- Page 1 User's Manual Wireless Handheld Barcode Scanner with Stand Models: V-LHHBS-A1B V-LHHBS-A1W Volcora Site Website | www.volcora.com Email | support@volcora.com...
-
Page 3: Notices
BT 2.4G Wireless Barcode Scanner Notices 1. Please read the user manual carefully before using this product. 2. The working voltage of this barcode scanner is 3.3V, charging voltage 5V. Please use our original USB cable to ensure the scanner work properly. 3. -
Page 4: Table Of Contents
BT 2.4G Wireless Barcode Scanner Contents Notices ......................1 Introduction & Features ................3 Application & Parameters ................4 Working Environment & Related Regulations ..........5 Installation of Cable ..................6 Initialization Settings & Version Information ..........7 BluetoothPairing Method ................ -
Page 5: Introduction & Features
BT 2.4G Wireless Barcode Scanner Introduction The series of barcode scanner produced by our company feature as strong light source, enhanced long-distance scanning technology. It can read the damaged, stained and poor printed barcode fast under different ambient light conditions. It is durable in use, since it is protected by the industrial safety technique. -
Page 6: Application & Parameters
BT 2.4G Wireless Barcode Scanner Application ・Applicable to Business (electrical, book, clothing, medicine, cosmetics, etc.), retail industry, postal service, telecommunications industry, warehousing, logistics industry, public security system, customs systems, banking system, medical system. ・Compatible with Microsoft, Android, Linux and other operating systems and Bluetooth protocol ・Support multi-national keyboard language Parameters... -
Page 7: Working Environment & Related Regulations
BT 2.4G Wireless Barcode Scanner Working Environment ・Working Temperature: 32°F to 104°F/0°C to 40°C ・Storage Temperature: -40°F to 140°F/-40°C to 60°C ・Humidity: 5% to 95% relative humidity (no condensation) ・Ruggedness: Resist about 6 times drops from 1.5m to concrete ground ・Ambient Light Immunity: Under normal office and factory ambient lighting conditions, or exposed to the sun wonʼt take any effect to it. -
Page 8: Installation Of Cable
BT 2.4G Wireless Barcode Scanner Installation of Cable Sample graph USB Cable Installation Each barcode scanner is with one USB cable., For connection, please refer to above sample diagram. (!) Noted: Computer host can charge scanner via USB cable and USB cable can also be used as a wire to transmit barcodes. -
Page 9: Initialization Settings & Version Information
BT 2.4G Wireless Barcode Scanner Initialization Settings & Version Information (A) You can scan the setting code "Initialization Settings" to make the scanner back to factory default settings (B) If you have after-sales problems and need to contact our customer service staff, please provide version information by scanning setting code "Version Information"... -
Page 10: Pull Up/Hide Keyboard (Ios System) & Caps Lock Switch & Caps Lock Switch
BT 2.4G Wireless Barcode Scanner Pull Up/Hide Keyboard (iOS System) & Caps Lock Switch Pull up/hide iOS keyboard %%SpecCode1A Double-click to pull up iOS keyboard Double-click to hide iOS keyboard Caps Lock Switch All lowercase All uppercase Do not convert case Case interchange... -
Page 11: 2.4G Wireless Pairing Method
BT 2.4G Wireless Barcode Scanner 2.4G Wireless Pairing Method: (A) Scan the setting code of Dongle. %%SpecCodeA8 (B) Scan the setting code Forced Pairing with Dongle, The scanner will enter pairing state, and the blue light on the left flashes quickly. -
Page 12: Sound/Vibration Setting
BT 2.4G Wireless Barcode Scanner Sound/Vibration Setting Sound OFF Sound ON Vibration OFF (optional) Vibration ON (optional) Sleep Time Setting 1 min 5 min 10 min 30 min Never Sleep Sleep Immediately... -
Page 13: Ending Character Setting
BT 2.4G Wireless Barcode Scanner Ending Character Setting Add CR (Carriage Return) Add LF (Linefeed) Add CR+LF Cancel CR + LF Add TAB... -
Page 14: Keyboard Language Setting
BT 2.4G Wireless Barcode Scanner Keyboard Language Setting English (USA) German French Spanish Italian International Universal Keyboard Janpanese Belgian Portuguese English (UK) Portuguese (Brazil) French (Switzerland) - Page 15 BT 2.4G Wireless Barcode Scanner Russian Czech French (Canada) Hungarian Polish Sweden / Finland Spanish (Mexico) Argentine (Latin America) Norwegian German (Swizerland)
-
Page 16: Transmission Speed Setting & Bluetooth Protocal
BT 2.4G Wireless Barcode Scanner Transmission Speed Setting Choosing the transmission speed according to the receiving speed of the device Fast Middle Slow Super Slow Bluetooth Protocal Bluetooth HID Bluetooth SPP Bluetooth BLE Notes: Scanning any one of above 3 setting codes can make the scanner enter bluetooth pairing status. -
Page 17: Working Modes
BT 2.4G Wireless Barcode Scanner Working Modes Under "Normal Mode", the data of the code you scanned will be transferred to your device via Bluetooth, 2.4G or USB A short and low beep show the data is transferred successfully. If not, the scanner will beep 3 times shortly and lowly. - Page 18 BT 2.4G Wireless Barcode Scanner Scanning following setting code to upload the data you have scanned to your device via Bluetooth, 2.4G wireless or USB. Notes: Making sure that scanner is got connected with your device. After uploading data, the data which have been stored in the scanner will not be deleted from the scanner Upload Data Scanning following setting code to clear all the data which is stored...
