Mosolabs SCE4255W Configuration Manual

Canopy 4g indoor radios
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Moso Canopy 4G Indoor Radios
Model: SCE4255W
Configuration Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCE4255W and is the answer not in the manual?

Questions and answers

Related Manuals for Mosolabs SCE4255W

Summary of Contents for Mosolabs SCE4255W

  • Page 1 Moso Canopy 4G Indoor Radios Model: SCE4255W Configuration Guide...

  • Page 2: Table Of Contents

    EPC CONFIGURATION ............................. 52 ’ C EPC ..........................52 ONNECT TO LOUD LOG MANAGEMENT ............................54 GUI ..............................54 OG FROM ................................54 ET TXT ................................. 55 ET LOG ................................... 55 LEAR TCPDUMP CAPTURE PROCEDURE ........................56 MosoLabs Confidential Property...
  • Page 3 GUI .......................... 56 CPDUMP APTURE ROCEDURE ON ABBREVIATIONS ............................. 57 MosoLabs Confidential Property...

  • Page 4: Introduction

    Notes: If device has more than ONE physical WAN interface, please just select one WAN interface to use. Step 1. Use an RJ45 cable to connect the WAN port of the Moso Canopy to a Router which is connected to Internet or Intranet. MosoLabs Confidential Property...
  • Page 5 Step 2. The WAN port of the Moso Canopy will be able to get one dynamic IP if the router supports DHCP server. Or refer to “Configure Device’s Network” section to setup the WAN port of the Moso Canopy. MosoLabs Confidential Property...

  • Page 6: Access Web

    "Login" button. Please get the general account from MosoLabs team. For testing purposes, the Moso Canopy opens the remote login function temporarily, to determine the IP of the Moso Canopy’s WAN port and to find a PC on the WAN side of the Moso Canopy. Open a web browser on the PC and type the URL https://wan_ip_address and input username and password, and then click "Login"...

  • Page 7: Reset Button

    Press and hold the “reset” button for more than 10 seconds and release it to force the device to factory default. In this process, all LEDs will shut down, then the PWR LED will flash which means the device is rebooting. This takes 2-3 minutes. MosoLabs Confidential Property...

  • Page 8: Device Status Check

    IPSEC state of Moso Canopy device, this page is the default one after login. Visit "LTE State" page under "State" group to check the cell parameters and 2 cell state, neighbor list of Moso Canopy device. MosoLabs Confidential Property...
  • Page 9 The "Cell State" has a total of 11 statuses as follows: Starting L1 Starting Stack Setup S1 S1 Connected Stack Running Pending Down PowerDown L1 Finished L1 Failed None MosoLabs Confidential Property...

  • Page 10: Firmware And Configuration File Management

    Firmware Upgrade This chapter provides details of upgrading the firmware onto the Moso Canopy device. Step 1. Get the new firmware from MosoLabs and store it in the local disk. Step 2. Visit "Firmware Management" page under "Manage" group. Step 3. Click "Select a File" button and select the new firmware restored on the local disk.

  • Page 11: Configuration File Management

    Function 2. Upgrade customized file. Click "Select a File" button and select a customized configuration file stored locally and click "Upload" button and start the configuration upgrade. The Moso Canopy will reboot automatically after upgrading. This will take 3-5 minutes. The customized configuration can be obtained from MosoLabs. MosoLabs Confidential Property...

  • Page 12: Configure Device ' S Network

    Canopy device. The default IPv4 connection type of the Moso Canopy device is "DHCP" which means the Moso Canopy’s WAN is a DHCP client. The Moso Canopy will get the dynamic IP from DHCP server in the network. MosoLabs Confidential Property...
  • Page 13 2. Visit "IPv6 Set" page under "Network set" group and configure the WAN IPv6 address of the Moso Canopy device. MosoLabs Confidential Property...

