- Page 1 V-HHBS Barcode Scanner Wireless Function Guide V1.1.1...
- Page 2 • Product information may be updated without prior notice. • All content in this guide is protected by copyright. Unauthorized copying, distribution, or bundling with other products without our written permission is strictly prohibited. Service Information For technical assistance, product support, or repair services, please contact us. www.volcora.com...
- Page 3 Revision Version Description Date V1.0 Initial Version 2022.08.18 Modified default scan mode V1.1 2022.10.19 www.volcora.com...
-
Page 4: Table Of Contents
Table of Content Chapter 1 System Setting ....................6 Query Firmware Version ..................6 Restore Factory Default ................... 6 Query Battery Level ....................6 Beeper ........................7 Beeper Volume ....................7 Beeper Frequency .................... 7 Vibration ........................8 Scanner Sleep Mode ....................8 Chapter 3 Scan Mode .................... - Page 5 Real-Time Mode ..................... 19 Batch Mode ....................20 No-Loss Mode ....................20 Display Stored Data Numbers ................ 20 Clear Stored Data ................... 21 Data Transmission Speed ..................21 BT HID Country Keyboards ................... 22 Chapter 5 Data Format ....................26 Prefix/Suffix ......................
-
Page 6: Chapter 1 System Setting
Chapter 1 System Setting Query Firmware Version Query the wireless module version Query Firmware Version Restore Factory Default Restore Factory Default Query Battery Level Query Battery Level... -
Page 7: Beeper
Beeper Beeper Volume High（default） Medium Mute Beeper Frequency 2K（default） 2.7K... -
Page 8: Vibration
Vibration Optional function, valid for partial products. Enable（default） Disable Scanner Sleep Mode Sleep now No Sleep Sleep in 30S Sleep in 1 Minute Sleep in 2 Minutes Sleep in 5 Minutes（default）... - Page 9 Sleep in 10 Minutes Sleep in 30 Minutes Sleep in 60 Minutes Sleep in 6 hours...
-
Page 10: Chapter 3 Scan Mode
Chapter 3 Scan Mode Trigger Scan Mode Trigger Scan Mode （ default ） Continuous Scan Mode Continuous Scan Mode... -
Page 11: Chapter 4 Wireless Setting
Chapter 4 Wireless Setting Introduction The scanner supports different way for connection with hosts. User can select proper way to connect. Pair with dongle Quick Pair Step 1: Press the button to start the scanner, the indicator light is always on after successful startup; Step 2: Scan the "Quick Pair"... -
Page 12: 2.4G Mode
2.4G Mode 2.4G Mode... -
Page 13: Bluetooth Hid Mode
Bluetooth HID Mode Bluetooth HID mode: match with Android, ios system cell phone or PC terminal with Bluetooth function. Bluetooth HID Mode How to pair Bluetooth method 1: Example A: Press the button to start the scanner, the indicator light is always on after successful start;... -
Page 15: Bluetooth Spp Mode
Bluetooth SPP Mode Bluetooth SPP mode: Android devices or PC-based enterprise or private customized Bluetooth serial software. Bluetooth SPP Mode A: Press the button to start the scanner, the indicator light is always on Example after successful start; B: Scan the barcode of "Bluetooth SPP mode", the indicator light blinks after successfully entering the Bluetooth SPP mode;... - Page 16 D: Click "Barcode Scanner BLE", pairing E: After successful pairing, the buzzer will beep and the blue light will be on at the same time;...
