- Page 3 BEFORE OPERATION OF THIS TOOL, READ & UNDERSTAND ALL OF THE INSTRUCTIONS & SAFETY INFORMATION IN THIS MANUAL. CONTENTS Safety First...............4 Important Safety Information..........5 Parts Breakdown...............8 Set up and Installation............1 1 Page 3...
-
Page 4: Safety First
SAFETY FIRST Safety is essential in the use and maintenance of this tool. This instruction manual & any markings on the tool provide information for avoiding hazards and unsafe practices related to the use of this tool. Observe all of the safety information provided. SAFETY ALERT SYMBOLS This symbol is used to call your attention to hazards or unsafe practices that could result in injury or property damage. -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING Read and understand all instructions and safety information in this manual before operating or servicing this tool. Also read the instruction manual supplied with your drill. FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH. WARNING - PERSONAL SAFETY HAZARDS Only qualified persons should use this equipment. - Page 6 IMPORTANT SAFETY INFORMATION WARNING ENTANGLEMENT HAZARD Do not operate this tool while wearing loose fitting clothing. Put up long hair and keep it away from the unit. Keep hands away from moving objects or anything that can pinch or crush a hand or body part. FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH.
- Page 7 DO NOT ALTER CABLE PULLING EQUIPMENT OR ANY EQUIPMENT BOUGHT FROM iTOOLco. Doing so will VOID YOUR WARRANTY. Guards, testing, and safety features are provided for your protection.
- Page 8 PARTS BREAKDOWN Page 8...
- Page 9 PARTS BREAKDOWN Page 9...
- Page 10 PARTS BREAKDOWN Page 10...
-
Page 11: Setup And Installation
Adjusting the Height of the All Jack Position the All Jack next to the workpiece to adjust to the proper height. On the lower pin, pull pin to adjust the rough height of the final position (Fig 1.). Re-engage pin within 12-15 inches/305-380 millimeters below the final anchored position. - Page 12 SET UP AND INSTALLATION Adjusting the Height of the All Jack (Cont.) On the upper locking pin, pull out and turn the finger ring to the unlocked position to allow the upper arm to extend and retract when engaging the gas shock lever (Fig. 1). While pulling down on the gas shock engagement handle (Fig.
-
Page 13: Adding Extensions
Depress, push pinpoint and connect two poles together. FIG.1 Tying an All Jack to a Railing or Ladder To tie All Jack to a railing or ladder, turn the bracket vertically or horizontally to mate with the framing member. Page 13... - Page 14 SET UP AND INSTALLATION Adjust for Angled Mounting For angled mounting, remove the lower quick bolt (Fig. 1) and adjust to the correct angle. This will allow jack to pivot at any angle you use. FIG.1 Page 14...
