B3 NON-PENETRATING
ROOF MOUNT
The B3 NPRM is a flexible and heavy
duty non-penetrating roof mount for
ground and roof-top mounting. This
model has a footprint of 9.69 ft
mast height between 8ft and 10ft.
Hardware
Frame assy (1), mast assy (1), LH brace angle (1), RH
brace angle (1), rear brace angle (1), 3/8" x 4" tap
bolt GR.5 (2), 3/8" USS flatwasher (2), 3/8" whiz lock
nut (2), 3/8" x 1" bolt GR.5 (5), 3/8" Nut (5), 3/8" split-
lockwasher (5), Cinder Blocks (10-not included)
Power Supply
120 volt & solar power
Operating Environment
Outdoor use