-
Page 17: Android Input Mode
Android Input Mode Only valid for Bluetooth Mode. Android Input Mode USB Virtual COM Only valid for wired connection mode. USB Virtual COM Bluetooth Device Name Set user-specified Bluetooth name. Please proceed with caution before familiarizing yourself with the following instructions. -
Page 18: Query Bluetooth Name
a) The maximum length of the name can only be set to 16 bytes, if the name barcode exceeds 16 bytes, the scanning gun will only take the first 16 bytes as the Bluetooth name. b)Bluetooth complete name includes: Bluetooth name + protocol type, only support modify Bluetooth name. -
Page 19: Bluetooth Hid Keyboard
Bluetooth HID Keyboard This function needs to be valid in ios system when Bluetooth HID connection is successful. HID Keyboard Show/Do not Show Press Trigger Twice to Show/Hide HID Keyboard Disable Data Transmission Mode Real-Time Mode Real-Time Mode... -
Page 20: Batch Mode
Batch Mode If the scanner works beyond the transmission range of the wireless, it is recommended to use the storage mode. In storage mode, the scanner will emit a short tone (low frequency first and then high) while the indicator light blinks once after successful scanning, and the scanned barcode will be automatically stored in the scanner. -
Page 21: Clear Stored Data
upload storage data several times by scanning the "Upload Data". Upload Data When uploading data, please try to make sure that the wireless signal connection is good, or upload with the data cable connected. Clear Stored Data Clear Stored Data Data Transmission Speed If there is missed data on the receiving end, the rate of occurrence should be turned down, which is prone to occur on poorly performing host device. -
Page 22: Bt Hid Country Keyboards
Ultra Low （ only valid for Bluetooth Mode ） BT HID Country Keyboards United State (default) Germany France Spain Italy Japan... - Page 23 International Keyboard Belgium-French Portugal United Kingdom German IOS Brazil-Portuguese Russia Czech Italy 142...
- Page 24 Turkey Q Turkey F Sweden/Finland Mexico-Spanish Denmark Norway Croatia Swiss-German Swiss French...
- Page 25 The Netherlands Hungary Poland Canadian French Argentina (Latin American) Slovak...
-
Page 26: Chapter 5 Data Format
Chapter 5 Data Format Prefix/Suffix To add prefix and suffix, first scan to set prefix or suffix, then scan the corresponding barcode (see appendix for barcode), up to 32 bytes. To cancel prefix and suffix, first scan to set prefix or suffix, then scan to exit setting mode. Add Prefix Add Suffix Character Conversation Set... -
Page 27: Gs Replace Character
Character Conversion Set 1 Character Conversion Set 2 Character Conversion Set 3 GS Replace Character Enable GS Replace Disable GS Replace Hide Decoded Bar Code Data 隐藏条码方法：Scan Hide Front-Segment Decoded Data or Scan Hide Back-Segment Decoded Data to decide that you need to hide front or back segment data, then scan corresponding digital barcodes to hide the data, up to 16 characters can be hided. -
Page 28: Terminator Suffix
Hide Back-Segment Decoded Data Hide 1 Digit Hide 2 Digits Hide 3 Digits Hide 4 Digits Terminator Suffix Carriage Return(default) Line Feed... -
Page 29: Case Conversion
Carriage Return + Line Feed No Terminator Suffix Case Conversion Conversion only affects only scanned bar code data, and does not affect Code ID, suffix, prefix and other appended data. No Case Conversion(default) Convert Case Convert to upper case Convert to lower case... -
Page 30: Transmit Time Before/After Barcode Data
Transmit Time before/after barcode data Transmit Real Time now （relative time） Transmit Time before barcode data （relative time） Transmit Time after barcode data （relative time） Disable (default) -
Page 31: Appendix
Appendix Appendix 1 Control Character Set character set character character character character decimal ASCII Programming Barcode set 1 set 2 set 3 set 4 keypad NULL Home Ctrl+A Alt+001 Enter Ctrl+B Ctrl+B Alt+002 Cap Lock Right Ctrl+C Up Arrow Ctrl+C Alt+003 Arrow *User-specified... - Page 32 Down Enter Enter Ctrl+P Alt+010 Arrow NULL NULL Ctrl+Q Alt+011 NULL NULL Ctrl+R Alt+012 delete Enter Enter Enter Alt+013 Enter Page Up Ctrl+N Alt+014 Insert Page Down Ctrl+O Alt+015 Ctrl+P Alt+016 NULL Ctrl+Q Alt+017 Home Print NULL Ctrl+R Alt+018 Screen Back NULL Ctrl+S...
- Page 33 Ctrl+U Alt+021 Ctrl+V Alt+022 Ctrl+W Alt+023 Ctrl+X Alt+024 Ctrl+Y Alt+025 NULL Ctrl+Z Alt+026 Ctrl+[ Alt+027 ALT+028 Ctrl+\ Alt+028 ALT+029 Ctrl+] Alt+029 NULL Ctrl+^ Alt+030 NULL Ctrl+_ Alt+031...
-
Page 34: Appendix 2 Normal Characters
Appendix 2 Normal Characters decima ASCII Programming Barcodes Space " &... - Page 36 < >...
- Page 42 Ç ç...
