OPFXS DIG DEEP MK1 User Manual

Table of Contents
1.
Introduction
2.
Controls
3. Function Switch Settings
1. Toggle Between Fast and Slow SUB ATTACK
2. Toggle Between MONO and SPLIT Output
3. Set TRACKING
4. Set SUB TONE
4.
Tips for Optimal Performance
5.
Internal Trimmer Adjustment
6.
Specifications
7.
Warranty Information
1. Introduction
Thank you for choosing the DIG DEEP MK1 Sub-Harmonic Octaver by OPFXS. This user manual will
guide you through the operation, controls, and maintenance of your pedal. Please read this manual carefully
to ensure you get the most out of your DIG DEEP MK1 experience.
2. Controls
DRY
The DRY knob sets the level of the dry input signal. The DRY knob can both boost or reduce gain. DRY knob
has a secondary function called TRACKING which can be accessed through FUNCTION switch.
SUB
The SUB knob sets the level of the lower octave. SUB knob has a secondary function called SUB TONE which
can be accessed through FUNCTION switch.
FUNCTION
The FUNCTION switch is used to set various functions, including SUB ATTACK, SPLIT OUT, TRACKING, and
SUB TONE.
OPFXS DIG DEEP
Sub-Harmonic Octaver
opfxs.com
- User manual -
Revision:
MK1
27/12/2024