  • Page 14: Bring Up S1 With Mme

    Modify button to save it to flash. Bring up S1 with MME This section provides details of the configuration of Moso Canopy’s S1, which can support the CA function. 1. Visit "LTE Basic Setting" page under "Manage" group to set Cell parameters. MosoLabs Confidential Property...
  • Page 15 Moso Canopy EIRP = TxPower + 3*CarrierNumber + AntennaGain Tunnel Type: The type of tunnel,such as IPv4,IPSEC MME IP Address: IP of MME PLMNID: PLMN of Moso Canopy TAC: TAC of Moso Canopy Sync Source:The sync type,default is FREE_RUNNING MosoLabs Confidential Property...
  • Page 16 MME ID, number of MME IP, and each MME IP address. Ex.: {{1,1,172.21.143.206},{2,1,172.21.143.220}}.Represents a total of two MMEs configured with MMEID of 1 and 2, and each MME has only one IP, 172.21.143.206 and 172.21.143.220, respectively. 3. Config Multi-MME with one PLMNID MosoLabs Confidential Property...
  • Page 17 172.21.143.220. Cell with PLMNID 11805 will connect to MME ID 1, and cell with 11132 will connect to MME ID 2. 5. eNodeB Type Configuration Visit "FAPControl" page under "FAPService" group to find "FAPService_FAPControl_LTE_X_000E8F_RRMConfig" Object and below parameter. MosoLabs Confidential Property...

  • Page 18: Moso Canopy Output Power

    Moso Canopy Output Power This section provides details of configuration of Moso Canopy’s output power. Bring up S1. 1. Visit "CellConfig" page under "FAPService" group and set ReferenceSignalPower, it's in dBm with a range between -60 and 50. MosoLabs Confidential Property...
  • Page 19 TxPower = ReferenceSignalPower + 31, if Bandwidth = 20MHz. The calculated TxPower will be announced to the UE in packets sent from the small cell device to UE, then the UE will use that value from the Moso Canopy device to perform the communication preparation. MosoLabs Confidential Property...

  • Page 20: Add One Neighbor Cell

    RSTxPower: RS power of neighbor cell. Leave it blank if not knowing this value. Blacklisted: enable it if putting this neighbor cell to black list of HO. TAC/EnbType: not modify it. Data Model Nodes Table Device.Services.FAPService.1.CellConfig.LTE.RAN.NeighborList.LTECell.{i}.Enable Device.Services.FAPService.1.CellConfig.LTE.RAN.NeighborList.LTECell.{i}.Alias Device.Services.FAPService.1.CellConfig.LTE.RAN.NeighborList.LTECell.{i}.MustInclude Device.Services.FAPService.1.CellConfig.LTE.RAN.NeighborList.LTECell.{i}.PLMNID Device.Services.FAPService.1.CellConfig.LTE.RAN.NeighborList.LTECell.{i}.CID Device.Services.FAPService.1.CellConfig.LTE.RAN.NeighborList.LTECell.{i}.EUTRACarrierARFCN Device.Services.FAPService.1.CellConfig.LTE.RAN.NeighborList.LTECell.{i}.X_000E8F_EnbType Device.Services.FAPService.1.CellConfig.LTE.RAN.NeighborList.LTECell.{i}.X_000E8F_EnbAddr MosoLabs Confidential Property...

  • Page 21: Gps Sync

    "LTE Basic Setting" page under "Manage" group and find "Cell Configuration" object to enable "Auto Internal Neighbors" as below: GPS Sync This section provides details of the configuration of GPS. MosoLabs Confidential Property...
  • Page 22 GPS sync. The Moso Canopy device starts to do GPS Sync. It will take a couple of minutes to run GPS Sync function. After it's completed, the "LTE State" page shows GPS Sync. Data Model Nodes Table Device.Services.FAPService.1.REM.X_000E8F_tfcsManagerConfig.primSrc MosoLabs Confidential Property...

  • Page 23: 1588 Sync

    If selected, enable Unicast mode, otherwise use Multicast mode. Default is Multicast. X_000E8F_PTPConfigUnicastMaster: If unicast mode is enabled, configure PTP master related parameters. The format is as below: <address><priority><log_sync_interval><log_delay_req_interval> <address>: PTP master IP address <priority>: 0 <log_sync_interval>: 0 <log_delay_req_interval>: 0 MosoLabs Confidential Property...
  • Page 24 3. Reboot the Moso Canopy device and visit "LTEState" page under "State" group to check the status of 1588 sync. The following screen will be shown when sync is OK. Data Model Nodes Table Device.Services.FAPService.1.REM.X_000E8F_tfcsManagerConfig.primSrc Device.Services.FAPService.1.REM.LTE.X_000E8F_PTP_Cfg.* MosoLabs Confidential Property...

