC0WFP IC806 R3611 CN703 R3612 LUG706 KDS4148U KDS4148U CN244 5/6F 3. PCB CONNECTION DIAGRAM 3.1 USB ASSY SIDE A SIDE A USB ASSY SIDE B SIDE B USB ASSY VSX-S500-K... -
Page 11: Each Setting And Adjustment
U B I COM U PGR A D E COMP L E T E 5. Updating is completed when rebooting is finished, and the GUI menu is displayed. 6. Check that the version of the firmware has been upgraded. VSX-S500-K... - Page 12 CONN E C T I NG Although the same message continues to be displayed until upgrading is finished, upgrading progresses. Wait until the unit is automatically rebooted and the GUI menu is displayed. (About 4-5 minutes) 4. When rebooting is finished, upgrading is completed. VSX-S500-K...
