HYXIPOWER HYX-E50-H3 User Manual

High voltage battery

Advertisement

Quick Links

User Manual
HIGH VOLTAGE
BATTERY
HYX-E50-H3 / HYX-E100-H3
Carefully read this battery system user instructions before using.
Read and save these instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYX-E50-H3 and is the answer not in the manual?

Questions and answers

Summary of Contents for HYXIPOWER HYX-E50-H3

  • Page 1 User Manual HIGH VOLTAGE BATTERY HYX-E50-H3 / HYX-E100-H3 Carefully read this battery system user instructions before using. Read and save these instructions.
  • Page 2 This document cannot be copied fully or partially, transferred, or distributed in any form without the prior written permission of ZHEJIANG HYXI TECHNOLOGY CO., LTD (hereinafter referred to as "HYXiPOWER"). TRADEMARKS and other HYXiPOWER trademarks are the trademarks or registered trademarks of HYXiPOWER All other trademarks mentioned herein are the properties of their respective owners.
  • Page 3: Table Of Contents

    CONTENTS User Manual CONTENTS 1. Product Introduction ------------------------------------------------------------------------------------------------1 1.1 Scope of Application ------------------------------------------------------------------------------------------------------------- 1 1.2 Overview of Product Naming Rules ------------------------------------------------------------------------------------------- 1 2. Safety Instructions ------------------------------------------------------------------------------------------------- 2 2.1 Interpretation of The Logo ----------------------------------------------------------------------------------------------------- 2 2.2 Precautions/Environmental Requirements ----------------------------------------------------------------------------------- 2 2.3 Risk Factors ---------------------------------------------------------------------------------------------------------------------- 3 2.4 Response to Emergency Situations -------------------------------------------------------------------------------------------3 2.5 Notes ------------------------------------------------------------------------------------------------------------------------------4 2.6 Personnel Requirements ------------------------------------------------------------------------------------------------------- 4...
  • Page 4 CONTENTS User Manual 5.2.3 Battery-INV -------------------------------------------------------------------------------------------------------------------- 17 5.2.4 Switch on when system connected --------------------------------------------------------------------------------------- 18 5.2.5 Parallel Connection ---------------------------------------------------------------------------------------------------------- 19 6. LED indicator description ---------------------------------------------------------------------------------------- 20 6.1 LED display and system status -----------------------------------------------------------------------------------------------20 6.2 SOC lamp and capacity correspondence ---------------------------------------------------------------------------------- 20 7.
  • Page 5: Product Introduction

    1.2 Overview of Product Naming Rules HYX - E 100 - H 3 Brand Name Battery Model Capacity High Voltage HYXiPOWER energy storage high voltage can provide a variety of operating modes according to different needs, self-generation, peak-shaving, battery priority, etc.
  • Page 6: Safety Instructions

    The "NOTICE", "CAUTION", "WARNING" and "DANGER" items in this manual do not represent all safety items to be observed. They are in addition to all safety precautions. HYXiPOWER shall not be liable for any violation of the general safety requirements or for any violation of the safety standards for the design, manufacture and use of the equipment.
  • Page 7: Risk Factors

    2. Safety Instructions User Manual 2.3 Risk Factors Risks of Explosion: • Do not subject the battery module to heavy impacts; • Do not crush or puncture the battery module; • Do not dispose of the battery module in a fire. Risks of Fire: •...
  • Page 8: Notes

    2.6 Personnel Requirements Personnel responsible for the installation and maintenance of HYXiPOWER equipment must first be strictly trained to understand various safety precautions and master the correct operation methods. Only qualified professionals or trained personnel are allowed to install, operate and maintain the equipment.
  • Page 9 2. Safety Instructions User Manual Professional personnel: People who have training or experience in operating equipment and can clearly understand the various potential sources and magnitudes of hazards during equipment installation, operation, and maintenance. Trained personnel: A person who has received the appropriate technical training and has the necessary experience to be aware of the hazards that may be presented to him when performing a particular operation and to take measures to minimize the hazards to himself or to other personnel.
  • Page 10: Limitation Of Liability

    User Manual 3. Limitation of liability HYXiPOWER is not responsible in the event of any of the following • It does not operate in the conditions of use described in this manual. • The installation and use environment do not comply with the provisions of the relevant international or national or regional standards.
  • Page 11: Installation

    4. Installation User Manual 4. Installation 4.1 Installation packing list of Batter Accessories Model Quantity Wall mounting bracket (Optional Purchase for 10kWh) Ground mounting bracket Wall mounting bracket (Optional Purchase for 10kWh) Ground mounting bracket fixing screws (M6*12) Expansion screws High voltage cable(HV+ 4-6mm High voltage cable(HV- 4-6mm Communication cable...
  • Page 12: Location And Environmental Requirements

    4. Installation User Manual Horizontal ruler Vacuum cleaner Protective gloves Goggles Dust mask Insulated shoes 4.3 Location and environmental requirements The battery enclosure has an IP65 protection rating and could be installed indoors and outdoors. The battery has no ventilation requirements. The battery housing should be installed in a location free from the risk of water (standing water, submersion, etc.).
  • Page 13: Precautions

    4. Installation User Manual 4.4.2 Precautions The battery is heavy. There is a risk of injury if the battery is not lifted or dropped properly during transportation or during installation or removal. Two or more people must lift and transport the inverter and battery. When wiring the battery, it must be well protected, one person should wire and one person should supervise and check to prevent the battery short circuit accident.
  • Page 14 4. Installation User Manual HYX-E50-H3 Description Description Ground Terminal Power Switch High-voltage positive socket BMS SOC LED High-voltage negative socket BMS Status LED COM INV Explosive-proof valve COM Parallel...
  • Page 15 4. Installation User Manual HYX-E100-H3 4 5 6 7 8 Description Description BMS SOC LED High-voltage negative socket Power Switch COM INV BMS Status LED COM Parallel Ground Terminal Explosive-proof valve High-voltage positive socket...
  • Page 16: Installation Steps On The Floor