  • Page 25: Ipsec Configuration

    UseForCWMP: Check this field if CWMP should use IPsec tunnel IPsec Mode: There are 4 IPsec modes,PSK\CERT\AKA\CUSTOM. The required CERT is chosen here. Certificate Subject: Cert subject SecGW Server: SecGWServer's IP Address SecGW ID: The id of SecGW, use %any when unsure MosoLabs Confidential Property...
  • Page 26 Then click on the Save button. If you want to set IPSec mode to PSK, you can refer to below configuration. 3. Modify the Tunnel type a) Enter Manage->LTE Basic Setting->S1 Configuration, Modify the value as follows: Tunnel Type: IPSEC MosoLabs Confidential Property...
  • Page 27 4. Check IPSec Status You can view Cell status in LTE_status.htm webpage, if Cell is up, the status will be "Stack Running". You can view IPsec status in TR098->SysPara-> Device.X_000E8F_DeviceFeature.SystemParams.RunControl.Service. If the IPsec is up, the status will be "running". MosoLabs Confidential Property...

  • Page 28: Multiple Ipsec Configuration

    The Multiple IPSec is to set up two IPSec at the same time. And each IPSec has a different purpose, for example, the first IPSec is used to connect the first MME, and the second IPSec is used to connect the second MME. 1. Visit "Manage" page under "IPsec Configuration" group to configure the two IPsec tunnels. MosoLabs Confidential Property...
  • Page 29 2. Visit "State" -> "System Status" page to check IPSec status. The page will be shown in the following figure if the configuration is correct. System Status Page The 1 ConnName is configured with FMT_000000000000000_0000_00. The 2 ConnName is configured with FMT_000000000000000_0000_01. 3. Visit "Manage"->"LTE Basic Setting" to configure the tunnel of S1 connection. MosoLabs Confidential Property...

  • Page 30: Modify Events Threshold

    This section provides details of the configuration of A2 threshold and A5 threshold. 1. Visit "CellConfig" page under "FAPService" group to find "FAPService_CellConfig_LTE_RAN_Mobility_ConnMode_EUTRA" table to set A2ThresholdRSRP 2. In same page and same table, set X_000E8F_INTER_A5Threshold1RSRP and X_000E8F_INTER_A5Threshold2RSRP MosoLabs Confidential Property...

