Coltene SciCan BRAVO G4 Quick Reference Manual

BRAVO G4
BASIC OPERATION
1
Power unit ON.
3
Load configurations.
4
Close unit door.
6
Open door.
MAINTENANCE SCHEDULE
Clean the door gasket and internal part of the door with
a clean wet cloth. Check for wear and replace if required.
Daily
Completely empty the waste tank before refilling the
water reservoir.
Clean the chamber and appropriate accessories with
a wet cloth. If required, use a neutral detergent (without
alkalines and bleaches). Carefully rinse with demineralized/
distilled water and remove any residue.
Weekly
Inspect and clean chamber anti-dust filter.
Replace if necessary.
Ensure area around BRAVO G4 is dust free.
Drain & clean the internal water reservoir as per the
instructions outlined in the Operator's Manual.
Monthly
If applicable, clean the external water tank used for
automatic filling.
CA +1 800-667-7733
www.scican.com
US +1 800-221-3046
Quick Reference Guide
2
Fill with demineralized/distilled water.
5
Run cycle.
47'
132°C Hollow wrapped B
Start a cycle.
Select a cycle.
7
Unload instruments.
Check the bacteriological filter and replace
as required.
Lubricate the door lock. Using a clean cloth, remove any
residues and lubricate the inside of the bushing with a film of
the silicone-based grease provided.
Every
3 - 6
Inspect and clean
Months
the chamber
drain filter.
Replace if required.
Every
Year
Replace the door gasket.
or
1,000
Cycles
Coltene International Dental Group
Manufactured for:
Dent4You AG
Bahnhofstrasse 2
CH-9435 Heerbrugg
NEVER USE
TAP WATER
132°C Hollow wrapped B
132°C
1,90 bar
132°C Hollow wrapped B
CYCLE
COMPLETED
133,3°C
133,1°C
1,941 bar
1,929 bar
End of cycle.
8
If required, drain manually.
Distributed by: Distributed by:
SciCan Ltd. Coltene/Whaledent Inc.
1440 Don Mills Road, 235 Ascot Pkwy.
Toronto, ON M3B 3P9 Cuyahoga Falls, OH
Canada 44223, US
Operator's Manual (located on
the USB key) should be consulted
TOUCHSCREEN
Data
Settings
VENTILATION
Front & Side Back
0.78 in /
20mm
0.78 in / 0.78 in /
20mm
20mm
FILLING OPTIONS
Top
Filling
Front
Filling
DRAINING OPTIONS
Manually Automatic
To Release
Spare Parts and Accessories
97400258
Door Gasket 17L/22L
97290160 Bacteriological Filter
97290210 Chamber Drain Filter
99951785
Chamber Rack 17L
99951786 Chamber Rack 22L
99950394
Pouch Rack
99951317
Tray 17L
99951318 Tray 22L
97467066
Tray Extractor
IMPORTANT!
Users of this device must be sure to select the
most appropriate sterilization cycle according
to the recommendations of the leading infection
control authorities and local regulatory
guidelines / recommendations.
before using this autoclave.
Cycles
Solid
Solid, Non-Lumened
Instruments
Hollow
Hollow, Lumened
Instruments
Rubber & Plastics
Textiles, Hollow,
Lumened, Solid
2.75 in /
70mm
