- Page 1 TS-2312-R03 Series Modbus Single Axis Inclinometer Technical Manual V1.0...
-
Page 2: Specifications
Lifting Equipment Inclination Control ⚫ During installation, users can employ the AIT serial port debugging assistant tool or AIT test and calibration software for on - site calibration. This helps correct any angle misalignment at the installation site. - Page 3 *Resolution: The smallest change value of the measured value that the sensor can detect and distinguish within the measurement range. *Accuracy: The root mean square error of the actual angle and the sensor measuring angle for multiple (≥16 times) measurements. AIT Sensing Inc. www.ait-sensor.com Tel ：+1 408 3596016...
-
Page 4: Electrical Interface
Yellow D+ Signal Inclinometer Acquisition − Terminal Green D− Black Ground Figure 2. RS 485 Wiring Diagram DC 9~36V RED VCC Yellow TXD Inclinometer Green RXD Black Ground Figure 3. RS232 Wiring Diagram AIT Sensing Inc. www.ait-sensor.com Tel ：+1 408 3596016... - Page 5 (2). Select the computer serial port and baud rate and click to connect to the serial port. (3). Click Start, the current tilt angle of the inclinometer in the X direction will be displayed on the screen. Figure 4. Software Debugging Interface AIT Sensing Inc. www.ait-sensor.com Tel ：+1 408 3596016...
-
Page 6: Installation
Finally, the mounting surface of the sensor and the surface to be measured must be tightly fixed, smooth in contact, and stable in rotation, and measurement errors due to acceleration and vibration must be avoided. AIT Sensing Inc. www.ait-sensor.com Tel ：+1 408 3596016... - Page 7 (inch) Figure 5. Outline Dimensions PCB Dimensions The length and width may have an error of ± 1mm, please refer to the actual product. Unit mm (inch) Figure 6. PCB Dimensions AIT Sensing Inc. www.ait-sensor.com Tel ：+1 408 3596016...
- Page 8 Modbus Single Axis Inclinometer TS-2312-R03 Figure 7 . Top View of TS-2312-R03 Table 3. Mechanical Index Connector Metal joint（Cable 1.5m) Protection level IP67 Shell material Magnesium aluminum alloy oxidation Installation Three M4 screws AIT Sensing Inc. www.ait-sensor.com Tel ：+1 408 3596016...
