MOUNT INSTALLATION
SPECIFICATIONS
Compatibility
Cobalt
Static Sapphire
Power Supply
120 volt & solar power
Operating Environment
Outdoor use
|
O X B L U E . C O M
1 7 7 7 E L L S W O R T H I N D U S T R I A L B LV D N W, AT L A N TA , G E O R G I A 3 0 3 1 8
VPTZ Sapphire
Ultra PTZ
B4 NON-PENETRATING
ROOF MOUNT
Modi sam eos et explam estini
blaborestrum sitate voluptas quidipis
milluptaerum quas mos ex exerfer
naturi doluptia se quo officimus
eaquae lit accatem ea nient as eles
corunt idebisc iassum que volo
Hardware
Support tube assembly (1), 6' ballast angle (4), 16" side
pad (4), mast (1), long rear brace (1), right side brace
(1), left side brace (1), brace clamp assembly (1), cinder
blocks (not provided)
A
3/8"x1" bolt GR.5 (20)
B
3/8" x 4" tap bolt GR.5 (3)
C
3/8" nut (19)
D
3/8" split-lockwasher (20)
E
3/8" whiz lock nut (3)
F
3/8" uss flatwasher (2)
|