-
Page 19: Change Bluetooth Name
BT 2.4G Wireless Barcode Scanner Change Bluetooth Name 1st：Scanning following setting code”Change BT Name” Change BT Name 2nd: Scanning a customized codes which its data is the name you want. You can generate a customized code via barcode generator, like label shop. -
Page 20: Hide Pre-Characters/Post-Characters
BT 2.4G Wireless Barcode Scanner Hide Pre-characters/Post-characters 1st: Scanning following setting code “Hide Pre-characters” or “Hide Post-characters” Hide Pre-characters Hide Post-characters 2nd: Choosing how many characters you need to hide. - Page 21 BT 2.4G Wireless Barcode Scanner Notes: If you need to cancel hiding characters setting, you can scan following setting code Cancel Hiding Pre-characters Cancel Hiding Post-characters...
-
Page 22: Add Time As Prefix Or Suffix & Update Time
BT 2.4G Wireless Barcode Scanner Add Time As Prefix or Suffix (optional) (A) Scanning setting code “Add Time as Prefix”, then there is scanning time in front of barcode data. Add Time as Prefix (B) Scanning setting code "Add Time as Suffix", then there is scanning time behind barcode data. - Page 23 BT 2.4G Wireless Barcode Scanner Update Time (optional) 1st：Making scanner and computer connected via USB cable, and turning on the scanner. 2nd：Finding "Update_Time_V1.1.exe" program in the computer and open it. As following picture show. 3rd: Click “Update Time” Notes: “Update_time_V1.1.exe” program can be downloaded in website: https://share.weiyun.com/508OXFZ, or scanning following QR-code.
-
Page 24: Prefix/Suffix Setting
BT 2.4G Wireless Barcode Scanner Prefix/Suffix Setting The setting prefix and suffix is divided into two parts, displayable characters and controlled characters Part: Displayable characters Step1: Scanning following setting code "Add Prefix" or "Add Suffix" Add Prefix Add Suffix Step 2: Finding the character which you need to add as prefix or suffix in appendix B, and scanning the barcode corresponding to the character. - Page 25 BT 2.4G Wireless Barcode Scanner Character Set 2 Character Set 3 Character Set 4 Step2: Scanning following setting code “Add Prefix” or “Add Suffix” Add Prefix Add Suffix Step 3: Finding the character which you need to add as prefix or suffix in appendix A, and scanning the barcode corresponding to the character.
-
Page 26: 2.4G Wireless Com-Port Mode Setting
BT 2.4G Wireless Barcode Scanner 2.4G Wireless COM-Port Mode Setting Step1: Scanning setting code “COM-Port Mode” COM-Port Mode Step2: Scanning setting code “Enter Pairing Mode” Enter Pairing Mode Step3: Insert the 2.4G wireless receiver into USB port in your device. One beep show that scanner and receiver connected. -
Page 27: Appendixa: Controlled Characters
BT 2.4G Wireless Barcode Scanner AppendixA: Controlled Characters Character Character Character Character Character ASCII Setting Code Set 4 Set 0 Set 1 Set 2 Set 3 NULL Home Ctrl + A Alt + 001 Ctrl + B Ctrl + B Alt + 002 Lock Right... - Page 28 BT 2.4G Wireless Barcode Scanner Character Character Character Character Character ASCII Setting Code Set 4 Set 0 Set 1 Set 2 Set 3 Page Ctrl + N Alt + 014 Insert Page Ctrl + O Alt + 015 Down Ctrl + P Alt +016 NULL Ctrl + Q...
- Page 29 BT 2.4G Wireless Barcode Scanner Character Character Character Character Character ASCII Setting Code Set 4 Set 0 Set 1 Set 2 Set 3 Ctrl + [ Alt + 027 Alt + 028 Ctrl + \ Alt + 028 Alt + 029 Ctrl + ] Alt + 029 NULL...
-
Page 30: Pendixb: Displayable Characters
BT 2.4G Wireless Barcode Scanner AppendixB: Displayable Characters ASCII Setting Code ASCII Setting Code Decimal Decimal Space " &... - Page 31 BT 2.4G Wireless Barcode Scanner ASCII Setting Code ASCII Setting Code Decimal Decimal < >...
- Page 32 BT 2.4G Wireless Barcode Scanner ASCII Setting Code ASCII Setting Code Decimal Decimal...
- Page 33 BT 2.4G Wireless Barcode Scanner ASCII Setting Code ASCII Setting Code Decimal Decimal Ç Ç...
-
Page 34: Faq (Frequently Asked Questions)
BT 2.4G Wireless Barcode Scanner FAQ (Frequently Asked Questions) What should I do if the scanner cannot pair with my Bluetooth device? (A) Making sure the scanner is in the pairing state under the required Bluetooth protocol (B) If the devices have connected successfully with other barcode scanner via Bluetooth, or other devices. -
Page 35: Buzzer Description
BT 2.4G Wireless Barcode Scanner Buzzer description Buzzcr Proformance Introduction One/long beep low to Power on high frequency One/long beep high to Power off low frequency One/short beep low Read a code under normal mode frequency One/short beep low to Read a code under storage mode high frequency One/short beep high to... - Page 36 Battery Display...
