MERGEWORKS EchoDeco INS-EDC Mounting Instructions page 2

Parts List
Description
Item
1 Panel
2 Mount
Self-Drilling Screw
3
4 Cable
2
3
Step 1: Using Self-Drilling Screws (Item 3), Install Mount (Item 2),
2 places appropriately spaced for hanging, in top trim of Panel
(Item 1) as shown.
Self-Drilling Screw
Step 2: Taking into account your ceiling mount option (see separate
ceiling mount instructions), cut 2 lengths of Cable (Item 4) to the
length desired to hang from ceiling, plus a few extra inches for
adjustment.
1
Qty
1
2
4
A/R
4
Mount
DETAIL A
A
Step 3: Insert one end of Cable into Mount by depressing button
on top of Mount, feed approximately 6" of Cable, and release
button to secure. Feed extra cable to side as shown.
Step 4: Install chosen Ceiling Mount option according to separate
Ceiling Mount Instruction.
Step 5: Connect Cables attached to Panel to the Ceiling Mounts.
Step 6: After making final adjustments, trim excess Cable.
Depress to feed,
release to secure.
Feed extra Cable to side.
Trim excess Cable.