    4. Installation User Manual 4.5.2 Installation steps on the floor • Step 1: Secure the ground mounting bracket to the designated position on the back of the battery using M6*12 screws. • Step 2: Move the battery close to the wall and mark the drilling position. •...
  • Page 17: Installation Steps On The Wall

    4. Installation User Manual Step 4 4.5.3 Installation steps on the wall • Step 1:Use 8- M6*12 screws to fix wall mounting bracket on the battery. • Step 2: Place the wall mounting bracket horizontally on the wall, recommend to select the hole position shown in the picture and mark the drilling position.
  • Page 18 4. Installation User Manual Step 4 Step 3 Step 5 Step 4 DANGER • Before drilling, please make sure to avoid the pre-buried utility lines in the wall to avoid danger; • To prevent dust from entering human respiratory tract or eyes when punching holes, personnel should wear appropriate protective gear.
  • Page 19: Electrical & Com. Connection

    5. Electrical & Com. Connection User Manual 5. Electrical & Com. Connection 5.1 Electrical and Communication Interfaces 5.1.1 Communication Interface (COM INV-BAT) Pins Name Function Connector 12V_BDU_COM Backup power supply RJ45 GND_BDU_COM Backup power supply RJ45 Encode(+) Positive input for encoding RJ45 CAN1H Communication with inverters...
  • Page 20: Power Button

    5. Electrical & Com. Connection User Manual Pins Name Connector Function For debugging use RS485A RJ45 For debugging use RS485B RJ45 Positive input for encoding Encode(+) RJ45 RJ45 RJ45 Negative input for encoding Encode(-) RJ45 Communication with battery CAN2H RJ45 Communication with battery CAN2L RJ45...
  • Page 21: Battery-Inv

    5. Electrical & Com. Connection User Manual The cross-sectional area of the secondary grounding cable must be the same as the cross-sectional area of the PE core in the AC cable. The secondary grounding cable and terminal block are to be prepared by the customer. •...
  • Page 22: Switch On When System Connected

    5. Electrical & Com. Connection User Manual • Connect the inverter's negative quick plug to the BAT- socket of the battery; • Connect the inverter's positive quick plug to the BAT+ socket of the battery; • Connect the inverter's communication cable to the COM port of Battery(Only parallel needs two communication cable).
  • Page 23: Parallel Connection

    5. Electrical & Com. Connection User Manual 5.2.5 Parallel Connection • Step 1: Connect the COM1 port of the first battery (Main battery) to the BMS port of the inverter using the communication cable. • Step 2: Use communication cable to connect all the COM port between the batteries. •...
  • Page 24: Led Indicator Description

    6. LED indicator description User Manual 6. LED indicator description 6.1 LED display and system status Pins Name SOC Green WORK Blue ALARM Red WORK ALARM System Status ● ● ● ● ● ● Shutdown Idle state On 0.5s, off 1.5s According to the power display Normal operation According to the power display...
  • Page 25: Battery System Startup And Shutdown Procedure

    7. Battery system startup and shutdown procedure User Manual 7. Battery system startup and shutdown procedure Battery system startup normal process Turn on the switch, then system will startup. Battery system shutdown process Turn off the switch, then the system will shutdown.
  • Page 26: Online Monitoring

    8. Online monitoring User Manual 8. Online monitoring All the battery data is uploaded to the inverter, and the monitoring is uploaded from the inverter side.
  • Page 27: Routine Maintenance

    9. Routine maintenance User Manual 9. Routine maintenance 9.1 Routine maintenance If the energy storage system is not used for more than three months, it is necessary to charge the energy storage battery to a full charge to avoid over-discharge due to self-consumption of the system. The battery has a discharge depth of 90%, i.e.
  • Page 28: Alarm Description

    Contact HYXiPOWER after-sales staff to solve 1. Restart the device Prohibition of charge/ high voltage relay Battery charging over-voltage 2. Contact HYXiPOWER after-sales staff to solve disconnection the problem 1. Restart the device Prohibition of discharge/high voltage relay Battery discharge undervoltage 2.
  • Page 29 1. Check the connection between BDU and battery pack harness Battery pack communication High Voltage Relay Disconnection lost 2. Contact HYXiPOWER after-sales staff to solve the problem Smoke sensor communication High Voltage Relay Disconnection Contact HYXiPOWER after-sales personnel to lost solve 1.
  • Page 30: Appendix

    10. Appendix User Manual 10. Appendix 10.1 Technical Parameter Battery System HYX-E50-H3 HYX-E100-H3 Appearance Nominal Battery Energy 5.12 kWh 10.4 kWh Usable Capacity ¹ 4.6 kWh 9.36 kWh Nominal Voltage 102.4 V 208 V Working Voltage 86.4 ~ 115.2 V 175.5 ~ 234 V...
  • Page 31: Contact Information

    10. Appendix User Manual 10.2 Contact Information If you have any questions about this product, please contact us. In order to provide you with faster and better after-sales service, we need your assistance in providing the following information. • Equipment model : •...
  • Page 32 Version: UM_HYX-E50/100-H3_User manual_V1.0-2025 The manual is subject to change without notice while the product is being improved. Zhejiang Hyxi Technology Co., Ltd. Building 1, No. 57 Jiang'er Road, Changhe Street, Binjiang District, Hangzhou, Zhejiang Province, China. www.hyxipower.com support@hyxipower.com...