  • Page 31: Configure Sas

    3) select "Certification File" to local cert file. 4) Click "Upload" to Assign cert file. 5) Select "Third Party Certification Service" as SAS. 6) Select "Private Key" to local key file. 7) Click "Upload" to Assign key file. MosoLabs Confidential Property...
  • Page 32 8) Reboot Device and check the "Device.Security Certificate." list in below picture. It will add a new cert. Check the "Subject" value to validate the cert. 9) Configure the "CertSubject" item in table SAS Configuration of Manage->SAS Configuration page with the Subject value see from above setup. See the below Picture. MosoLabs Confidential Property...
  • Page 33 Method(support from FF3922) ManufacturerPrefixEnable(Only the Disable Google platform may need to be enabled) Installation Method Single-step CPI Enable Disable Server https://developer-sc- 02.federatedwireless.com/v1.2/[sample] UserID SDC[sample] ICGGroupId Category ChannelType CertSubject /C=TW/O=Sercomm/OU=WInnForum CBSD Certificate/CN=P27-SCE4255W:%s Location indoor Location Source HeightType AMSL MosoLabs Confidential Property...
  • Page 34 Single step (CPI enable): SAS OAM Configuration Parameter value SAS Enable Enable Method (support from FF3922) ManufacturerPrefixEnable (Only the Disable Google platform needs to be enabled) Installation Method Single-step CPI Enable Enable Server https://developer-sc- 02.federatedwireless.com/v1.2/[sample] UserID SDC[sample] MosoLabs Confidential Property...
  • Page 35 ICGGroupId Category ChannelType CPISignatureData ABCD[sample] CertSubject /C=TW/O=Sercomm/OU=WInnForum CBSD Certificate/CN=P27-SCE4255W:%s Location indoor Location Source HeightType AMSL Multi step: MosoLabs Confidential Property...
  • Page 36 SAS Enable Enable Method (support from FF3922) ManufacturerPrefixEnable (Only the Disable Google platform needs to be enabled) Installation Method Multi-step Server https://developer-sc- 02.federatedwireless.com/v1.2/[sample] UserID SDC[sample] ICGGroupId Category ChannelType CertSubject /C=TW/O=Sercomm/OU=WInnForum CBSD Certificate/CN=P27-SCE4255W:%s Location indoor Location Source HeightType AMSL MosoLabs Confidential Property...
  • Page 37 The value should be "AGL" or "AMSL". AGL height is measured relative to the ground level. AMSL height is measured relative to the mean sea level. Elevation: manually input Elevation Data Model Nodes Table Device.Services.FAPService.1.FAPControl.LTE.X_000E8F_SAS.Enable Device.Services.FAPService.1.FAPControl.LTE.X_000E8F_SAS.Method Device.Services.FAPService.1.FAPControl.LTE.X_000E8F_SAS.ManufacturerPrefixEnable Device.Services.FAPService.1.FAPControl.LTE.X_000E8F_SAS.CPIEnable Device.Services.FAPService.1.FAPControl.LTE.X_000E8F_SAS.Server MosoLabs Confidential Property...

  • Page 38: Setup For S1 Or X2 Handover

    3. Visit "REM" page under "FAPService" group to find "FAPService_REM_LTE" table to set "EUTRACarrierARFCNDLList". This is needed to set ANR frequency. This list is comma-separated (maximum length 256) of strings and each entry is a EARFCN in the DL direction to measure. MosoLabs Confidential Property...
  • Page 39 The PCI range of different type eNB will need to be configured if using ANR to add neighbor cell. Visit "FAPControl" page under "FAPService" group to configure X_000E8F_CSGSmallCellPCIStart and X_000E8F_CSGSmallCellPCIRange. In the following figure, PCI range of Home eNB is from 485 to 503 (both 485 and 503 are included). MosoLabs Confidential Property...
  • Page 40 6. Visit "CellConfig" page under "FAPService" group to find "FAPService_CellConfig_LTE_RAN_Mobility_ConnMode_EUTRA" table to set Inter-frequency handover parameters "A2ThresholdRSRP", "X_000E8F_INTER_A5Threshold1RSRP" and "X_000E8F_INTER_A5Threshold2RSRP". The real value equals to (configuration value - 140)dBm. Ex. A5 threshold1 is 35-140=-105dBm. The A1Threshold couldn't be less than A2Threshold. MosoLabs Confidential Property...

  • Page 41: Son Configuration

    If the detection fails, select the next one in the PCI List, the method is as step two. 1. Visit "REM" page under "FAPService" group and Setting "ScanOnBoot" and "EUTRACarrierARFCNDLList"under "FAPService_REM_LTE". EUTRACarrierARFCNDLList should be Comma-separated EARFCNs list which needs to be scanned before cell is UP. MosoLabs Confidential Property...

  • Page 42: Multiple Source Ip Configuration

    IP addresses in IPSec tunnels to setup the multiple MME. Of course, the administrator can still keep the WAN IP addresses of Moso Canopy to setup the multiple MME. MosoLabs Confidential Property...
  • Page 43 In the red block diagram of above figure, the first cell uses the first MME and IPSec and the second cell uses the second MME and IPSec. 3. Visit "LTE Basic Setting" page under "Manage" group to set carrier number. 4. Visit "LTE Basic Setting" page under "Manage" group to set Tunnel type to be IPSec. MosoLabs Confidential Property...

