- Page 1 KOUPLE INSTRUCTION MANUAL PARALLEL CONTROL UNIT Electrical feeding 110-230V~ 50/60Hz – 24V═ 4420070 – Rev. 20220628...
- Page 2 When correctly assembled, installed and used according to the present instructions, they will not generate any danger for persons, animals or items.
-
Page 3: Table Of Contents
ID PLATE AND MARKING DATA ..................5 RECOMMENDATIONS AND INSTRUCTIONS FOR ASSEMBLY ........6 ELECTRICAL CONNECTIONS ..................6 6.1. Electrical connection of KOUPLE 230V ..............6 6.1.1. Meaning and colour of the wires to be connected to the control unit ....6 6.1.2. -
Page 4: Safety Indications
KOUPLE is a unit that controls the parallel functioning (tandem) of two motors in 110/230V~ (AC) 50/60Hz or 24V═ (DC), equal to each other and mounted on the same frame. -
Page 5: Technical And Constructional Information
TECHNICAL AND CONSTRUCTIONAL INFORMATION The KOUPLE has been designed to feed in parallel 2 actuators – that is 2 exits – having the same nature and characteristics. The specific use is intended to powering 2 chain or rack actuators for ventilation, local air conditioning worked by the connected motors; all other use is not recommended unless prior approval from the manufacturer. -
Page 6: Recommendations And Instructions For Assembly
In order to facilitate the wiring process, it is recommended that you remove the board from the container. 6.1. Electrical connection of KOUPLE 230V The electrical connections to the control unit are the following: The cable of the movement control switch (button) should be connected to the “... -
Page 7: Operating Principle And Meaning Of The Leds
The control unit manages two outputs and controls their current draw. When an output stops drawing current due to a mechanical or electrical blockage, KOUPLE also blocks the power supply of the other output after about 1.5 seconds. The blockage of the machines occurs by removing the power supply voltage from both outputs. -
Page 8: Selection Of The Dip-Switches
The unit is factory-set with the default settings having both dip-switches to OFF. 6.2. Electrical connection of KOUPLE 24V The electrical connections to the control unit are shown in fig.1: The cable of the movement control switch (button) should be connected to the “IN”... -
Page 9: Operating Principle And Meaning Of The Leds
The intervention threshold and delay have been chosen to satisfy the majority of applications on the market. The intervention of the KOUPLE 24VDC is signalled by a red LED which is steady-on as long as there is power. Under normal conditions, the LED is not lit. -
Page 10: Environmental Protection
ENVIRONMENTAL PROTECTION All materials used in the manufacture of this appliance are recyclable. We recommend that the device itself, and any accessories, packaging, etc. be sent to a centre for ecological recycling as established from laws in force on recycling. The device is mainly made from the following materials: Iron Aluminium... -
Page 11: Declaration Of Conformity
Telephone number: +39 0424 411011 E-mail address: info@nekos.it declare that the document is issued under our sole responsibility and belongs to the following product: Apparatus model / Product: Control unit KOUPLE Trademark: NEKOS Model/Type: KOUPLE 230V – KOUPLE 24V Batch:... - Page 12 NEKOS S.r.l. I - 36064 - COLCERESA (VI) - Via Capitoni, 7/5 Phone +39 0424 411011 Fax +39 0424 411013 info@nekos.it http://www.nekos.it...
