- Page 1 4K Floodlight Security Camera Quick Start Guide Model: SWIFI-4KFLOCAM-AU...
-
Page 2: Camera Overview
CAMERA OVERVIEW FRONT VIEW Adjustable floodlights (with brightness control via app) Speaker QR code (for device pairing) Night detection sensor LED indicator Infrared LEDs (for night vision) Passive infrared motion sensor Microphone (bottom) - Page 3 CAMERA OVERVIEW SIDE VIEW Mounting bracket Adjustable camera head Release tab Power cord Pull the rear rubber cover open to access: • MicroSD card slot 32GB card pre-installed, Max. 128GB card supported • Reset button Press and hold for 5 seconds to enter pairing mode...
-
Page 4: Get Started
GET STARTED Wi-Fi Coverage Availability • Before permanently mounting the floodlight camera, it is important to confirm the availability of Wi-Fi and signal strength at the desired installation location. • Please note that Wi-Fi quality can vary significantly at different locations around the home due to environmental factors, such as home construction type and wireless interference from other electronic devices. - Page 5 GET STARTED service app, such as YouTube or Netflix , on your phone. If possible, temporarily pause all online ™ ™ activities, including gaming and video streaming, on all other devices that are connected to your network while testing is performed, as this can affect the connection speed and quality. If you don't experience any video streaming issues (buffering, stuttering, etc), you can proceed with the installation of the floodlight camera.
- Page 6 QR code below to get the app. Open the app and create your Swann Security account by tapping “Not yet registered? Sign Up” at the bottom of the screen. Then, activate your Swann Security account by confirming the verification...
-
Page 7: Mount The Camera
MOUNT THE CAMERA MINIMUM 9CM CLEARANCE FOR OPTIMUM RESULTS, INSTALL UNIT AT LEAST 8 FEET (2.4M) ABOVE THE GROUND. rear view Attaching the camera to • Ensure the bracket is mounted on a secure and stable surface the mounted bracket that can support the full weight of the floodlight camera. - Page 8 MOUNT THE CAMERA IMPORTANT: ENSURE THE INSTALLATION LOCATION IS WITHIN RANGE OF YOUR WI-FI ROUTER BEFORE MOUNTING PERMANENTLY. FOR INFORMATION ON HOW TO CHECK WI-FI COVERAGE, SEE "GETTING STARTED" ON PAGES 4-5. To mount the floodlight camera, follow these steps (refer to page 7 for illustrations and additional notes): Press the release tab on the mounting bracket and slide it out of the base of the floodlight camera.
- Page 9 MOUNT THE CAMERA Wall-Mounted Example Ceiling-Mounted Example TIP: If you have a light switch that controls the floodlight camera, remember not to turn off the switch as this will also turn off the unit. The unit needs to be powered at all times to stay connected to your Wi-Fi. Put a sticker label on the light switch so that people know not to turn it off.
-
Page 10: Set Up The Camera
SET UP THE CAMERA Launch the Swann Security app and sign in. Tap the Pair Device button on the screen (or tap the menu in the top left and select Pair Device). The app will now guide you through the pairing process to icon set up the camera with your Wi-Fi network. - Page 11 THE SWANN SECURITY APP MANUAL To learn more about using the Swann Security app, you can download the Swann Security app manual from the App Menu > User Manual. The manual provides detailed information on how to view camera live video, use 2-way talk, playback and download motion recordings, and configure various camera settings, including light duration, motion detection sensitivity, modes, and more.
-
Page 12: Motion Detection Tips
MOTION DETECTION TIPS Optimising motion detection • The camera’s passive infrared motion sensor detects heat signatures of moving objects. • You’ll generally get good detection results by pointing the camera at an angle where people will be moving across the coverage area (i.e., from left to right or right to left, as shown in the figure on the right). - Page 13 Firmware update in progress Have questions? We're here to assist you! Scan the QR code below to visit the Swann Help Center for technical support, FAQs, guides and help articles related to your product. In addition, you can participate in community forums and access other helpful resources.
- Page 14 NOTES Wi-Fi Connection Notes Camera (MAC) ID (12 alphanumeric characters) (for future device pairing in case QR code label fades) Wi-Fi Router Information Wi-Fi Network Name (2.4 GHz SSID): Wi-Fi Security Key/Password: (case-sensitive) Wi-Fi Extender Information (if any) Wi-Fi Network Name (2.4 GHz SSID): Wi-Fi Security Key/Password: (case-sensitive) Internet Speed Test:...
-
Page 15: General And Safety Information
The content in this guide is for information purposes only and is subject to change without notice. While every effort is made to ensure that this guide is accurate and complete at the time of publication, no liability is assumed for any errors and omissions that may have occurred. For the latest version of this guide, please visit: support.swann.com... - Page 16 SUPPORT.SWANN.COM — FAQs & Help Articles — Manuals, Guides & Videos — Technical Support — Community Forums QSG4KFLOCAMVER1AU © Swann Communications 2023...