  • Page 44: Split C/U Plane For Mocn

    The eNB can be configured to different interface IP to make control plane connect to different MMEs and make user plane connect to different SGWs. 1. Visit Manage->LTE Basic Setting page to add Multi MME IP address. MosoLabs Confidential Property...
  • Page 45 2. Visit FAPService->CellConfig page to configure the PLMN according to different MMEs. For explanation of nodes, please refer to section “Bring up S1 with MME.” 3. Visit FAPService->CellConfig page to configure the SGW IP (such as 10.41.3.201,10.41.1.207) and then to enable the function. MosoLabs Confidential Property...

  • Page 46: Cmp Configuration

    ProtoType: The protocol type of customer for theCMPv2, HTTP or HTTPS Recipient: subject of the CMPv2 server certification, used to verify the CMPv2 server CertEncodeMethod: CMPv2 the cert encode method (Optional, or fill in "V_ASN1_APP_CHOOSE"(default)) MosoLabs Confidential Property...

  • Page 47: Kpi Configuration

    1. Visit "FAP_PerfMgmt" page under "FAP" group to the "Device.Security Certificate." Enable: the KPI statistics function is turned on or off. URL: URL is the address of file server for the XML file of KPI statistics upload. MosoLabs Confidential Property...

  • Page 48: Dscp Configuration

    Device.IP.Interface.1.IPv6Address.1.. Normally, you just need to modify "4" to "6". But if your MME IP address type is IPv4, you may need to check this config and make sure it is IPv4. NOTE: Our default value is IPv4. MosoLabs Confidential Property...

  • Page 49: Moso Canopy Nl Syn Configuration

    This section provides details of the configuration of the NL sync. Visit "REM" page under "FAPService" group: 1. Under "FAPService_REM_X_000E8F_tfcsManagerConfig", set primSrc to be NL, and syncMode to be FREQ or PHASE. 2. Under "FAPService_REM_X_000E8F_NlSync", enable EnableSync. MosoLabs Confidential Property...

  • Page 50: Volta Ota Syn Configuration

    Visit "REM" page under "FAPService" group: 1. Enable ScanOnBoot. Enabled means to open the Sniffer function, disabled means to close the sniffer function. Then change REMBandlist and EUTRACarrierARFCNDLList. EUTRACarrierARFCNDLList is the frequency point of the configured sweep frequency. MosoLabs Confidential Property...
  • Page 51 Change PrivateAlgCtrl bit0 to 1，because it means to turn on the synchronization function, on the contrary,bit0 =0 means to turn off the synchronization function. Restart the cell, then you can see the following information. MosoLabs Confidential Property...

  • Page 52: Anr Configuration

    PCI range. If neighbor cell's PCI is in the range of small cell, neighbor cell is home type. If neighbor cell's PCI is out of range of small cell, neighbor cell is macro type. MosoLabs Confidential Property...

  • Page 53: Epc Configuration

    This section provides details of the configuration of the MosoLabs’ Cloud EPC. MosoLabs’ Cloud EPC function should be used only after the discussion with the MosoLab team. 1. Visit "IPSec" page under "Manage" group to set IPSec with certification mode, MosoLabs’...
  • Page 54 MME Port: 36412 3. Refer to “IPsec Configuration” section to check IPsec status after rebooting. The status should indicate OK. 4. Visit "LTEState" page under "State" group to check "Cell State". The status should be "Stack Running" MosoLabs Confidential Property...

  • Page 55: Log Management

    Etc. It will show you enodeb log after you select "enodeb.log" Get txt Log Visit "Manage" page under "Log" group. Select the type of log and then click "Text File Log Download" button. Then you can get txt log you want. MosoLabs Confidential Property...

  • Page 56: Get Log.zip

    Visit "Manage" page under "Log" group to click "Zipped File Log Download" button, then you can get log.zip. Normally, you may need to click "ClearLog" button to clear old log before testing. Clear Log Normally, you may need to click "ClearLog" button to clear old log before testing. MosoLabs Confidential Property...

  • Page 57: Tcpdump Capture Procedure

    Click Start and the following prompt will appear. After confirming the tcpdump command is correct, click Yes button to Start capturing packets. If the command is incorrect, you can click No and re-input the command. Click Stop to stop the tcpdump capture. MosoLabs Confidential Property...
