Pulsar 510 DL PIPE Instruction Manual

SPECS
Size: 1.5 x 3 x 5.5 in (38.2 x 76.6 x 139.4 mm)
Maximum Cartridge Size: 11.5 mm diameter/61 mm length
Battery Capacity: 650 mAh
Voltage: 2.8 V / 3.4 V / 3.8 V
Charging: USB-C
Resistance: 0.8-2.0
Static Current: ≤10uA
POWERING ON/OFF
To turn the device on or off, press the button 5 times. The indicator light will remain on for one second to indicate
the power-on or power-off state. The device does not have auto-shutoff and must be turned off manually.
PRE HEATING
Press the button 2 times within 15 seconds or inhale 2 times quickly to pre-heat the device. Colorful rainbow lights
and a fire icon will flash to indicate that it is pre-heating. The process will be interrupted if you do anything else with
the device while it's pre-heating.
SCREEN DISPLAY
The screen displays the current voltage level, the battery level, and a lightning icon during charging. The screen
turns off after 10 seconds of inactivity.
ADJUST VOLTAGE
Press the button 3 times within 1.5 seconds or inhale 3 times quickly to adjust the voltage. The corresponding light
color for each voltage will flash 3 times when selected.
 2.8 V - Green (L)  3.4 V - Blue (M)
The voltage and battery percentage levels are always on the display screen while the voltage is being adjusted. The
current voltage will flash 3 times and then stay on for 10 seconds.
BATTERY LEVEL INDICATOR
Short press the button to display the current battery level when in normal working mode.
When over 75%, the green light
When between 35-75%, the
When below 35%, the red light
When voltage drops below 3.2 V, the red light will flash 10 times, indicating that the device has entered the standby
state. On the screen display, the voltage level will be shown as 0. The device does not support pass-through use or
fast charging.
INSTRUCTIONS
1. Charge the battery using the provided USB-C cable. Plug into the connector on the bottom of the unit and
attach the cable to a power source. The red light will turn on when it is connected and charging.
2. Allow the battery to fully charge before use. The light will turn green when the device is fully charged. Discon-
nect the device from the cable when it is fully charged.
3. Remove the pipe stem (twist off) and screw in a 510 threaded cartridge of your choice into the bowl of the pipe.
4. Reattach the pipe stem (twist on and lock) and ensure it is firmly connected before use. Use without the stem
for larger cartridges.
5. If the unit is turned off, press the button five times to turn it on.
6. Adjust the voltage by pressing the button 3 times or inhaling on the mouthpiece 3 times. (Green Light = 2.8 V,
Blue Light = 3.4 V, Red Light = 4.0 V)
7. Pre-heat the device by pressing the button 2 times or inhaling on the mouthpiece 2 times. Colorful rainbow
lights will flash to indicate that it is pre-heating.
8. Press and hold the button or inhale slowly to vape. The current voltage light will brighten and remain on while
vaping. The light will gradually fade out when you stop. While vaping, the screen displays the voltage setting
and static current light.
 4.0 V - Red (H)
will turn on for 2 seconds.
blue light will turn on for 2 seconds.
will turn on for 2 seconds.
PulsarShop.com
INSTRUCTION
MANUAL
KIT INCLUDES
1 x Pulsar 510 DL Pipe Battery
1 x USB-C Charging Cable
1 x Matching Stem (replacements sold separately)
PU-0781-24
