Hella marine APELO 5XA 285 814-001 Instruction Sheet

Please read all instruction in the guide as improper installation may void the warranty.
This product is for recreational DC PWM lights only and not to be used for safety related operation.
Do not mount product onto or near (<50cm) metallic surfaces as it may decrease the radio signal
transmission range of the product.
Do not use this product to control inductive and capacitive loads such as motors, pumps, cranes, etc. as
these types of loads could damage the product.
Do not clean this product with any cleaning chemical that contains Acetone.
Please review the full wiring instructions before use.
Function
Power Supply +VE
1
Power Supply -VE
Switch Function 1
2 Switch Function 2
Switch Common
Light Supply 1
3
Light Supply 2
* Momentary 13A, sustained 12A, @25°C ambient. CH1 and CH2 combined.
Use CH1 to connect Hella Dual Color lamps. Use CH2 to connect Hella RGB/W lamps.
Lamp Return
Red Color Control
4 Green Color Control
Blue Color Control
White Color Control
INSTRUCTION SHEET
5XA 285 814-001
for:
Before you begin
!!!Warning!!!
Quick Wiring Guide
Max Terminal on Backplate
13A PWR +
N/A PWR -
N/A SW
N/A SW
N/A SW
CH1
13A*
CH2
N/A CTRL
3A CTRL
3A CTRL
3A CTRL
3A CTRL
Wire Color
Red ( + )
Black ( – )
Blue ( + )
Brown ( + )
Black ( – )
Red
Red
Black ( – )
Red
Green ( – )
Blue
Brown ( – )
1
